- Page 1 ® ® VISION BEYOND SOUND VISION BEYOND SOUND ® INSTRUCTION MANUAL MSW1100 VERTICAL CD/MP3 SHELF SYSTEM WITH USB FLASH READER AND AM/FM DIGITAL PLL TUNER Photo is for reference only. Printed In China...
- Page 2 The lightning flash and arrow head within the triangle is a warning sign alerting you of "dangerous voltage" inside the product. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO DRIPPING OR SPLASHING LIQUIDS. DO NOT EXPOSE TO DRIPPING OR SPLASHING LIQUIDS! CAUTION: GROUNDING OR POLARIZATION.
-
Page 3: Warranty
Package Contents MSW1100 Music System 1 Remote Control 1 Desktop Music System Stand ® ® VISION BEYOND SOUND VISION BEYOND SOUND ® INSTRUCTION MANUAL MSW1100 VERTICAL CD/MP3 RADIO SHELF SYSTEM WITH USB FLASH READER AND AM/FM RADIO Product and Instruction Manual subject to change. Photo is for reference only. -
Page 4: Location Of Controls
Location Of Controls 01. CD Door (Motorized) 02. EQ (Equalizer) Button 03. Sleep Button 04. Timer Button 05. CD Program Button 06. CD Down/Back Button 07. CD Stop Button 08. CD/Clock/Radio Digital Multifunction Display 09. CD Play/Pause Button 10. CD Up/Next Button 11. -
Page 5: Remote Control
01. On/Off Button 02. Find/M/S Button 03. Timer Button 04. EQ Button 05. Sleep Button 06. Mem. (-) Button 07. Band Button 08. Intro Button 09. Function Button 10. Repeat Button Backup Batteries - Open the battery door at rear of unit. - Insert 2 pieces “AA”... -
Page 6: Quick Start
Quick Start 1. Connect the table stand. 2. Plug the AC cord into a wall socket and unwrap the FM antenna wire. 3. Press the On/Off button to switch “On” the unit. 4. Listen to the CD player. - Press the Function button repeatedly until “CD” is displayed. - Press the Open/Close button. - Page 7 5. How to listen to the radio. - Press Tuner/Band button to switch to Radio Mode. - Press Tuner/Band button to switch to “FM” radio band. - Press Tuner/Band button again to switch to “AM” radio band. - Press and release the Next button to tune radio frequency up. - Press and release the Back button to tune radio frequency down.
-
Page 8: Digital Clock Functions
Digital Clock Functions - This unit also has a built-in digital clock, which is displayed when the unit is in Standby Mode or when you press and hold the Program button for two seconds during the CD or Radio operation. - To set the correct time, follow the procedure below: P ress and hold the Program button for 3 seconds. -
Page 9: Automatic Power On/Off Timer Function
Automatic Power On/Off Timer Function This unit has a timer function that enables you to program the unit to automatically turn “On” or “Off” at preset times. This function can also serve as an alarm clock. How To Set Timer 01. -
Page 10: Electronic Volume Control
Electronic Volume Control - This unit uses an electronic volume control. - To increase or decrease the loudness of this unit, press the volume up Vol + or volume down Vol - keys. - Release the key when volume level is at the desired loudness. - Sometimes, especially during listening to the radio, you may notice a "click-click-click"... - Page 11 IMPORTANT: Improving Radio Reception For the FM band, fully extend the FM wire antenna at the rear of the unit. Try to change its position until a clear reception is received. For the AM band, rotate the unit until a desired signal is reached. Avoid placing the unit in direct sunlight and metal desks/surfaces.
- Page 12 Normal CD Operation - cont. Normal CD Operations - cont. - The CD player can be programmed to play up to 64 tracks (songs). - Always press the Stop button before programming. - Press the Program button once, the display will show the memory symbol to indicate that the set is now programmed into the CD player.
- Page 13 Finding (Searching) MP3 Songs By Song Name - During Stop or Play Modes, press the Find button once. - The “Find” symbol will flash in the display, and the letter “A” will be shown (See Example Below). - This is the “Search Alphabet”. - Press the Next or Back button to advance the Search Alphabet to select the desired letter.
- Page 14 Finding (Searching) MP3 Songs By Album - MP3 files (songs) can be organized into folders when you record them on to a CD-R disc each folder is called an "Album" and you can (for example) organize your albums on a disc so that each album contains songs by a particular artist, or alternatively, by a different genre or type.
- Page 15 This Means You Are In Album Mode Album Name (Which You Want To Open) CARROT... TOMATO... - To exit the Find Mode, press the Find button repeatedly until the “Find” symbol disappears from the LCD display. ALBUM VEGETABLES... Press and hold for 2 seconds. N E X T Press and release repeatedly to scroll through all the songs contained within the selected album.
- Page 16 USB Flash Drive MP3 Playback - This unit is equipped with a USB socket which can accept and play MP3 files stored on standard USB flash drives which are for memory storage. This unit is compatible with USB version 1.1 & 2.0. - To utilize this function, press the Function button repeatedly until the display shows “Card USB”, and then insert a USB Flash drive into the USB socket.
-
Page 17: Anti-Skip (Anti-Shock) Function
Repeat Playback Functions - During anytime of Playback Mode, press the Repeat button repeatedly to select from the following: Repeat To repeat current track. Repeat All To repeat all tracks from any type of media. Repeat Album To repeat all songs from currently selected album. Anti-Skip (Anti-Shock) Function - This unit has a built-in digital anti-skip function which prevents CD skipping when the unit is physically moved or subjected to vibrations for up to 100 seconds. -
Page 18: Specifications
Connecting An External Powered Subwoofer (Not Included) - This unit has a built-in subwoofer connection which can be connected to any standard powered subwoofer. - By connecting to a powered subwoofer, the low frequency (bass sound) can be strongly enhanced to provice a much richer and deeper sound to your music. - Page 19 System Setup Procedure Set-up of MSW1100 with desktop stand. Step 1: Place the stand under the main unit. Step 2: Slide the stand upward. (See Diagram Below) Desktop use with supplied pedestal stand Step 3: Stop when the arrows are aligned. (See Diagram) The stand is now locked to the main unit or speakers.
-
Page 20: Troubleshooting
Troubleshooting Problems Radio Noise or sound distorted on radio broadcasts FM ST indicator does not light Compact Disc Player CD will not play USB will not play General AC power doesn't work Remote is not working No Sound Possible reasons - Station not tuned properly for AM or FM. - Page 21 For customer service inquiries in Latin and South America, please email custserviceLA@auviworld.com. © 2006 Auvi Technologies, LLC. All Rights Reserved. Auvi Electronics N.A., LLC and Auvi Electronics L.A., LLC are separate subsidiaries of Auvi Technologies, LLC. All the mentioned trademarks or trade names are the property of their respective owners. Specifications of product features are subject to change without notice, which might alter the functionality described within this instruction manual.
