SHENZHEN FLYING INDUSTRY DEVELOPMENT W-01 Quick Start Manual

Wireless Infrared Motion Detector W-01(Model 0010019)

Package:

1 x Wireless infrared motion detector
1 x Bracket
1 x User manual

Feature:

Model: 0010019 (W-01)
Size: 100mm x 60mm x 40mm, antenna not included
Working distance: 100 m (Open field)
Detection distance: 10 m
Detection range: Fan-shaped angle 110°
Decode: Fixed code by Pins
Alarm time: 2 seconds
Battery: 6F22-9V battery (Included, useful life time 6-12 months).
Indication of low battery

Installation:

When installing it, choose the favorable locations according to the environment. The lens should face the designated surveillance locations.
The height of installation should be about 2 meters above the ground.
Using screws to fix the bracket on the wall and put the detector on the bracket, then adjust the detector to the suitable angle of 10~14° . (See Side
View)
Note A: Don't put the detector towards lighting, sunshine or the computer.
Note B: Don't put the detector in an environment of strong wind, steam, oil smoke or be exposed to high temperature.
Note C: Don't put any barriers in the detecting area.
Note D: Don't install 2 infrared movement detectors within a small space.

Usages:

Pull out the antenna of the movement detector.
Push down the power switch of the movement detector to position "ON". After 60 seconds delay, the movement detector will enter into the
automatic detection state.
Within the area of detection, the movement detector will be triggered by any movement, LED will turn on green light for 2 seconds, and the
movement detector will send alarming message to the main unit.
Indication of low battery: When the voltage of battery is less than 6V, LED will straightly turn on red light. At this time, you must immediately
change the battery.
Side View
Top View
o
10~14
2 M
o
110
Detecting area
10 M
0
