Heart of House Jasmin 304/4733 Assembly Instructions

Bistro table

Jasmin Bistro Table.

Dimensions

Diameter-70cm

Height-72.5cm

Important –

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800

For further assistance please visit http://www.argos-support.co.uk/

Please keep for future reference

304/4733

Issue 1 - 26/05/10

Table of Contents

Do you have a question about the Jasmin 304/4733 and is the answer not in the manual?

Page 1 Jasmin Bistro Table. 304/4733 Assembly Instructions - 304/4733 Please keep for future reference Dimensions Diameter-70cm Height-72.5cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 For further assistance please visit http://www.argos-support.co.uk/ Issue 1 - 26/05/10...
Page 2 page 2. This product has been When using a parasol with this designed for careful domestic table,always use a parasol base. outdoor use.
Page 3 Components - Parts Please check you have all the parts listed below Table top x1 Table leg x4 Small top x1 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. Metal washer x16 M6*52mm Screw×4 M6*12mm Screw×8...
Page 4 Assembly Instructions Step 1 Assembly frame Assembly should be carried out by two people. Use allen key ,screws metal washer ,nuts and spanner to fix the small top 3 to 4 table legs 2 . Important: Do not fully tighten all screws until assembly is complete.
Page 5 Step 3 Seal all the screws & and nuts with plastic caps & Step 4 Turn the table to its upright position Customer Helpline: 03456 400800 For further assistance please visit http://www.argos-support.co.uk/ Argos Limited...
