SEDLBAUER speed win PCI Manual

16 bit-isdn-controller/isdn-usb-adapter, pci-isdn-controller/isdn-pcmcia-adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual
Document version
1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the speed win PCI and is the answer not in the manual?

Questions and answers

Summary of Contents for SEDLBAUER speed win PCI

  • Page 1 Manual Document version 1.00...
  • Page 2 ISDN terminal. All rights reserved. No part of this manual may be reproduced without the written permission of Sedlbauer AG. Although the greatest care was taken in compiling the texts in this manual, it is never possible to rule out mistakes entirely.

  • Page 3: Table Of Contents

    7.1.2 Installation of plug & play ISDN adapters ....................41 7.1.3 Configuration of the ISDN adapter ......................43 The Sedlbauer CAPI 2.0 RAS driver under Windows ME .................46 7.2.1 Functions ..............................46 7.2.2 Installation of the Capi 2.0 RAS driver for Windows ME ................46 7.2.3...
  • Page 4 Installation of the CAPI-Driver .........................64 9.4.2 Installing the Capi 2.0 RAS driver ......................67 9.4.2.1 Simultaneous installation of the Sedlbauer Capi 2.0 RAS driver and the Windows NT network support 67 9.4.2.2 Installing the Sedlbauer Capi 2.0 RAS driver with activated network support ........70 9.4.2.3...

  • Page 5: Foreword

    Manual ISDN Adapter - Foreword - 1 Foreword This manual describes installation and operation of the following ISDN adapters from Sedlbauer AG: • speed win PCI plug-in card for PCI bus • speed card plug-in card for ISA-bus • speed star PCMCIA adapter •...

  • Page 6: Scope Of Delivery

    Manual ISDN Adapter - Foreword 2 Scope of delivery • • • • ISDN-Adapter • • • • connection cable • • • • CD-ROM with the following software: CAPI driver software for the DSS1 protocol CAPI 2.0 RAS driver for DFÜ networking connections Supported Operating Systems: Windows 95 Windows 98...

  • Page 7: Performance Features

    Manual ISDN Adapter - Performance features - 3 Performance features • Suitable for ISDN basic rate interface and PBXs with a DSS1 interface. • The ISDN adapter is approved according to the effective regulations • • • • The ISDN Adapter fulfils the emitted interference requirements specified in EN 55022:1994 Class B •...

  • Page 8: Startup

    A vacant ISA bus slot for the speed card • • • • A vacant PCI bus slot for the speed win PCI • • • • For the speed star the PC must have a PCMCIA interface according to the PCMCIA standard 2.0.

  • Page 9: Hardware Installation

    Manual ISDN Adapter - Startup /Technical Requirements / Hardware Installation 4.2 Hardware installation 4.2.1 Installation of „speed win PCI“ Caution: First disconnect the PC from the 230 V mains! To install the ISDN controller, open your PC as described in your manual supplied with your computer. Insert the ISDN adapter in a vacant PCI bus slot.
  • Page 10 Manual ISDN Adapter- Startup/Hardware Installation IRQ15 IRQ12 RJ-45-Slot IRQ11 IRQ10 IRQ7 IRQ5 (Default-Setting IRQ4 IRQ3 Jumper to set the Hardware-Interrupts Setting the I/O address The I/O address is set by the DIP switch in the middle of the card. Note: I/O address on default: 270h DIP-Switch (S1-S8) to set the I/O address-...
  • Page 11 Manual ISDN Adapter - Startup /Technical Requirements / Hardware Installation DIP standard settings Port Address DIP-Switch COM1 3F8h COM2 2F8h COM3 3E8h COM4 2E8h LPT1 378h LPT2 278h 220h These addresses 270h can be used 280h for expansion! 300h 310h 330h Note: •...

  • Page 12: Installation Of „Speed Star

    Should you have any problems or questions, please contact your computer vendor. 4.2.4 Installation of „speed USB Installing the hardware is easy. Connect the „Sedlbauer“ „speed USB“ to a free USB port. When the adapter is connected to the USB port of your computer during operation the software installation will start immediately.

