MLN-192 Option Card Installation
The MLN-192 Milan Option Card for the VENUE E6L engine is
™
compliant with MILAN
interoperability specifications, and
provides AVB connection to 3rd-party Milan-compliant devices.
E6L-112 installation varies slightly from E6L-192/144, as noted
throughout this guide.
Images shown in this guide (such as cable colors or hardware
configuration) may not exactly match your E6L.
System Requirements
VENUE software 7.0 or higher. After install-
VENUE Software
ing the MLN-192 card you must update its firmware as described
in this guide.
Required Materials
Included:
• 1x MLN-192 Card
• 1x Back Bracket and 1x Option Card Bracket
• 1x replacement faceplate for E6L-112 (only)
Not Included (must be acquired separately):
• Phillips #2 screwdriver (not included), 12-inch recommended
• Anti-Static wrist strap (not included)
• Foam or other soft surface to place the card on
• Table or other flat work surface strong enough to support the
E6L Engine Core
Unlike AVB-192 and WSG-HD cards, no internal Ethernet
jumper cables are required for the MLN-192 card.
™
The Stylized M
Logo, the MILAN & Design
are registered or unregistered service marks and certification marks of Avnu Alli-
ance, Inc. in the United States and other countries. Unauthorized use strictly
prohibited.
© 2020 Avid Technology, Inc
®
mark, and the MILAN™ word mark
9320-70130-00 REV A
Removing the E6L Engine Core
MLN-192 cards are installed in the E6L engine core, which slides
out of the E6L chassis.
To remove the E6L engine core
Put on your anti-static wrist band and configure it according to
1
its instructions.
Shut down your system, and disconnect any cables connected
2
to your E6L engine.
Place your E6L on a table or other flat surface that provides
3
enough room for the E6L engine core to be removed comfort-
ably. Make sure your surface is clear of any debris.
If your E6L engine is installed in a rack and there is enough
room inside the rack to access the inside of the core, instead
of completely removing the core you can slide it out until it
catches, and then proceed with installation.
On the back of the E6L, loosen the four thumbscrews that se-
4
cure the core to the engine chassis.
Figure 1. Four thumbscrews on the back of the E6L
MLN-192 Option Card Installation 1
Advertisement
Related Manuals for Avid Technology Milan MLN-192
Summary of Contents for Avid Technology Milan MLN-192
- Page 1 MILAN™ word mark are registered or unregistered service marks and certification marks of Avnu Alli- ance, Inc. in the United States and other countries. Unauthorized use strictly prohibited. MLN-192 Option Card Installation 1 © 2020 Avid Technology, Inc 9320-70130-00 REV A...
- Page 2 Simultaneously pull the two bottom thumbscrews outward so Remove AVB-192 Network Cards the latches they are attached to are fully extended, as shown in Figure 2. E6L-192 and E6L-144 Only Before installing an MLN-192 Card in an E6L-192 or E6L-144, both AVB-192 Network Cards must be temporarily removed.
- Page 3 Using a #2 Phillips screwdriver, loosen the rear bracket cap- Back Bracket and Option Card tive thumbscrews that secures the back of the AVB-192 Net- Bracket work cards to the chassis. The MLN-192 Card package includes one Back Bracket and one Option Card Bracket.
- Page 4 Remove the MLN-192 Card from its packaging and hold it by Install the MLN-192 Card its edges. MLN-192 Card installation differs depending on the type of E6L engine. Follow the instructions in the section appropriate for your Rear bracket E6L engine: Ethernet ports •...
- Page 5 E6L-112 Align the PCIe connector on the card with the corresponding PCIe port, and align the flange on the card with the retaining If you are installing an MLN-192 card into an E6L-112, the clip on the PC board. MLN-192 card can be installed in Expansion slot 1, or into AVB Applying pressure along the full length of the card, press it Network slot 3.
- Page 6 Installing MLN-192 Card into Expansion Slot 1 Recommended: Disconnect the power cables connected to HDX cards installed above the Option card slots and tuck them (E6L-112 Only) out of the way. It is possible to install cards into Expansion slots without disconnecting these cables, as long as you are To install the MLN-192 card into Expansion slot 1: careful to not stretch the cables or damage their connectors Looking inside the core from the right side, locate the E6L...
- Page 7 Remove the captive thumbscrew assembly from the rear end Make sure the card is fully seated in the PCIe slot and that the of the card. white retaining clip clicks into position. You can check by looking underneath the card. Figure 28.
- Page 8 • Carefully place the card retaining bracket back into posi- To install the faceplate for E6L-112 AVB Network slot 3: tion, making sure to not disturb the surface of the DSP cards Place the card on your padded work-surface face-down. in the process or pinch any cables.
- Page 9 To install the MLN-192 card into AVB Network slot 3: Re-Install the AVB-192 Cards Hold the card it by its edges. E6L-192 and E6L-144 Only Inside the unit, place the face of the card into position in the After installing a MLN-192 card into an E6L-192 or E6L-144, slot, with the back of the card tilting upwards.
- Page 10 Lift the tab on the retaining clip and press the card firmly into Re-connect the Ethernet cable from the E6L to the right-most the PCIe port and clip. port on the Master AVB-192 card. Original factory cabling may vary. Follow the instructions in this guide to achieve the recommended cabling scheme.
- Page 11 Lift the tab on the retaining clip, and then apply pressure along Tighten the rear bracket captive thumbscrew to secure the the entire edge of the card to press it firmly into the PCIe port back of the card to the chassis. and clip.
-
Page 12: Confirming Installation
Let the firmware update complete. You can wait for the banner Re-install the E6L Engine Core display to indicate the update has finished, or go to Options > to view progress of the update. Slide the core back into the E6L chassis, making sure the con- Devices nectors face outward. -
Page 13: Appendix A: Brackets
Appendix A: Brackets The MLN-192 Card package includes one Back Bracket and one Using a #2 Phillips screwdriver, loosen the two captive thumb- Option Card Bracket. These newer brackets are pre-installed in screws that secure the back bracket to the interior wall of the all recently manufactured E6L engines. - Page 14 Replace the two screws to secure the top of the new bracket to the tabs on the chassis. Replace the Option Card Bracket To replace the option card bracket: Using a #2 Phillips screwdriver, loosen the two captive thumb- screws that secure the bracket to the chassis. Figure 58.
-
Page 15: Appendix B: E6L-112 Card And Slot Configurations
Appendix B: E6L-112 Card and Slot Configurations E6L-112 engines support a maximum of two Option cards, in- stalled into Expansion slot 1 and/or Network slot 3, in the follow- Configurations MLN-192 ing combinations: AVB-192 AVB-192 ACT T S S IG IG 5 –... - Page 16 MLN-192 Option Card Installation...
