Limited Warranty
Audiovox Corporation (Audiovox) warrants this product against defects in
materials or workmanship for one (1) year from the date of purchase.
During this period, this product will be replaced without charge. This
warranty does not cover any damage due to acts of nature, commercial
use, accident, misuse, abuse or negligence. This warranty is only valid in
the USA. Replacement as provided under this warranty is the exclusive
remedy of the consumer. Audiovox shall not be liable for any incidental
or consequential damages for breach of any express or implied warranty
on this product, except to the extent that limitations of this sort are
prohibited by applicable law. THERE ARE NO IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURCHASE EXCEPT
TO THE EXTENT THAT IMPLIED WARRANTIES OR EITHER SORT ARE
REQUIRED BY APPLICABLE LAW, AND IN SUCH CASE, EACH WARRANTY
IS LIMITED IN DURATION TO THE ONE YEAR.
For Customer Service
Visit Our Website At
For customer service and
www.audiovox.com
Product Information, Photos,
technical information:: 1.800.290.6650
FAQ's, Owner's Manuals
TERK and the TERK logo are registered trademarks of AUDIOVOX Corp.
44P008A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Audiovox HDTVo
Summary of Contents for Audiovox HDTVo
-
Page 1: Limited Warranty
This warranty is only valid in the USA. Replacement as provided under this warranty is the exclusive remedy of the consumer. Audiovox shall not be liable for any incidental or consequential damages for breach of any express or implied warranty on this product, except to the extent that limitations of this sort are prohibited by applicable law. - Page 2 HDTVo Owner’s Manual Indoor/Outdoor Amplified HDTV Antenna...
-
Page 3: Safety Precautions
Use extreme caution when installing or removing an outdoor antenna that is located close to overhead wires such as power lines, telephone lines or cable TV lines. If any part of the antenna makes contact with overhead power lines, touching the antenna or the antenna cable can cause electrocution and death. - Page 4 Please read and follow these important safety precautions: • Be sure to select an antenna site well away from all overhead wires. • Do not try to guess which overhead wires carry high voltage. Check with the Power Company. • If you notice anything making contact with the overhead wires, call the Power Company to have it removed safely.
- Page 5 About Your New TERK HDTVo Antenna Your TERK HDTVo antenna is designed for both single and multifamily homes. It’s specifically engineered to provide superior reception of high-definition (HDTV), digital television (DTV) and VHF/UHF TV channels in most viewing locations. The HDTVo’s...
- Page 6 Fig 1.
- Page 7 Positioning the HDTVo The HDTVo MUST be mounted horizontally (See Fig 2.) with the front of the HDTVo precisely facing the direction of the TV station’s broadcasting transmitters. (See Fig 2.) The higher the elevation of the antenna, the better the reception performance will be.
- Page 8 Right On the side of the house facing the broadcast tower Fig 2. Wrong Not on the side of the house facing the broadcast tower...
- Page 9 (such as on the roof or high up on the side of your house). The HDTVo can also be mounted in an attic. Remember that the HDTVo is a highly directional antenna. As a result, it needs to be mounted with the front of the HDTVo precisely facing the direction of the TV station’s broadcasting transmitter.
- Page 10 (see “Positioning the HDTVo”). 7. Tighten the 3” partially threaded bolt and the 3/8” screw, securing the antenna in the antenna bracket. 8. Skip to the “Connecting the HDTVo to a TV” section to complete installation.
- Page 11 To mount the HDTVo on a roof with 45-90 degree pitch (see fig. 3C): 1. Locate the HDTVo antenna and all included components. 2. Using the four lag screws, attach the mini-mast bracket to the roof. Be sure to position the bracket vertically on the roof.
- Page 12 To mount the HDTVo on a roof with 0-45 degree pitch (see fig. 4): 1. Locate the HDTVo antenna and all included components. 2. Using the four lag screws, attach the mini-mast bracket to the roof. Be sure to position the bracket vertically on the roof.
- Page 13 To mount the HDTVo on a rafter located in an attic where the roof that has 45-90 degree pitch (see fig. 5): 1. Locate the HDTVo antenna and all included components. 2. Using the four lag screws, attach the mini-mast bracket to the rafter.
- Page 14 To mount the HDTVo on a rafter located in an attic where the roof has 0-45 degree pitch (see fig. 6): 1. Locate the HDTVo antenna and all included components. 2. Using the four lag screws, attach the mini-mast bracket to the rafter.
- Page 15 (see “Positioning the HDTVo”). 6. Tighten the 3” partially threaded bolt and the 3/8” screw, securing the antenna in the antenna bracket. 7. Skip to the “Connecting the HDTVo to a TV” section to complete installation.
- Page 16 Connecting the HDTVo to a TV 1. Run the RG6 coaxial cable from the antenna towards your television set and connect the RG6 coaxial cable to the supplied Power Injector on the terminal labeled “TO ANTENNA”. 2. Connect the “TO TV” lead on the power injector to the “ANT IN”...
- Page 17 Avoiding Water Damage Water Damage Prevention: At the point where your coaxial cable lead enters the house, you should allow for some slack in the coaxial cable as a “drip loop.” This will prevent moisture from running down the coaxial cable and entering the house.
- Page 18 Satellite Dish HDTVo Installation Procedure for use with a Satellite Dish If you have a satellite dish it is possible to install the HDTVo using the same wiring as the satellite dish. To do this you will need to purchase a set of diplexers (Terk model BDS-P1).
-
Page 19: Troubleshooting
Power Injector turned off. I am not receiving all channels. Reposition the HDTVo to a different location, such as the other side of the house or to a higher location. Obstructions such as other houses or buildings, large trees, mountains and water towers can cause poor reception. - Page 20 Need more help? Call 1-800-290-6650 for Technical Support Monday through Friday 9:00AM to 5:00PM EST, or contact us at www.audiovox.com. If your TV has a connection not mentioned in this manual, contact Terk for the appropriate adapter.
