Summary of Contents for Profoto RMI3
- Page 1 Profoto RMI3 Integration Manual...
- Page 2 This document and its contents shall not be reproduced or transferred in any form without express prior permission. All rights reserved. © Profoto AB 2019 Specifications are subject to change without prior notice. www.profoto.com...
- Page 3 Thank you for choosing Profoto Thank you for giving us your confidence by investing in the Profoto RMI3. For more than five decades we have sought after the perfect light. What drives us is our conviction that we can offer even better tools for the most demanding photographers.
- Page 4 This equipment contains electrical and electronic components that could be harmful to the environment. Equipment may be returned to Profoto distributors free of charge for recycling according to WEEE. Follow local legal requirements for separate disposal of waste, for instance WEEE directive for electrical and electronic equipment on the European market, when the product ‘s life has ended!
-
Page 5: Table Of Contents
Interface Description ..................9 UART Serial Interface ..............9 Reset Interface ................9 RF Characteristics..................10 Important Integration Notes ..................10 Mechanical Integration ................10 Electrical Integration ..................12 Antenna Integration ...................12 Regulatory Information ..................13 Certification ....................13 Europe ..................13 United States and Canada.............13 Japan ...................15 www.profoto.com... -
Page 6: Introduction
(free line of sight in open space ) General Description The RMI3 module is powered by an 8-bit micro processor with a radio transceiver from Texas and features a complete feature set for wireless interaction with the Profoto Air range of professional studio equipment. -
Page 7: Hardware Description
Hardware Description Mechanical Characteristics Dimensions 46x 18 x 10 mm +/- 1mm [Length, Width, Height] Weight: approx 10g Product Image www.profoto.com... -
Page 8: Electrical Characteristics
Mechanical Drawing Electrical Characteristics PINOUT Function VCC (Transmit) Sync O.C. Test_0 Trig N.C. Sync COM TX Reset Test_2 Test_3 Test_1 RMTE COM RX +3V CPU www.profoto.com... -
Page 9: Recommended Operating Conditions
(a dongle from B&B Electronics is recommended) from 3.3V or use the Profoto Air USB dongle which mates with an RMI3 module and provides a USB interface to a computer. Serial characteristics: 38400. 8, N, 1 (no flow control) -
Page 10: Rf Characteristics
Only FHSS 2416.996 2421.994 2426.993 2429.992 2432.992 2435.991 2438.990 2441.990 Only FHSS 2446.988 2451.321 2453.987 2456.653 2459.652 2462.318 2465.317 2468.316 2471.316 2474.315 Reserved 2479.314 Note: Channel 4, 12 is only used for frequency hopping. Channel 22 is not currently used. www.profoto.com... -
Page 11: Important Integration Notes
Important Integration Notes Profoto’s RMI3 has been designed to allow for easy integration with a wide range of devices. There are some key factors you need to consider when integrating the module. Mechanical Integration The module needs at least 10 mm clearance in order to fit. This is the maximum height with consideration to the connector pins. -
Page 12: Electrical Integration
RMI3 uses an on board chip antenna. The use of any other antenna is not approved and will break the modular approval. All data are to be considered as nominal and Profoto reserves the right to make changes without further notice. www.profoto.com... -
Page 13: Regulatory Information
EN 301 489-17 V3.1.1 (or later). For RF, conduced test results can be inherited from the RMI3 test report to the end product using RMI3. Limited EN 300 328 V2.1.1 (or later) testing for radiated spurious emission is necessary and the test must be repeated with the end product using the RMI3 module. - Page 14 2.8 Label and compliance information IMPORTANT NOTE: The RMI3 module is labelled with its own FCC and IC ID. If the FCC and IC ID:s is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a physical label or eLabel referring to the enclosed module.
- Page 15 FCC ID and IC Certification Number cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC and Industry Canada authorization. www.profoto.com...
-
Page 16: Japan
Canada. IC RF Exposure limits The RMI3 device complies with the IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. For hand held operation, this device has been tested and meets IC RF exposure limits when the device is positioned a minimum of 1.0 cm from the body. - Page 17 Profoto AB Box 1264 SE-172 25 Sundbyberg SWEDEN Phone +46 8 447 53 00 info@profoto.com www.profoto.com...
