USER'S MANUAL

Series MPCIB396 P6

(Bidirectional counter)

ME3025_13

03/21

Need help?

Do you have a question about the MPCIB396 P6 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Mect MPCIB396 P6 Series

Page 1 USER’S MANUAL Series MPCIB396 P6 (Bidirectional counter) ME3025_13 03/21...
Page 3 MPCIB 396 P6 mect s.r.l. INDEX INDEX ........................... 3 1.0 OVERVIEW ....................5 1.1 TECHNICAL FEATURES .................. 5 1.2 DISPLAY MESSAGES ..................6 1.3 WIRING DIAGRAMS ..................6 1.4 WIRING SCHEMATICS .................. 7 1.5 NPN or PNP INPUTS CONFIGURATION ............. 8 1.6 PROGRAMMING TIPS ...................
Page 4 MPCIB 396 P6 mect s.r.l. 5.8 BASIC PROGRAM.................... 39 6.0 PASSWORD FUNCTION ................40 7.0 SET UP......................41 8.0 NOTES ......................41 ME3025_13 03/21...
Page 5 MPCIB 396 P6 mect s.r.l. 1.0 OVERVIEW The MPCIB396 P6 model is an instrument which counts, places or measures by a bi- directional encoder. Main characteristics are:  count memory at the switching off (you can exclude this function from the menu).
Page 6 MPCIB 396 P6 mect s.r.l. 1.2 DISPLAY MESSAGES Table 2 r.01.00 software version ErP 4 item IS = FS ErP 6 item dEnon = 0 ErP 7 If windows alarm SP2 < SP1 ErP 8 If windows alarm HY > (SP1-SP2)
Page 7 MPCIB 396 P6 mect s.r.l. BASIC TERMINAL BOARD DESCRIPTION Terminals 1-2-3 - exchange relay output (AL3: 1 = Com, 2 = NC, 3 = NO) Terminals 4-5-6 - exchange relay output (AL2: 4 = Com, 5 = NC, 6 = NO)
Page 8 MPCIB 396 P6 mect s.r.l. NPN connection PNP connection 1.5 NPN or PNP INPUTS CONFIGURATION The “hold” and “reset” inputs can be used with “npn” or “pnp” polarity.  “npn” input: short-circuit JP7 and program the menu item “nInP”=nPn  “pnp” input: short-circuit JP14 and program the menu item “nInP”=PnP The instruments are delivered with NPN inputs.
Page 9 MPCIB 396 P6 mect s.r.l. 1.6 PROGRAMMING TIPS  Press key to get into the programming menu.  Press key to search the item to program and the as indicated in diagram menu  If the set up needs a number to write, use the...
Page 10 MPCIB 396 P6 mect s.r.l. 1.7 BASE INSTRUMENT MENU DIAGRAM Notes: symbol means: symbol means: ME3025_13 03/21...
Page 11 MPCIB 396 P6 mect s.r.l. 1.8 OPTIONS MENU DIAGRAM Notes: symbol means: symbol means: ME3025_13 03/21...
Page 12 MPCIB 396 P6 mect s.r.l. 2.0 INSTALLATION REMARKS 2.1 INSTALLATION PROCEDURE Make connections as indicated at pages: page 6, 7 and 8 – base instrument wiring diagram and input signal wiring 1. Switch the unit on. With the key it is possible to modify the decimal point position.
Page 13 MPCIB 396 P6 mect s.r.l. n° Key to Appears NOTES seq. press on the display “measure” To get out from the menu Reset Exit 3. If requested monodirectional input see paragraph “monodirectional pulse counter functioning” 4. If requested Add/Subtract counting modes see paragraph “A+B and A-B functioning”...
Page 14 MPCIB 396 P6 mect s.r.l. n seq. Key to Appears NOTES press on the display prog.  Set up the desired preset between –999999 and + 000000. 999999 **(press “prog. ” to confirm) PrESEt  nrES RESET TERMINAL CONFIGURATION prog. ...
Page 15 MPCIB 396 P6 mect s.r.l. n seq. Key to Appears NOTES press on the display appears on the display (see “COEN function” paragraph) **(press “prog. ” to confirm) CoEnC  dIUSon DIVISION FACTOR TOTAL COUNTING prog.  10000 Set division factor value (165535). This number will be the denominator of the correction constant **(press “prog.