  • Page 13: S Interface

    PC to the S bus of the ISDN system. Use the supplied connection cable to join the RJ-45 jack (Western jack) of the ISDN adapter to an S jack. speed win PCI/speed card -Interface Figure 4.3.1 speed star...
  • Page 14 Manual ISDN Adapter- Startup/S Interface The following chapters describe the software installation for the various operating system (or user interfaces) that are supported by the ISDN adapter. Select the section concerning the operating system (or user interface) on which the ISDN adapter will be installed and configured.

  • Page 15: Software Installation For Windows 95

    Windows 95. These Sedlbauer ISDN adapters are plug & play adapters, i. e. Windows 95 automatically identifies the adapter as a new hardware component. If you use „speed star“ please note that the adapter must be plugged in! Insert the installation CD-ROM in the correct drive.

  • Page 16: Configuring The Capi-Driver

    Click the „Device Manager“ tab in the „System Properties“ dialog box and select „View devices by type“. The following dialog box appears: Figure 5.2.1.1 • Select „Sedlbauer ISDN-PC-Adapter...“and then click <Properties>. The „Sedlbauer ISDN-PC- Adapter ...“ dialog box appears. • Click the „EAZ< < < < MSN“ tab to open the EAZ-MSN mapping table.
  • Page 17 Manual ISDN Adapter - Startup /Software Installation for Windows 95 Figure 5.2.1.2 In this table you can assign an MSN to an EAZ (terminal selection digit). • Click the <Apply> > > > button to save the settings for EAZ-MSN mapping.

  • Page 18: Uninstalling The Capi Driver

    Click the „Device Manager“ tab in the „System Properties“ dialog box and select „View devices by type“ (see figure 5.2.1.1) • Select „Sedlbauer ISDN-PC-Adapter...“ and click the < < < < Remove> > > > button. • Click <OK> in the „Confirm Device Removal“ dialog box.

  • Page 19: Installing The Sedlbauer Ndis-Wan Miniport Driver

    Manual ISDN Adapter - Startup /Software Installation for Windows 95 5.3 Installing the Sedlbauer NDIS-WAN Miniport driver The NDIS-WAN Miniport driver enables you to access the Internet, e.g. with the Microsoft Internet Explorer. The driver also allows you to connect to Windows NT or windows 95/98/ME/2000 computers by means of RAS (Remote Access Services) or Dial-Up Networking.

  • Page 20: Tcp/Ip-Protocol

    Manual ISDN Adapter - Startup /Software Installation for Windows 95 Once you have selected „Communications“, click < < < < Details...> > > > to open the „Communications“ window. Select „Dial-Up Networking“ and click < < < < OK> > > > twice to accept your choice and the following dialog box. When prompted, insert the Windows 95 CD to install Dial-Up Networking.

  • Page 21: Installation

    Manual ISDN Adapter - Startup /Software Installation for Windows 95 5.3.3 Installation You will need the German version of the Microsoft ISDN Accelerator Pack 1.1, the Sedlbauer Miniport driver and your Windows 95 CD. The Miniport driver and the Accelerator Pack are on the Installation CD-ROM.
  • Page 22 Manual ISDN Adapter - Startup /Software Installation for Windows 95 Figure 5.3.3.2.1 Confirm this dialog box and the next with < < < < OK> > > > .to continue with the installation. The next dialog box displays a message concerning the information required by Windows about your ISDN service.
  • Page 23 Manual ISDN Adapter - Startup /Software Installation for Windows 95 Figure 5.3.3.2.3 At this point you may be prompted to insert the Windows 95 installation CD in your CD drive and specify the drive and path. Version conflicts similar to those shown in the next figure may be identified under certain circumstances when copying the files.

