- Page 1 Self-Regulating Heating Cables For Pipes and Roof De-Icing Owner’s Manual PLEASE READ AND SAVE THESE INSTRUCTIONS...
-
Page 2: Specifications
DR-9RC 120V / DR-9RC 240V Operating Instructions & Parts Manual Please read and save these instructions. Read carefully before installation, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instructions for future reference. - Page 3 Self-Regulating Heating Cables for Pipes CHOOSING A CABLE – Make sure to choose a cable longer than the pipe ensure coverage. NOTE: For each valve or spigot on pipe an additional foot of cable is needed. When the cable is longer than the pipe, spiral the excess cable around the pipe length evenly.
- Page 4 Roof Clips Shingle Roof Metal Roof Roof Clips Roof Clips Hanger Bracket Hanger Bracket DR-006 (*sold separately) Self-Regulating Heating Cables for Roofs, Gutters and Downspouts Estimate the Cable Length You Need • If you only need to install the cable in the gutters only, follow An accurate estimate of the cable length you need is important “B.
- Page 5 Figure 5 – Roof Measurement Step 2. Use the estimated cable length calculated above to select the proper de-icing cable from Table 3. In general, choose the longer cable if the length you need is between the sizes offered. If the difference is small (less than 5 feet or so), the shorter cable can be used.
- Page 6 Figure 6 – Roof Measurement D. EXAMPLE #1 – EXAMPLE OF TYPICAL ESTIMATION Consider a roof section (See Figure 4) that you want to treat that has: • 32 feet of roof • an overhang of 12 inches with a gutter •...
-
Page 7: Installing The Cable
Installing the Cable Planning the Cable Arrangement Before laying out and attaching the cable to your roof, it is important to plan how the cable will be arranged. To prevent ice dams, the cable pattern must be arranged so that it routes meltwater to flow from “warm areas” of the roof through the “cold areas”... - Page 8 Installing the Cable (Continues…) Gutter and Downspouts Only Routing Pattern : If your icing problems are only in the gutter, cable would be routed only in the gutter and downspouts using the recommended “double run” of cable, as shown in Figure 9. This figure shows an alternate “single end of run”.
-
Page 9: Warranty Information
