SysMaster A60H-080M0-027 Quick Start Manual

LED Motion Sensor Bulb
Art.no 36-6884, 36-6905
Model A60H-080M0-027, A60I-047M0-027
Please read the entire instruction manual before use and
then save it for future reference. We reserve the right for any
errors in text or images and any necessary changes made
to technical data. In the event of technical problems or other
queries, please contact our Customer Services.

Self-test

The motion sensor in the LED light bulb performs a self-
diagnostic test every time it is switched on using the light
switch. Here's how it works:
Screw the light bulb into the desired light fitting and switch the light
fitting on using the light switch. The light bulb will come on for about
3 seconds and then go off. Every time motion is detected within
10 seconds, the light bulb comes on for about 2 seconds and then
goes off. This means that the motion detector is operating normally.
After 10 seconds has elapsed, the light bulb will come on and shine
for 60 seconds when motion is detected.
The idea is that the light switch controlling the light fitting with
the light bulb in should always be switched on. The light bulb
will then come on and go off automatically following an initial
self-test.
Note: If multiple motion sensor light bulbs are located in
the same room they should be spaced at least 1.5 m apart so
as not to conflict with one another.
GREAT BRITAIN • customer service tel: 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk postal 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ

Detection range

When mounted on a ceiling
3–4 m
When mounted on a wall
4 m
Standing upright e.g. on a window sill
4 m

Responsible disposal

This symbol indicates that this product should not
be disposed of with general household waste.
This applies throughout the entire EU. In order
to prevent any harm to the environment or
health hazards caused by incorrect waste
disposal, the product must be handed in for
recycling so that the material can be disposed
of in a responsible manner. When recycling
the product, take it to your local collection facility
or contact the place of purchase. They will
ensure that the product is disposed of in
an environmentally sound manner.

Specifications

Base E27
Colour temperature 2700 K
Luminous flux 36-6884: 806 lm, 36-6905: 470 lm
Power 36-6884: 10 W, 36-6905: 6.5 W
Colour rendering
index (CRI) 80
Height 110 mm
Diameter 60 mm
Operating temperature −20 to 40 °C
