Summary of Contents for Prothelis meintal

  • Page 1 Manual Prothelis AG June 4, 2021...
  • Page 2: Table Of Contents

    CONTENTS Contents 1 Important Note 2 Package contents 3 Activating meintal 4 Installing the app 5 Using your tracker 6 SAFETY INFORMATION 7 Declaration of conformity 8 Warranty 9 Technical Specifications...
  • Page 3: Important Note

    Important Note PROTHELIS SAYS THANK YOU! We are delighted that you have chosen to purchase a meintal tracker from Prothelis and thank you for the confidence you have shown in us. 1 Important Note Although the typical activation time of the embedded SIM card is about 10 min­...
  • Page 4: Package Contents

    1. Go to https://my­prothelis.de/activate and create a user account. 2. Register your tracker and choose a service package for the desired period. 3. Connect meintal to an appropriate power supply using the included USB cable and insert the plug into a 100­240V socket.
  • Page 5: Installing The App

    Installing the app 4 Installing the app Download the free Prothelis app from the App Store or Play Store and simply scan in the QR code. Sign in to your account. The tracker is now ready for use. App Store (iOS)
  • Page 6 5.2 Interacting with your tracker meintal has a push button which you can use to give a command. Each com­ mand is confirmed by the LED. Below you can find a list of commands which are supported by the device: 5.2.1 Switching on or off...
  • Page 7: Safety Information

    We will be happy to help you. Any use of the tracker and its accessories other than for the intended use is prohibited. Any claims for dam­ ages against Prothelis GmbH that are caused by use other than for the intended use are excluded. All the specifications and information have been compiled taking the current state of technology and engineering development standards into account.
  • Page 8 6.2 First steps 6.2 First steps Remove all the elements from the packaging and check that everything is present. All products are subject to a restrictive quality control. Nevertheless, please check that the elements (in particular the cable) are intact. Sources of danger are, for example, cracks in the cable insulation.
  • Page 9 6.5 Damage • Always ensure that the tracker is attached to the object being tracked in such a way that it is not exposed to any excessive heat. (Tracker is at­ tached under a vehicle’s bonnet). • The tracker and accessories must not be attached and stored in or near heating and gas equipment or similar.
  • Page 10: Declaration Of Conformity

    Never try to remove the battery from the device! 7 Declaration of conformity Prothelis AG hereby declares that the GPS tracking device meintal (article no. 0903480­02) complies with the essential requirements and other relevant provi­ sions of Directive 2014/53/EU. The complete text of the Declaration of conformity can be downloaded from the following website: https://prothelis.de/conformity...
  • Page 11 9.2 Connection 9.2 Connection • GPRS 9.3 Protection Class • IP 67 9.4 GNSS Receiver • GPS + GLONASS • Accuracy: <2.5 m (CEP) 9.5 GSM Module • GSM 900 33dBm (2W) • GSM 1800 30dBm (1W) 9.6 SIM Card •...
  • Page 12 9.8 Accumulator 9.8 Accumulator • 5000 mAh LiPo accu • Chargeable via USB • Lasts up to 5 days during active usage 9.9 Temperature • Charge: 0 °C to +45 °C • Usage: Use in ambient temperatures from ­20 °C to +60 °C 9.10 Button •...
