1. Color Camera
1. Color Camera
2. Camera mounting Bracket
2. Camera mounting Bracket
3. Bracket mounting screws
3. Bracket mounting screws
and nuts
and nuts
Audio From Camera
Video From Camera
DC 12V
Ground/Shield
BLACK
Power In
YELLOW
Vidio Out
WHITE
Audio Out
Cable Connector End View
Installation Instructions
Model ROSEC
Color Camera External Mount
ROSEC FEATURES:
High Resolution, 1/3 CCD Color Camera
Compact ZINC Alloy Die Cast Body
Waterproof Housing
Waterproof microphone
Adjustable Mounting Angle
Wide Angle Lens
Microphone
Connector
Optional Universal Cable Required
1
"
Cable
