Digital & Analog Audio Extractor
with 18Gbps HDMI Passthrough
EXP-CON-AUD-H2
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the
installation process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest documentation.
• Read through the
Wiring and Connections
guidelines before creating or choosing premade cables.
Basic Wiring Diagram
Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-CON-AUD-H2 Quickstart Guide | 200317
section for important wiring
5V DC
Power Supply
HDMI Source
In the Box
1x EXP-CON-AUD-H2 Audio Converter
1x 5V DC 1A Power Supply with Wall Adapters
2x Mounting Brackets
4K/UHD HDMI Display
1 of 4
Quickstart Guide
Key
HDMI
Digital Audio
Analog Audio
Multiroom Amplifier
AVR
