Cuppon CSD 150 User Manual

Automatic sliding
Hide thumbs

Advertisement

Quick Links

CSD 150
AUTOMATIC SLIDING
USER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the CSD 150 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cuppon CSD 150

  • Page 1 CSD 150 AUTOMATIC SLIDING USER’S MANUAL...

  • Page 2: Table Of Contents

    CSD 150 AUTOMATIC SLIDING TERMS OF THE WARRANTY TABLE OF CONTENTS Prior to starting assembly or installation, please read all assembly and installation instructions and watch carefully the assembly video delivered together with our product. Any faults during the assembly may cause damage tı the people or goods. This product has been produced in accordance with well-known technical standards and safety regulations.
  • Page 3 CSD 150 AUTOMATIC SLIDING PARTS SOCKET CONNECTIONS The parts and the equipment constituting the product WARNING: Materials used during assembly should be in have been shown in the below. accordance with applicable standards, and connections should be performed by an authorized personnel.
  • Page 4 CSD 150 AUTOMATIC SLIDING GENERAL CONNECTION DIAGRAM POSITION SWITCH TRANSMITTER RECEIVER PHOTOCELL PHOTOCELL INTERNAL RADAR PHOTOCELL RECEIVER TRANSMITTER ON /OFF SWITCH 5A FUSE OPEN-CLOSE CLOSE-OPEN NEUTRAL SWITCH CHECK CHECK EXTERNAL RADAR OPENING CLOSING SPEED SPEED...
  • Page 5 CSD 150 AUTOMATIC SLIDING OPERATING FUNCTIONS CONNECTIONS Photocell Receiver / Photocell Transmitter ELECTRIC TERMINAL DESCRIPTION Safety photocell is a system which detects an obstacle found between doors through MOTOR OUT MOTOR OUTPUT infrared signals for safety and control. ENCODER MOTOR ENCODER OUT In order to ensure an optimum operating efficiency, the Receiver and the transmitter should be level.

  • Page 6: Operating Functions

    CSD 150 AUTOMATIC SLIDING OPERATING FUNCTIONS OPERATING FUNCTIONS RADAR 1 (Internal Radar) RADAR 2 (External Radar) This is the radar for detecting any movement around the interior of the door mechanism. This is the radar for detecting movement around the exterior of the door mechanism.
  • Page 7 CSD 150 AUTOMATIC SLIDING OPERATING FUNCTIONS OPERATING FUNCTIONS CURTAIN PHOTOCELL MICROWAVE RADAR: Open / Close For safety purposes, this system triggers the door by detecting any obstacle found Door opening or door closing movements can be performed by Open/Close Inputs with between the doors and any movement which may be seen during passage on the door normally open button (no contact).

  • Page 8: Installation Settings

    CSD 150 AUTOMATIC SLIDING INSTALLATION SETTINGS DIP SWITCH SETTINGS PHOTOCELL PHOTOCELL TRANSMITTER TRANSMITTER POSITION SWITCH CLOSE-OPEN POSITION 1 CLOSE-OPEN POSITION 2 OPEN CLOSE 1- SAFETY PHOTOCELL OFF: Safety photocell closed ON : Safety photocell open 2-CLOSING TIME OFF: It waits 3sec after door opens, and then closes...

  • Page 9: Operating Functions

    CSD 150 PHOTOCELL AUTOMATIC SLIDING TRANSMITTER OPERATING FUNCTIONS External Equipment POSITION SWITCH SNRF Numbering Machine & RF Card Reader. SDA Touch Screen Switch. External equipment such as SELS El Sensor can be connected to the system with Open - Close input.
  • Page 10 CSD 150 AUTOMATIC SLIDING OPERATING FUNCTIONS OPERATING FUNCTIONS POSITION SWITCH DOOR CONTROL WITH RF With the position switch, different functions of the door can be chosen such as Installation, In order to control the door with remote control, Indefinite SN-12 plus receiver is positioning, Always open, Always close.

  • Page 11: Mechanical Installation

    CSD 150 AUTOMATIC SLIDING MECHANICAL INSTALLATION 1. Microprocessor Control Unit 9. Stopper Our product is designed in a manner operating with different hardware and peripheral 2. Safety Photocell (Receiver - Transmitter) 10. Side Covers devices. Prior to start with mechanical installation procedure, please read all assembly 3.
  • Page 12 CSD 150 AUTOMATIC SLIDING PROBLEM CAUSE REMEDY Socket on the microprocessor Please check the transformer Power led doesn’t turn on. coming from the transformers entrance on the microprocessor. may not be mounted. LEDS (INDICATORS) : By checking the sequential elec-...

  • Page 13: Safety Warning

    CSD 150 AUTOMATIC SLIDING TECHNICAL SPECIFICATIONS SAFETY WARNINGS Technical Specifications • The manufacturer reserves the right to make any changes which deemed beneficial or necessary. Operating Voltage 230 V AC±10% 50 Hz Motor Voltage 24 V DC • Electrical safety of your product can only be ensured if only it is connected to an earthing system accurately.
  • Page 14 NOTLAR NOTLAR...