  • Page 24: Software-Installation For Windows 98

    Windows 98. These speed USB ISDN adapters like speed win PCI, speed star and speed USB are plug & play adapters, i. e. Windows 98 automatically identifies the adapter as a new hardware component. If you use „speed star“, please note that the adapter must be plugged in! Windows 98 interactively guides you through the installation.
  • Page 25 Manual ISDN Adapter - Startup /Software Installation for Windows 98 • In the next dialog box you may be asked for the components for your ISDN adapter - speed card. Figure 6.1.1.2 For notes to the ISDN guard please see chapter 10. •...

  • Page 26: Installation Of Plug & Play Isdn Adapter

    In the next window click “CD-ROM drive” and confirm with <Next>. • Confirm the request for restart with <Yes> Now, the Sedlbauer AG ISDN configuration will be started: Select the language you wish to guide you through installation. Confirm with “Next”...

  • Page 27: Configuration Of The Isdn Adapter

    The IRQ and The I/O-address of speed card can be changed in the device manager (Start/Settings/Control Panel, double-click on the icon “System”, register card “device manager”). • Double-click “Sedlbauer ISDN adapter” • Mark “ISDN adapter ISA” and select the button <Properties>.
  • Page 28 Manual ISDN Adapter - Startup /Software Installation for Windows 98 General settings: D-channel-protocol: This field is to fix the signalling protocol: (DSS1) Test mode: This field is to select the test mode when starting the driver. Standard: Adapter Figure 6.1.3.1 Advanced settings: Figure 6.1.3.2...
  • Page 29 June 1998 the specification for the CAPI 2.0-implementation of V.42bis was changed. Unfortunately the two versions are not compatible. The drivers for the Sedlbauer ISDN-adapter use the new standard as default setting from driver version 2.2 rev. 0.5. Activate by application: Only applications requiring a V.42bis extended protocol via...

  • Page 30: The Sedlbauer Capi 2.0 Ras Driver Under Windows 98

    In order to fulfil the above functions the Capi 2.0 RAS driver must be installed. To do so you need the Sedlbauer and your Windows CD ROM. • Insert the Sedlbauer CD into the right drive. Now the installation program will be started. • Click “Language” and <Next>...

  • Page 31: Isdn Configuration

    Manual ISDN Adapter - Startup /Software Installation for Windows 98 Mark “CAPI 2.0 RAS driver” and click “OK” twice. Figure 6.2.2.2 6.2.3 ISDN Configuration Select the Switch-protocol for your ISDN-adapter Confirm with <Next> Figure 6.2.3.1 In this dialog box you can select your call number(s) and SPID (Service Profile ID) Confirm with “Next”...
  • Page 32 Manual ISDN Adapter - Startup /Software Installation for Windows 98 Now you are asked to insert your Windows 98 CD. Click <OK>. Should the message “Cannot find Capiras.sys” appear insert again Sedlbauer CD-ROM and enter the path Example for installation from CD-ROM drive D: D:\CAPIRAS\WIN9X Confirm the following prompt for restart with „Yes“.

  • Page 33: Capi- Driver Update

    ● Click the „Device manager“ tab in the „System Properties“ dialog box and select „View devices by type“ ● Mark the “ISDN adapter…” in the field “Sedlbauer ISDN adapter” and click the <Remove> button ● Confirm with <OK> ● In the next dialog box “Sedlbauer AG ISDN-configuration” mark “Sedlbauer AG ISDN configuration for…”...

