800W ELECTRIC JACK HAMMER DEMOLITION CHISEL BIT
ITEM: 61110
OWNER'S MANUAL AND SAFETY INSTRUCTIONS
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT'S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER)
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 4900 MON-FRI 9AM TO 3PM PST
Advertisement
Table of Contents
Summary of Contents for Stark Tools USA 61110
- Page 1 800W ELECTRIC JACK HAMMER DEMOLITION CHISEL BIT ITEM: 61110 OWNER’S MANUAL AND SAFETY INSTRUCTIONS SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY, OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION GENERAL SAFETY WARNINGS Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. SAFETY The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. - Page 3 IMPORTANT SAFETY INFORMATION POWER TOOL USE AND CARE DO NOT force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. DO NOT use the power tool if the Switch does not turn on and off.
-
Page 4: Features And Specifications
FEATURES & SPECIFICATIONS BULL POINT BIT SCALING BIT SQUARE CLAY CHISEL POWER SWITCH SPADE BIT SELECTOR RING HAND GRIP VENTILATION OPENINGS LOCKING SLEEVE POWER AUXILIARY CORD HANDLE Assembled Product Dimensions (L x W x H) 35.00 x 14.00 x 8.00 Inches This 2800W jack hammer is ideal for demolition, trenching, chipping, breaking holes in concrete-block- brick, removing foundation concrete slab, oil chimney and so on. -
Page 5: Operation
OPERATION COMMON APPLICATIONS: Piping & wiring installation Water supply & drainage work Sanitary facility installation Interior work Machinery installation Civil engineering work PRIOR TO OPERATION: 1. POWER SOURCE: Ensure that the power source to be utilized conforms to the power specifications on the nameplate. -
Page 6: Maintenance And Inspection
MAINTENANCE AND INSPECTION OIL FEEDING: Prior to oil feeding, ALWAYS disconnect the plug from the power receptacle. Since the oil chamber is built into the tool, it can be used approximately 20 days at 3-4 hours a day, without supplying lubricating oil. Just before there is no oil visible in the oil gauge window when holding the hammer upright use the provided wrench to remove the oil gauge. -
Page 7: Parts List
PARTS LIST... - Page 8 PARTS LIST...
-
Page 9: Please Read The Following Carefully
PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
