Thank you for purchasing this quality product from A.R.T. Furniture. Be sure to check all packing mate-
rial for parts which may have come loose inside the carton during shipment. Identify and count all parts
and compare with the parts list below.
Note: Some furniture is heavy, it is recommended that two people assembly this item to avoid injury or
damage.
No.
Hardware List
A
B
C
D
Page1
Bolt cover
5/16
5/16"
Wrench
1/2"
Bolt
5/16"X0.787"
Flat washer
5/16"
! KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE !
ASSEMBLY INSTRUCTIONS
Qt.
NO
4
1
1
2
4
3
4
4
HAMPDEN FIREPIT
923460-4114
PARTS LIST
DESCRIPTION
PIECES
TABLE TOP
TABLE BASE
Lid
Fire Glass
1
1
1
1
07/29/2017