  • Page 34: Ppp- Access To T-Online

    Manual ISDN Adapter - Startup /Software Installation for Windows 98 6.5 PPP- Access to T-Online Have ready your T-Online Access data you will need them. The PPP-Access to T-Online enables you to access the Internet without the T-Online decoder. When you start the Internet browser a connection to the Internet will be established without calling T-Online.
  • Page 35 Manual ISDN Adapter - Startup /Software Installation for Windows 98 Figure 6.5.3 • Select the “Server Types” tab and enter the settings shown in the next figure. • Please note the following alternatives: • You should select “Log on to network” only when you are working in a local network. Stand-alone computers are somewhat faster in the Internet when this option is not marked.
  • Page 36 Manual ISDN Adapter - Startup /Software Installation for Windows 98 Note: T-Online works with IP addresses assigned by the server. Any IP addresses defined here will be invalid. The “Name server address” is supplied when the connection is made, i.e. it does not have to be defined.
  • Page 37 Manual ISDN Adapter - Startup /Software Installation for Windows 98 Figure 6.5.7 Note: A user name consists of the following components: Terminal identification code (here: 000184920268) T-Online no. (telephone number, here: 08154711) Co-user number (here: 0001), which must be separated by # if the telephone number has less than 12 digits Your personal password for your T-Online terminal is used as the password.

  • Page 38: Setting Up A Multilink Connection

    Manual ISDN Adapter - Startup /Software Installation for Windows 98 6.6 Setting up a Multilink connection The Sedlbauer Capi 2.0 RAS driver supports multilink PPP. This allows you to bundle the two ISDN user channels, doubling the speed of transmission to 128 kBit/s.

  • Page 39: Software-Installation For Windows Me

    Windows ME. These speed USB ISDN adapters like speed win PCI, speed star and speed USB are plug & play adapters, i. e. Windows ME automatically identifies the adapter as a new hardware component. If you use „speed star“, please note that the adapter must be plugged in! Windows ME interactively guides you through the installation.
  • Page 40 Manual ISDN Adapter- Startup/Software Installation for Windows ME Figure 7.1.1.1 In the next dialog box enter the components your ISDN adapter needs speed card. Figure 7.1.1.2 You can find notes on the ISDN guard in chapter 10. Confirm with <Finish>. Turn off your computer and install your ISDN-adapter as descriped in chapter 4.2.2 and 4.3.

  • Page 41: Installation Of Plug & Play Isdn Adapters

    ”Automatic search for a better driver (recommended)”. Insert the installation CD-ROM delivered with this adapter. • Confirm the request for restart with <Yes>. After restart the Sedlbauer AG ISDN configuration appears: Select the language you wish to guide you through configuration. Confirm with <Next>...
  • Page 42 Manual ISDN Adapter- Startup/Software Installation for Windows ME speed USB Figure 71.2.3 You can find notes on the ISDN guard in chapter 10. • Confirm with <Finish>. Your ISDN adapter is now installed.

  • Page 43: Configuration Of The Isdn Adapter

    The IRQ and the I/O address of speed card can be changed in the device manager (Start/Settings/System Control, double click on the icon “System”, register card “device manager”). • Double click on “Sedlbauer ISDN adapter” • Mark “ISDN adapter ISA and select the button <Properties>.
  • Page 44 June 1998 the specification for the CAPI 2.0-implementation of V.42bis was changed. Unfortunately the two versions are not compatible. The drivers for the Sedlbauer ISDN-adapter use the new standard as default setting from driver version 2.2 rev. 0.5. Activate by application: Only applications requiring a V.42bis extended protocol via...
  • Page 45 Manual ISDN Adapter - Startup /Software Installation for Windows ME The register card “Info” The register card “Info” contains notes on copyright- and programm versions, the address of the manufacturer as well as the opportunity to check the file & version of the drivers. When you click “driver versions”...

  • Page 46: The Sedlbauer Capi 2.0 Ras Driver Under Windows Me

    In order to fulfil the above functions the Capi 2.0 RAS driver must be installed. To do so you need the Sedlbauer and your Windows ME CD ROM. • Insert the Sedlbauer CD into the right drive. Now the installation program will be started. • Click “Language” and <Next>...
  • Page 47 Manual ISDN Adapter - Startup /Software Installation for Windows ME Select the button “Have disk” and enter the following path in the next window: Example for installation from CD-ROM drive D:\CAPIRAS\WINME Confirm with “OK” Note: When installing speed USB enter the following path: Example for installation from CD-ROM drive D:\capiras\WINME.USB...

