- Page 1 CEILING FAN INSTALLATION AND OPERATION INSTRUCTION READ AND SAVE THESE INSTRUCTIONS FAN RATING AC 120V. 60Hz SKU# 1100668...
-
Page 2: Safety Rules
1. SAFETY RULES 1. To reduce the risk of electric shock, insure 8. Avoid placing objects in the path of the electricity has been turned off at the circuit blades. breaker or fuse box before beginning. 9. To avoid personal injury or damage to the 2. -
Page 3: Tools And Materials Required
2. TOOLS AND MATERIALS REQUIRED ● Philips screw driver ● Blade screw driver ● Adjustable wrench ● Step ladder ● Electrical tape & wire cutters 3. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items; Blade set (5) Hanger bracket and canopy assembly Ball/downrod assembly... -
Page 4: Installing Your Fan
4. INSTALLING YOUR FAN Mounting Options If there isn't an existing CUL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or Outlet box turning off circuit breakers. Secure the outlet box directly to the building structure. -
Page 5: Hanging The Fan
5. HANGING THE FAN REMEMBER to turn off the power. Follow Hanger bracket the steps below to hang your fan properly. Step 1. Remove the decorative canopy bottom cover from the canopy by turning the Canopy cover counter clockwise. (Fig. 5) Step 2. -
Page 6: Make The Electric Connections
INSTALLATION OF SAFETY SUPPORT An additional safety support is provided to prevent the fan from falling. Secure the safety cable to the ceiling joist with screw and Safety cable Hanger bracket washer, as illustrated in Figure 9. Figure 9 6. MAKE THE ELECTRIC CONNECTIONS SUPPLY CIRCUIT Remember to disconnect the power. -
Page 7: Finishing The Installation
7. FINISHING THE INSTALLATION Step 1. Tuck connections neatly into ceiling Outlet Box outlet box. Hanger bracket Step 2. Slide the canopy up to hanger Screw bracket and place the key hole on the canopy over the screw on the hanger bracket, turn Canopy canopy until it locks in place at the narrow section of the key holes. -
Page 8: Installing The Switch Housing
The following procedure should correct most fan wobbling problems. Check after each step. Touching 1. Check that all blade and blade arm screws ceiling are secure. 2. Most fan wobbling problems are caused when blade levels are unequal. Check this level by selecting a point on the ceiling above the tip of one of the blades. -
Page 9: Operating Your Fan
10. OPERATING YOUR FAN NOTE WAIT FOR FAN TO STOP BEFORE CHANGING THE SETTING OF THE SLIDE SWITCH. Turn on the power and check the operation of your fan. The pull chain controls the fan speed as follows: 1-Pull = High Speed Figure 15 2-Pulls = Medium Speed 3-Pulls = Low Speed... -
Page 10: Care Of Your Fan
11. CARE OF YOUR FAN Here are some suggestions to help you maintain your fan 1. Because of the fan's natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. - Page 11 BOSTON HARBOR FANS & LIGHTING WARRANTY Boston Harbor Fans warrants this fan to be free from defects in workmanship and material present at time of shipment from the factory for 30 years from the date of purchase. This warranty applies only to the original purchaser. Boston Harbor agrees to correct such defect at no charge or at our option replace the ceiling fan with a comparable or superior model.