Page 16 MPCIB 396 P6 mect s.r.l. 2.3 FRONT KEYS ENABLING The keys used on the front of the instrument for the direct sets up (reset, total counting, alarms and decimal point) can be disabled from the programming menu. Follow the next table.
Page 17 MPCIB 396 P6 mect s.r.l. N seq. Key to Appears on NOTES press the display prog.  On = enabled, OFF= disabled  Press “ ” key till when the desired function appears on the display **(press “prog. ” to confirm)
Page 18 MPCIB 396 P6 mect s.r.l. N seq. Key to Appears NOTES press on the display  Press “ ” key till when the desired function appears on the display. Press “prog. ” to confirm Reset Readout To get out from the menu Exit 2.5 “CoEnC”...
Page 19 MPCIB 396 P6 mect s.r.l. 2.6 “ PrESEt” FUNCTION (preset) The “PrESEt” function on the MPCIB396 P6 instrument allows to set up a preset, i.e. a number which appears every time that the instrument is zeroed. The “PrESEt” function works with any number between –999999 and +999999 (to set up the negative sign see “SET UP”...
Page 20 MPCIB 396 P6 mect s.r.l. or shorting to ground the terminal 18 or 19 if programmed to this function (see paragraph “TERMINALS 18 AND 19 CONFIGURATION”). The key can be disabled setting “OFF” at the “Abtrt” menu item (see “Front key enabling”...
Page 21 MPCIB 396 P6 mect s.r.l. 2. threshold with programmed set point (SOGLIA) 3. offset respect setpoint 1 (dELtA) For both alarms it is possible to configure: 1. starting relay condition (normally open or normally closed) 2. eventual hysteresys 3. eventual delay times (activation, deactivation or activation + deactivation) WINDOWED THRESHOLD (FinES).
Page 22 MPCIB 396 P6 mect s.r.l. AUTOMATIC CYCLE THRESHOLD for up count (S.AuuP). The counting when reaches the value SP1 changes the output for the time programmed in the “dELAY" menu item, loads the preset value on the display and restarts the cycle.
Page 23 MPCIB 396 P6 mect s.r.l. Table 8 n° Touch Appears REMARKS seq. on the display prog.  Touch the “prog. ” key to get into the PASS programming menu prog.  0 000 Digit the password code **(press “prog. ” to confirm) OUtPUt prog.
Page 24 MPCIB 396 P6 mect s.r.l. n° Touch Appears REMARKS seq. on the display ECC-dIS = activation + deactivation delay nO dLY = no delay  Select the desired item by " " key and confirm with “prog. ” SEL.d ...
Page 25 MPCIB 396 P6 mect s.r.l. n° Touch Appears REMARKS seq. on the display ECC-dIS = activation + de-activation delay nO dLY = no delay  Select the desired item by " " key and confirm with “prog. ” SEL.d ...
Page 26 MPCIB 396 P6 mect s.r.l. N.SEQ. Press key appears on NOTES display Reset measure Procedure to get out from the alarms menu. Exit 4.0 ANALOGUE OUTPUTS (option) The MPCIB396 P6 instrument can be ordered with a voltmeter or ammeter standard analogue output ( “OAP”...
Page 27 MPCIB 396 P6 mect s.r.l. 1- Follow the connections in FIG B for the voltmeter output or the connections on FIG A for the ammeter output. Rc< 400ohm Rc> 1Kohm Fig B Fig A Ammeter output Voltmeter output 2- Follow the programming procedure on following table and then check with the examples that follow.
Page 28 MPCIB 396 P6 mect s.r.l. Table 11 Press appears NOTE seq. display prog.  Press the “prog. ” key to get into the PASS programming menu prog.  0 0000 Input the personal Password number if already programmed see “password Function”...
