- Page 1 VERTEX Water Products EasyPur Water Machine ™ REVERSE OSMOSIS UNDERSINK WATER FILTRATION SYSTEM OWNERS MANUAL EZ-575 VERTEX WATER PRODUCTS...
-
Page 2: Table Of Contents
Table of Contents The VERTEX EasyPur Water Machine is made with quality components to Notice provide cleaner, safer drinking water. No chemicals are added or used in i i . Parts List this system. To preserve the filter capability, it is a must that the filter 1 . -
Page 3: Notice
i. NOTICE 1.0 INTRODUCTION The Vertex EasyPur Water Machine™ is a 5-stage water cleansing system. The This instruction manual was written to guide a professional plumber to make an principal cleansing of the water of its dissolved solids is by the Reverse Osmosis easy installation of the Vertex EasyPur Water Machine™. -
Page 4: Location Of Ro Unit
Figure 1 2.0 Installation 2.1 Location of RO Unit The RO unit may be located under the kitchen sink or in the basement. A cold water supply line must be close by. When locating the system under a sink make sure there is adequate room for the filter module assembly as well as the storage tank. -
Page 5: Connecting The Feed Water Supply
2.3 Connecting the feed water supply (Figure 3, 4) 2.4 Installation of drain connection (Figure 5) The feed water assembly consists of 1/2” brass slip joint adapter, a black washer, and Place the drain outlet saddle on the drain pipe. Allow proper space for the drilling a 1/4”... -
Page 6: Porcelain/Enamel Over Steel Or Cast Iron Sinks
2.8 Tubing Connections (Figure 8) The standard tubing connections on the EasyPur Water Machine™ are of Quick Connect 0-ring seal design and manufacture. Use the tubing and follow the instructions in Figure 8 [NOTE: This procedure is for the non to make the connections. -
Page 7: Tubing Connections
b. Feed Water Line Tubing Connections Find the black colored 1/4" drain line from the membrane. Remove from membrane hous- Connect the orange colored 1/4” inlet tubing to the ball valve, or saddle valve ing. Connect this tube to the 1/4" barbed fitting on the air-gap faucet. installed in step 2.3 above. -
Page 8: Recommended Filter Changes
4.0 Recommended Filter Changes 5.0 Filter Replacement Procedure Turn off the feed water at the feed water ball valve. Empty at least 2.0 gallons from This system contains a replacement treatment component, the reverse osmosis mem- the storage tank to take any back pressure off the system. Put a shallow pan under the RO system to catch any water that may spill during the operation. -
Page 9: Conditions Of Use
NSF/ANSI 58. Test results; Average Clean Water Production Rate = 28.4gpd (31lpd) at an efficiency rate percentage of Vertex Water Products sells its products through independent water dealers 14.2% efficiency. Efficiency rating is the percentage of influent water to the sys- tem that is available to the user as reverse osmosis treated water under oper- who re-sell the product to the end user. -
Page 10: Appendix A: Theory Of Operation
A.2 The Reverse Osmosis Membrane Appendix A: Theory Of Operation This is the heart of the machine, and the great protector. The membrane is a replica- tion of human or animal stomach tissue, which permits the water molecule to pass through, but holds the dissolved molecules back. - Page 11 VERTEX WATER PRODUCTS Montclair, California, USA M-EZ1 REV B • 8/08 Copyright 2008 VERTEX Industrials, Inc.