  • Page 48: Isdn Configuration

    In this dialog box you can select your call number(s) and SPID (Service Profile ID) Confirm with “Next” and follow the instructions Figure 7.2.3.2 Confirm the following prompt for restart with „Yes“. Now the Sedlbauer Capi 2.0 RAS driver is completely installed!

  • Page 49: Capi- Driver Update

    ● Click the „Device manager“ tab in the „System Properties“ dialog box and select „View devices by type“ ● Mark the “ISDN adapter…” in the field “Sedlbauer ISDN adapter” and click the <Remove> button ● Confirm with <OK> ● In the next dialog box “Sedlbauer AG ISDN-configuration” mark “Sedlbauer AG ISDN configuration for…”...

  • Page 50: Software Installation For Windows 2000

    Windows 2000. These Sedlbauer ISDN adapters as speed win PCI, speed star and speed USB are plug & play adapters, i. Windows 2000 automatically identifies the adapter as a new hardware component. If you use speed star, please note that the adapter must be plugged in! Windows 2000 guides you through installation.
  • Page 51 Double-click I/O-sector and select a free worth. Consider the conflict information, too. Figure 8.1.1.3 • Confirm with <OK> • Close the resource-window by clicking <OK> • Select <Next> In the next window the Sedlbauer AG ISDN configuration will be started (see figure 8.1.1.4).
  • Page 52 • Confirm the next message “Installation successfully completed” with <OK>. • Now, the Sedlbauer speed configuration appears. Take over the standard settings as described in chapter 8.1.3 and confirm with <OK>. • Click <complete> and answer the request for restart with <No>.

  • Page 53: Installation Of Plug & Play Isdn Adapters

    Select the language you wish to guide you through installation and confirm with <Next>. • In the following window you can select the components for your ISDN adapter. Mark “Sedlbauer speed configuration” and “Sedlbauer speed ISDN guard”. You can find notes on the ISDN-guard in chapter 10.

  • Page 54: Configuration Of The Isdn-Adapter

    Don´t forget to change the settings on speed card. Note: If your ISDN adapter is already installed you can start ISDN configuration by selecting „Start/Programs/Sedlbauer ISDN configuration“ on your Windows-desktop. ● The ISDN-adapter can be configured in the next dialog box (see figure 8.1.3.1).
  • Page 55 June 1998 the specification for the CAPI 2.0-implementation of V.42bis was changed. Unfortunately the two versions are not compatible. The drivers for the Sedlbauer ISDN-adapter use the new standard as default setting from driver version 2.2 rev. 0.5. Activation by application: Only applications requiring a V.42bis extended protocol via...

  • Page 56: The Sedlbauer Capi 2.0 Ras Driver Under Windows 2000

    For the above mentioned functions the Capi 2.0 RAS driver has to be installed. Therefore you need the Sedlbauer CD-ROM and the Windows 2000 CD: For installation please proceed as follows: • Insert the Sedlbauer CD into the right drive. Now the installation program will be started. • Click “Language” and <Next> •...
  • Page 57 Manual ISDN Adapter - Startup /Software Installation for Windows 2000 ● Mark „No, I want to select the hardware from a list“ and confirm with „Next“. ● In the next dialog box select the hardware type „Network adapters“ and click „Next“ (see figure 8.2.2.2).
  • Page 58 Manual ISDN Adapter- Startup/Software Installation for Windows 2000 digital signature). You can confirm it with <YES>. ● Now, select the type of the ISDN transmission or the D-channel-protocol used by your telephone company (see figure 8.2.2.5). Figure 8.2.2.5 ● Confirm with <Next> Figure 8.2.2.6 Note: You can modify the above settings at any time in the device manager.

  • Page 59: Configuration Of Call Numbers For Ras

    8.2.3 Configuration of call numbers for RAS With the following settings you can enter the call numbers for the CAPIRAS-Lines of the Sedlbauer Capi 2.0 RAS driver. You only need these numbers if you want to use the Dial-up network. In the case of incoming calls they select the right device.