Page 29 MPCIB 396 P6 mect s.r.l. ** to modify the number set-up see the procedure illustrated in the paragraph “SET- UPS”. 4.3 NOTES ON THE SET UP OF ANALOGUE OUTPUTS  Program instrument with the following calibration: READING: 100 AMMETER OUTPUT: 5 mA ;...
Page 30 MPCIB 396 P6 mect s.r.l. 5.0 SERIAL OUTPUT (option) "MPCIB396 P6" series models can communicate with an host computer along an opto-isolated RS232, RS422, RS485 half duplex serial line. Unidirectional serial output "MPCIB396 P6" series instrument with unidirectional optoisolated RS232 output...
Page 31 MPCIB 396 P6 mect s.r.l. Key to Appears NOTES seq. press on the display programming menu prog.  0 0000 Input the personal password number ** (confirm with “prog. ”) OUtPUt prog.   Out.An  Out.rS prog.  bAUd BAUD RATE prog.
Page 32 MPCIB 396 P6 mect s.r.l. L+ L - Host c omputer Figure F.(RS232) Figure G (RS485) ME3025_13 03/21...
Page 33 MPCIB 396 P6 mect s.r.l. 5.1 DATA READING FROM HOST TO INSTRUMENT MPCIB396 P6 Transmission string set-up. GID GID UID UID C1 C2 EOT = EOT from host indicates start of transmission string GID = Instrument address: ASCII in decimal code to transmit twice consecutively UID = Instrument address: in units ASCII to transmit twice consecutively C1 C2 = mnemonic ASCII code for command to follow (see paragraph “command...
Page 34 MPCIB 396 P6 mect s.r.l. D1 D8 = digits observed, including negative nos. , also ">", decimal points (if required ) and blank or zero for digit not used ( the transmitted digits must always be eight) ATTENTION: the data must always be right justified and in any case the significant numbers cannot be more than five.
Page 35 MPCIB 396 P6 mect s.r.l. C1 C2 = mnemonic ASCII code for command to follow . (see paragraph “command codes”). D1  D8 = Digits seen. The same rules are valid as those described in the paragraph " data transmission from MPCIB396 P6 to host"...
Page 36 MPCIB 396 P6 mect s.r.l. PrESEt Read/write ASCII 0 ÷ + -999999 P.dEC Read/write Hexadecimal (decimal point) 0 = no point 1 = 99999.9 2 = 9999.99 3 = 999.999 4 = 99.9999 5 = 9.99999 NUnEr Read/write ASCII 1 ÷ 65535...
Page 37 “D2” are considered “blank”. With the instrument in hold state, “D1” gets the H value while “D2” keeps staying “blank”. 5.6 ALARM SETTING (W status word) MPCIB396 P6 series instruments can have 3 alarms. The relevant codes to program are: reading/writing of SP1...
Page 38 MPCIB 396 P6 mect s.r.l. 5.7 AR STATUS WORD The “AR” status word allows to configure the front keys enabling by serial line, the terminals configuration, the kind of encoder counting. You can see the status word description in the following picture.
Page 39 MPCIB 396 P6 mect s.r.l. 5.8 BASIC PROGRAM The following basic program shows the reading of the set-point of an instrument by an host computer. Set up baud rate = 9600 and address = 01 for the functioning of the program.
Page 40 MPCIB 396 P6 mect s.r.l. .0 PASSWORD FUNCTION Programmed data can be protected from unauthorised changes using the password function. The instrument is supplied with the password code set = 0; any number in the range 0 to 9999 can be used as access key to changing set data.
Page 41 The instruments must be powered by safety isolating transformer or by selv type power supply. Mect srl is not responsible for damages to humans or goods for an improper use of the instrument or not conforming to the characteristics of its instrument.
