Johnson Outdoors Eureka! SPRK+ Camp Stove 2572201 Instruction Manual

FOR OUTDOOR USE ONLY.
ANS Z21.72 CSA 11.2-2016 Camp Stove
Instruction Manual
Read and comply with all instructions and warnings in this manual
before using this Product. Keep these instructions for future reference.
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper,
tent, car or home.
Model 2572201
Burner Head
Pan Supporter
Levelling Feet
Electrode
Windshield
Canister locking lever
Johnson Outdoors Gear,Inc.
625 Conklin Road,
Binghamton,NY13903
T:1.800.847.1460
WARNING
!
If you smell gas:
1. Do not attempt to light appliance.
2. Extinguish any open flame.
3. Disconnect from fuel supply.
4. Evacuate immediately.
5. Allow gas to dissipate 5 minutes before relighting the appliance.
Failure to follow these instructions could result in fire or explosion, which
could cause property damage, personal injury, or death.
FOR YOUR SAFETY
Do not store or use gasoline or other liquids with flammable vapor in the
vicinity of this or any other appliance.
DANGER
Failure to comply with the precautions and instructions provided with these stoves can result
in death, serious bodily injury and property loss or damage from hazards of fire, explosion,
burn, asphyxiation, and / or carbon monoxide poisoning. Only persons who can understand
and follow the instructions should use or service this stove.
If you need assistance or information such as an instruction manual or labels, contact you seller.
Drip Pan
• NEVER store butane near high heat, open flames, pilot lights, direct sunlight,
Canister Cover other ignition sources or where temperatures exceed 120 degrees F (49 C ).
• NEVER install or remove butane canister while outdoor stove is lighted,
near flame, pilot lights, other ignition sources or while outdoor stove is
hot to touch.
• During operation, this product can be a source of ignition. NEVER use the
stove in spaces that contain or may contain volatile or airborne combustibles,
or products such as gasoline, solvents, paint thinner, dust particles or unknown
chemicals. Minimum clearances from combustible materials: 1m / 3ft.
• Provide adequate clearances around air openings into the combustion chamber.
Control / Ignition Knob
• Butane canisters must be stored outdoors, in a well ventilanted space, out of the reach of children,
and must not be stored in a buliding, garage, or any other enclosed area.
High / low control knob
with piezo-ignition
WARNING: Provide ample ventilation when using this appliance. This appliance consumes
oxygen. To avoid endangering your life, do not use this appliance in unventilated structures.
Provide additional ventilation for any additional burning products or additional occupants.
Johnson Outdoors Gear,Inc.
Do not connect to a remote gas supply.
4180 Harvester Rd,
Burlington, ON L7L 0C1 Canada
T: +1.905.634.0023
• EXPLOSION - FIRE HAZARD
PRECAUTIONS FOR FUEL USE
This appliance is only intended for use with butane canisters that are
designed for vapor withdrawal only. This is done by lining up the notch
in the collar of the canister with the safety guide on the regulator. They
must fit together or the canister will not lock into place.
• The butane fuel canister shall comply with DOT 2P or 2Q requirements
and shall be listed to the Standard for Non-refillable (Disposable) Type
Metal Canister. Assemblies for Butane, UL 147B.
• Avoid any strong shock or impact to the fuel canister.
Keep canisters upright for storage.
Remove canister from stove before storing.
• Do not dispose of empty gas canister into fire, risk of explosion may occur.
• Use only butane set up for vapor withdrawal.
• Performance may be suboptimal if used in extreme conditions
(cold, hot, wind, altitude).
MAINTENANCE AND CAUTIONS
• Never leave the stove unattended when hot or when in use.
• Keep out of reach of children at all times.
• Keep the stove area clear and free of combustible materials, gasoline and other flammable
vapors and liquids.
• Do not obstruct the flow of ventilation or combustion air around the appliance.
• Keep your stove clean using a stiff brush to clean the burner head.
• Use a soft cloth to clean greasy parts of the stove with soap and
water.
• Keep the electrode and the burner gap free from debris for easy
lighting.
• Clean stove frequently to avoid grease build up and as necessary.
• Burner flame should be blue with hint of yellow tip.
BUTANE INFORMATION AND STORAGE
Only gas canisters marked with the fuel type approves for the appliance must be used.
In a home or residence, the canister must be removed from the stove and the canister must be
stored outdoors in a well ventilated area, out of the reach of children. They shall not be stored in
a building, garage or any other enclosed area.
The stove may be stored indoors but only if the canister is removed.
When the stove is not in use or in storage, always remove the fuel canister.
Safety guide
Notch
GOOD BAD
Blue
Yellow
Blue
Yellow
Holes in Burner