  • Page 60: Capi Driver Update

    Select „Sedlbauer ISDN Adapter..“ and click the <Uninstall> button. ● Click <OK> to confirm. ● In the next dialog box „Sedlbauer ISDN configuration“ mark „Sedlbauer AG ISDN configuration for...“ and click <Uninstall>. Confirm with <OK>. ● Restart your computer. The driver for the ISDN adapter is now removed!

  • Page 61: Software Installation For Windows Nt

    ISDN system and enable you to use its various services and features. Sedlbauer CAPI drivers support CAPI 2.0 for 16 bit and 32 bit applications. You can thus choose from a variety of communication options depending on the function of the ISDN application program connected to the standardized ISDN-CAPI interface.

  • Page 62: Installation With Activated Plug & Play Support

    9.2 Installation with activated plug & play support If plug & play support is installed on your PC, the Sedlbauer ISDN adapters are recognized automatically after start up the PC, that means after the hardware installation the operating system will announce that it has found a new hardware component.

  • Page 63: Installation With The Setup-Program Of Cd-Rom

    With detailed help texts the setup program guides you interactively through the various installation steps. To carry out the installation, insert the Sedlbauer CD-ROM in the drive. Provided the autorun function is not deactivated on your PC, the setup program will start up automatically. If it is deactivated, please start the file SETUP.EXE directly from the CD directory.

  • Page 64: Manual Installation

    Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 Figure 9.3.2 In the following window please select the type of the adapter and confirm with <OK>. 9.4 Manual installation 9.4.1 Installation of the CAPI-Driver You can install the CAPI drivers manually rather than use the setup program on the CD-ROM •...
  • Page 65 Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 Figure 9.4.1.2 • Mark “speed ISDN configuration” and “speed ISDN Guard” if needed (for notes on the ISDN guard see chapter 10). • Confirm with <Finish> • Confirm the next message “Installation successfully completed” with <OK>. •...
  • Page 66 Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 Figure 9.4.1.4 Caution: Please check whether the interrupt as well as the I/O address displayed on your computer are assigned. If so, please try other unassigned values. Under “Start/Programs/Windows NT diagnosics”, (register card “Resources”) the values can be displayed.

  • Page 67: Installing The Capi 2.0 Ras Driver

    Should you have installed no network board or the Windows NT 4.0 network support please start installation as described in chapter 9.4.2.1. Otherwise please start as described from chapter 9.4.2.2. 9.4.2.1 Simultaneous installation of the Sedlbauer Capi 2.0 RAS driver and the Windows NT network support •...
  • Page 68 Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 • Confirm with <OK>. Figure 9.4.2.1.4 • Click <OK> to install the supplied CAPI driver. • Click <Next>. • In the following applet select the network protocol for the internet access via the dial-up network. Chapter 9.4.6 shows an example of the configuration for an internet access via the „dial-up network“...
  • Page 69 E:\i386 • Confirm with <Continue>. Figure 9.4.2.1.7 • If figure 9.4.2.1.8 appears insert Sedlbauer CD-ROM into the corresponding drive and click <OK>. Figure 9.4.2.1.8 • Follow the instructions now. • The installation assistant for CAPI 2.0 drivers will now be started.

  • Page 70: Installing The Sedlbauer Capi 2.0 Ras Driver With Activated Network Support

    Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 9.4.2.2 Installing the Sedlbauer Capi 2.0 RAS driver with activated network support Note: Have ready your Sedlbauer as well as your Windows NT CD. • Click with the right-hand mouse button „Network Neighbourhood“ on your desktop, select in the following context menu „Properties“...

