Twiflex GMR-H Quick Start Manual

GMR-H and GMR40-H Disc Brake Caliper - Hydraulically Applied, Spring Released
Nominal dimensions given.
For specific dimensions please
contact Twiflex.
For GMR Mk 2 caliper details
see DB3604.
Disc Diameter mm
140
120
100
80
60
40
20
0
0 2
Maximum Braking Force = 36kN @ 140 bar.
The ratings shown on the above graph are based on fully bedded and conditioned brake pads. For bedding in
and conditioning procedures see Publication M1060.
Braking Force is defined as the Tangential Force acting on the brake disc at the Effective Disc Radius.
Braking Torque (Nm) = Braking Force (N) x Effective Disc Radius (m)
where Effective Disc Radius = Actual Disc Radius- 0.06
Brake Disc
25.4 (GMR)
38/40 (GMR40)
45
Disc Center Line
40
87 170 Mounting Hole CRS
610 760 915
4 6 8 10 12 14
Braking Torque kNm
193
Note:
The caliper may be assembled
as drawn (right hand assembly)
or with arms and thruster
To Edge of Disc
oppositely handed.
17
1065 1220 1370 1525
Maximum Pressure 175 bar
16 18 20 22 24 26
1830
28 30 32
DB3605
Brake Disc
25.4 (GMR)
38/40 (GMR40
