Telco Sensors Space Guard SG 14 User Manual

SG 14 - USER MANUAL
Space Guard Series
Photoelectric light curtains for automatic doors
Product Data
Electrical Data
SGT (Transmitter)
Supply voltage
Max. Voltage ripple
Reverse polarity protected
Max. current consumption
Max. output load
Short circuit protected
Inductive load protection
Environmental Data
Light immunity @ 5º incidence
Temperature, operation
Sealing class
Approvals
Available Models
Model
Transmitter SGT 14-xxx-0xx-A1-x-0x-xx
SGR 14-xxx-0xx-A1-x-08-xx
Receiver
SGR 14-xxx-0xx-A1-x-09-xx
Connection
Wiring Diagrams
4 3
5
1 2
5 pole M12 male connector
Black wire
Transmitter Model
connected to ( - )
SGT 14-xxx-0xx-A1-x-00-xx TX is not transmitting
SGT 14-xxx-0xx-A1-x-01-xx TX is not transmitting
SGT 14-xxx-0xx-A1-x-02-xx TX is transmitting
Transmitter SGT 14
Receiver SGR 14 with solid state
relay used as NPN output
Receiver SGR 14 with solid state relay output.
Installation & Adjustments
Installation and Adjustment
No initial set up or adjustments are required, due the automatic signal-tracking (AST) feature,
which automatically adjust each individual channel on the system.
Notice that the SG14 system must not be placed on moving doors.
Mount the transmitter (SGT) and receiver (SGR) facing each other and correctly
1 aligned. Telco recommends that the rails are placed at least 5mm from edges for
mechanical protection.
Wire the sensor according to the wiring diagram. Make sure the load does not
2
exceed 200 mA.
3 Check for correct wiring. Select blanking function if required.
4 Turn power on.
5 The status indicator (red LED) on the SGR will flash quickly when the AST is active.
Website: www.telcosensors.com
E-Mail: info@telcosensors.com
Made in Denmark
SGR (Receiver)
12 – 36 Vdc
15% (within supply range)
Yes
70 mA (RMS) 50 mA
- 200 mA
- Yes
- Yes
> 100.000 lux
-20 to + 65 ºC
IP67
Blanking Output
Output
Function Mode
- - -
Solid N.O.
State On / Off
Relay N.C.
1: Brown
2: White
3: Blue
4: Black
5: Black or Yellow/green
Black wire Black wire
not connected connected to ( + )
TX is transmitting TX is transmitting
TX is transmitting TX is not transmitting
TX is not transmitting TX is transmitting
Receiver SGR 14 with solid state relay
used as PNP output
!
This device is not to be used for Personnel Protection in Machine
Guarding Safety applications. This device does not include the self-
checking redundant circuitry necessary to allow its use in personnel
machine guarding stand-alone safety applications.
EN
When the power on indicators (green LEDs) are on, the system is operating.
6
If the Status indicator (red LED) is constant on the SGR cannot see the SGT.
7 Notice that the rails must not be moved after the power to the SGR is turned on.
Output Logic
Detection
Present
Absent
Sensing
Range
C profile:
1 – 10m
D profile:
1 – 7.5 m
Indicator LEDs
Indicators
Red LED:
Yellow LED:
Green LED:
Troubleshooting
Troubleshooting
Probable Reason
1. Symptom: Status indicator (Red LED) on SGR is constant on.
TX is not emitting
SGT is disabled
The lowest beam is blocked
2. Symptom: Output indicator (Yellow LED) is flashing
Severe electrical interference
Severe ambient light
Cross talk from another light curtain
SGR
Output Response Time
Output Response Time
Nº of channels
Response time (max)
For obstruction by objects
larger than 100 mm.
SGT Test Input
SGT Test Input
The transmitter can be externally disabled and enabled via the control wire (black wire) for test
purposes. To activate the test input, please refer to "Transmitter Model" table.
Make sure no object is present in the detection area when transmitter is disabled for test.
When the transmitter is disabled, the receiver will change its output.
The test input on SGT14 has to be activated a certain minimum time T
the output of SG14 will switch.
On activation of the SGT14 test input, the output of the receiver will switch within a certain
maximum time T
ON
When the test input of SGT14 is deactivated the output will be switched back within a certain
maximum time T
OFF
The time T is longer than T
r
Note: Refer to "SGT test input response time table" & graph.
SGR Dynamic Blanking Function
Dynamic Blanking Function
All channels can be blanked without switching the output by moving a non transparent object
between the SGR and SGT from top of the rails and down to the lowest channel in one
movement.
All channels will stay blanked as long as the lowest channel at the bottom of the rails is
obstructed. Make sure that the lowest channel is well obstructed when all the channels are
blanked.
Minimum speed of the blanking object
Maximum speed of the blanking object
There is no restriction on maximum speed when removing the object.
Note: Refer to "SGR blanking function response time" & graph.
Channel spacing
Minimum size of blanking object
Warning
Output mode
Dark operated
(N.O.)
Light operated
(N.C.)
Dark operated
(N.O.)
Light operated
(N.C.)
Check supply and cable to the SGT
Enable the SGT
Remove obstruction
Remove SGR and SGT supply cable from high
voltage cables
Change position of SGT and SGR
Change position of SGT and SGR
16 24 32
24 ms 24 ms 30 ms
.
.
in order to ensure a complete test cycle of minimum duration.
ON
V 1.6.CD Part Number: 0666220707
Telco A/S reserves the right to make changes without prior notice
tel
Output Output indicator
status (yellow led)
Closed On
Open Off
Open Off
Closed On
Status indicator
Output indicator
Power on indicator
Corrective Action
40 48 56
37 ms 43 ms 49 ms
in order to ensure that
r
0.05 m/s
1.6 m/s
46 mm
55 mm
April 2019 edition