  • Page 71: Part 2 - Installing The Capi 2.0 Ras Driver

    Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 9.4.2.3 Part 2 – Installing the Capi 2.0 RAS driver • The following dialog box shows the name of the CAPI 2.0 device and the controller number Figure 9.4.2.3.1 • Confirm with „Next“ •...
  • Page 72 • Confirm with <Continue> • Should „Unable to open the file E:\capiras.sys“ appear, insert Sedlbauer CD and confirm with <Retry>. Continue to follow the instructions. • In the following window you are asked to add the two RAS capable devices.
  • Page 73 Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 • The second RAS capable device ISDN2-Capiras has to be added in the next window via <Add> (see figure 9.4.2.3.6). Figure 9.4.2.3.6 • With <Configure> you can specify whether the specific channel is to be used for incoming and/or outgoing connections.
  • Page 74 Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 Figure 9.4.2.3.8 • Confirm with <Continue> and follow the instructions. Figure 9.4.2.3.9 Confirm the above dialog box with <Yes> to restart the computer. After restart you can check in the „Device manager“ - it is started by selecting the „Control Panel“ from the „Start/Settings“...

  • Page 75: Configuration

    Note: For the adapter „speed win PCI“ the I/O address and the IRQ´s are automatically set by the operating system. You will only get a window informing you about the automatic setting, but cannot change the resource settings.
  • Page 76 Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 • After marking the adapter in the above window with the mouse click <Properties>. • You can now use the selection list to change your requirements for the particular Adapter type and Recourse type (Interrupt and I/O range).
  • Page 77 June 1998 the specification for the CAPI 2.0-implementation of V.42bis was changed. Unfortunately the two versions are not compatible. The drivers for the Sedlbauer ISDN-adapter use the new standard as default setting from driver version 2.2 rev. 0.5. Activate by application: Only applications requiring a V.42bis extended protocol via...

  • Page 78: Configuration Of Call Numbers For Ras

    Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 9.4.3.2 Configuration of call numbers for RAS In the case of RAS connections via Sedlbauer CAPI 2.0 driver, a call number for incoming and outgoing calls can be configured for each device. The procedure is as follows: ●...

  • Page 79: Driver Update

    Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 ● Enter your call number. If it is applied for the service feature, a „sub address“ can be entered in this box. Should you wish your call number not to be shown to the opposite terminal activate „Do not show to opposite terminal“.

  • Page 80: Uninstalling The Driver Software

    Proceed as follows to remove the CAPI driver: ● Select the „Control Panel“ from the „Start/Settings“ menu of your Windows NT 4.0 desktop. ● Double-click on the icon „Software” Figure 9.4.5.1 ● Mark „Sedlbauer AG ISDN configuration for Win NT 4.0“ and select <Add/Remove> button.
  • Page 81 Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 Figure 9.4.5.2 ● Mark: Sedlbauer AG ISDN Configuration“ and select <Add/Remove>. Figure 9.4.5.3 ● Confirm with <OK>. ● Confirm the following prompt with <Yes>. Figure 9.4.5.4 The CAPI driver for the ISDN adapter is now removed!

  • Page 82: Internet Access Via The Dial-Up Network Using T-Online As Example

    Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 9.4.6 Internet access via the Dial-Up Network using T-Online as example The Windows NT Dial-Up Network enables you to set up connections to an Internet service provider. The necessary steps for obtaining access to the Internet are described below using the example of T-Online via PPP.
  • Page 83 Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 ● This new connection now needs to be configured. To do so, select the entry in question from the phone book and click on <Continue>. In the following menu select „Edit entry and modem properties...“...
  • Page 84 Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 Figure 9.4.6.5 Confirm both windows with <OK> in order to return to the „Dial-Up Networking“. Note: Should the assistant for new telephone book entries not be started automatically, a new telephone book entry will immediately be made up, which must then be configured according to figure 9.4.6.3 ff.
  • Page 85 Manual ISDN Adapter- Startup/Software Installation for Windows NT 4.0 Figure 9.4.6.7 If you start your Internet Browser now, such as e.g. the Microsoft Internet Explorer, you can use internet services like the World Wide Web via the existing connection. In order to disconnect the connection again, click on the icon in the task bar with the right-hand mouse button and select the connection to be terminated under the point „Disconnect“.

