Arena Luci LS1532­-WW User Manual

This strip should only be used for purpose for
which it has been intended and should be
installed using the instructions which are
provided. Arena Luci cannot be held liable for
damages to person, animals or objects as a
result of improper, unreasonable and wrong
usage.
This instruction manual contains important
information about the installation and use of the
projector. Please read and follow these
instructions carefully.
The security of this device is guaranteed only
with the proper use of the following instructions,
therefore they must be kept carefully.
Never install the strip in locations easily
accessible by people who ignore the existence of
this user's manual and safety instructions.
For the wiring please refer to enclosed wiring
diagrams. If in the diagrams indicated there
should not be that of your application, contact the
technical office.
Disconnect the strip from any power supply
before attempting any operation in contact or
inside the device, and when not in use.
It is essential that electrical installation conforms
to all relevant standards.
Prior to connect the strip to the power supply,
check the output voltage fits the technical
requirements on the label.
Never let the power cord come into contact with
other cables.
Never touch the electrical contacts, either directly
with your fingers, or indirectly by means of sharp
or metal objects.
Make sure that cables cannot cause trip hazard.
Please note that as part of Arena Luci's ongoing commitment to continuous product development,
specifications are subject to change in the course of product improvement without notice. Arena Luci is not
responsible for damages resulting from improper or different use than expected.
High Brightness
LED strip
User's manual

WARNINGS

Do not attempt to dismantle and modify the strip.
Due to the high technological level of this strip,
any service maintenance should be performed by
specialised operators. Please contact your Arena
Luci dealer for any operation.
Both the LED strip and the inside electronic
components should not be subjected to any
mechanical stress.
The mounting of the LED strip must not damage
or destroy the conducting paths made on the
PCB.
During the installation of the LED strip take all the
precautions to avoid damaging the electronic
components
electrostatic discharge.
Always install the LED strip on a heatsink.
Do not allow contact with water or any other
fluids, or metallic objects (IP 20).
Do not install the projector in areas of high
humidity. The unit is intended only for indoor
purposes.
Avoid installing the unit close to heat sources.
Allowed to be mounted directly on inflammable
surfaces.
Do not use any solvent based cleaning agents.
Use only a soft, dry anti­static cloth.
The installation of LED modules (including power
supplies) should be done according to current
technical rules and regulations. The installation
should be performed only by a qualified operator.
Avoid contact with either corrosive agents or
humidity and moisture on delicate elements:
damages from corrosion are not refunded as
component defects.
IP20 ­ 12V ­ 15W/m
LS1532­WW
LS1532­W
due to the occurrence of
