BEDIENUNGS- UND
MONTAGEANWEISUNG
GB INSTRUCTIONS FOR ASSEMBLY AND USE
F MANUEL D'UTILISATION ET DE MONTAGE
NL GEBRUIKS- EN MONTAGEAANWIJZING
E
INSTRUCCIONES DE EMPLEO Y DE MONTAJE
EWK 1220-0-2Z

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EWK 1220-0-2Z and is the answer not in the manual?

Questions and answers

Summary of Contents for Kuppersbusch EWK 1220-0-2Z

  • Page 1 BEDIENUNGS- UND MONTAGEANWEISUNG GB INSTRUCTIONS FOR ASSEMBLY AND USE F MANUEL D’UTILISATION ET DE MONTAGE NL GEBRUIKS- EN MONTAGEAANWIJZING INSTRUCCIONES DE EMPLEO Y DE MONTAJE EWK 1220-0-2Z...
  • Page 2: Table Of Contents

    Contents General Contents Your appliance data Safety Instructions Installation and Operating Electrical connection Features Installation Reversing the door swing Operating Humidity maintenance system Loading Maintenance, Cleaning and Care Maintenance In case of breakdown Environment...
  • Page 3: Your Appliance Data

    Please note: We require the following details for your request for customer service so that our customer service technicians can be well-prepared to carry out repairs and have the required spare parts available: 1. Your exact address 2. Your telephone number and, if available, fax number 3.
  • Page 4: Safety Instructions

    IMPORTANT SAFEGUARDS When using an electrical appliance, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: For your safety, read all instructions carefully, even if you are quite familiar with the appliance. Use this appliance only as described in this manual.
  • Page 5: Electrical Connection

    Do not connect or disconnect the electric plug when your hands are wet. It is recommended that a separate circuit, serving only your appliance be provided. Use receptacles that cannot be turned off by a switch or pull chain. This appliance must not be used by person with affected mental capacities (including children), lack of experience or knowledge, excepting under the supervision of an experimented and responsible person.
  • Page 6: Features

    FEATURES OF YOUR WINE COOLER Door Handle Digital control panel Shelves Condensor Cabinet Leveling legs Shelf Shelf INSTALLATION INSTRUCTIONS Before Using Your Wine Cooler Remove all exterior and interior packing. Before connecting the Wine Cooler to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system caused by handling during transportation.
  • Page 7 To prevent the appliance from heating up, ensure that an adequate ventilation gap is retained and install a suitable thermal insulation panel. An adequate flow of air to and from the cooling system must be ensured. The appliance must be installed to all electrical, plumbing, water and drain connections in accordance with state and local codes.
  • Page 8 Attention Store wine in sealed bottles. Do not overload the cabinet. Do not open the door unless necessary. Do not cover shelves with aluminum foil or any other shelf material which may prevent air circulation. Should the wine cooler be left empty for long periods it is suggested that the appliance is unplugged, and after careful cleaning, leave the door ajar to allow air to circulate inside the cabinet in order to avoid possible condensation, mold or odors forming.
  • Page 9: Reversing The Door Swing

    REVERSING THE DOOR SWING OF YOUR APPLIANCE Should you desire to reverse the opening direction, please follow the instructions below. ① Screw ② Decoration Plug ③Top Hinge Pin ④ Right Top Hinge Plate ⑤ Glass Door ⑥ Left Top Hinge Plate ⑦...
  • Page 10: Operating

    OPERATING The Wine Cooler should be placed in a position where the ambient temperature is between 16-32°C/60~95ºF. If the ambient temperature is above or below this range, the performance of the unit may be affected. For example, placing your unit in extreme cold or hot conditions may cause interior temperatures to fluctuate. The range of 5- 18°C/40-72ºF may not be reached.
  • Page 11 SETTING THE TEMPERATURE CONTROL The wine cooler has two temperature zones. The temperature settings of LOWER ZONE and UPPER ZONE are adjustable with the range 5º-22ºC/40º-72ºF. It is recommended to set the LOWER ZONE to 13-22ºC / 55-72ºF which is ideal for storing white and red wines and the UPPER ZONE to 5-13ºC / 40-55ºF which is ideal for storing sparkling and white wines.
  • Page 12: Humidity Maintenance System

    TEMPERATURE DISPLAY During normal operation, the temperature display on the control panel shows the temperature inside the appliance. The temperature display will flash if: - A different temperature is being set, - The temperature in the zone deviates by more than 5°C from the set temperature. The temperature display flashing ensures that the temperature can not rise or fall un-noticed and impair the wine.
  • Page 13: Loading

    LOADING The maximum amount of bottles able to be stored which is given, is only given as an indication , done in factory and is not contractual. This indication (as with the capacity in liters of a refrigerator) is to give a quick estimation of the size of the product.
  • Page 14: In Case Of Breakdown

    WHAT TO DO IN CASE OF A POWER OUTAGE Most power outages are resolved in a short time. An outage of 1 or 2 hours will not affect the temperatures in your cabinet. In order to protect the wines during the outage, open the door as little as possible. For outages that are very long, take necessary steps to protect the wine.
  • Page 15: Environment

    PROBLEMS WITH YOUR WINE COOLER You can solve many common Wine Cooler problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling customer service. TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE Not plugged in.
  • Page 16 Küppersbusch Hausgeräte GmbH Postfach 10 01 32, D-45801 Gelsenkirchen, Küppersbuschstr. 16, D-45883 Gelsenkirchen Telefon: (02 09) 4 01-0, Telefax: (02 09) 4 01-3 03 www.kueppersbusch.de Küppersbusch Ges. m. b. H. Eitnergasse 13, 1230 Wien, Telefon: 01 / 8 66 80-0, Telefax: 01 / 8 66 80 72...