  • Page 86: General Information

    ● Mark „Sedlbauer ISDN-Adapter...“ and click on the <Properties> button to obtain the resource settings.(For speed win PCI the resources are not displayed as they are assigned by the operating system.) To find out your driver version choose “Start/Programs/Sedlbauer ISDN Configuration” on the Windowsdesktop.

  • Page 87: Isdn-Guard

    Manual ISDN Adapter - ISDN Guard 10 ISDN-Guard The ISDN-guard will be installed together with the CAPI driver for the ISDN adapter. This program ensures that all connections performed with the ISDN adapter will be logged in a display window. The following data will be recorded and displayed (see also figure 10.1): Date, time, duration of connections Direction of connections (incoming or outgoing)

  • Page 88: Uninstalling The Isdn-Guard

    10.1 Uninstalling the ISDN-Guard Please proceed as follows to remove the ISDN-Guard Doubleclick the icon “Software” in the “System Control” menu (Start/Settings/System Control) Mark the “Sedlbauer speed ISDN Guard” Click <Add/Remove...> Mark “Sedlbauer speed ISDN Guard” Click <Uninstall>...

  • Page 89: Important Terms

    Manual ISDN Adapter – Important terms 11 Important terms Term Explanation 1TR6 protocol National D channel protocol of Deutsche Telekom AG (National ISDN) Accelerator Pack With this program it is possible to run all Windows applications with networking capabilities via ISDN. It provides the support required by a program to initialize remote connections, e.g.
  • Page 90 The biggest computer network in the world Interrupt Request IRQ is a signal (or a line) used by a peripheral device (e.g. „speed win PCI“) to trigger a hardware interrupt on the CPU. An interrupt request is used, for example, on the „speed win PCI“ to control the exchange of data between it and the CPU.
  • Page 91 Manual ISDN Adapter – Important terms Service indicator SIN is used to distinguish between devices which are connected to the same ISDN bus. Examples: SIN1 analog telephony SIN2 a/b services SIN4 fax group 4 SIN 7 64kbit/s data transfer SIN9 teletex or telex TAPI TELEPHONY APPLICATION PROGRAMMING INTERFACE.

  • Page 92: Technical Support

    If the problems cannot be corrected, please fill all the possible relevant comments in the annexed form. Return the completed form to the dealer from which you bought the product or fax it directly to Sedlbauer AG (fax no.: .49-8552-41-280).
  • Page 93 City: .......... FAX: ........eMail: ........Source of supply: Where did you buy the Sedlbauer products? ............................Have you already contacted your dealer in connection with your problem? What was the result? ..................................................Product name ........... Serial number of the hardware:......
  • Page 94 Manual ISDN Adapter- Technical support / Problem report page 2/3 What accessories does your PC have (e.g. graphic-, LAN-, video-, sound cards etc.)? ............................. What I/O addresses and IRQs are set for these cards? ............................. How is your PC connected to ISDN? ! ! ! ! Basic access ! ! ! ! Private branch exchange Manufacturer, type of private branch exchange: ................
  • Page 95 Manual ISDN Adapter - Technical support / Problem report page 3/3 Exact description (please give details of the problem, system messages and what you have already done in an attempt to rectify the problem): ............................................................................................................Check-list: Have you been able to confirm that your ISDN access is working properly? ! ! ! ! yes ! ! ! ! no How (e.g.

  • Page 96: Overview Of The Available Isdn Adapters From Sedlbauer Ag

    (text, pictures, programs) on the ISDN Network. speed win PCI The speed win PCI is an internal PC card for PCI bus, with “plug & play” capability. The adapter allows you to transmit any data (text, pictures, programs) on the ISDN Network.
  • Page 97 Communication Systems Division © 2000 Sedlbauer AG W.-Sedlbauer-Str. 2 " " " " D-94481 Grafenau Article no.: 509735 Phone: +49-8552-41-187 " " " " Fax: +49-8552-41-280...
