INSTALLATION AND OPERATION INSTRUCTIONS
PERLICK ICE CREAM CABINET
Introduction
Congratulations on your purchase of a Perlick
commercial underbar product. This manual has been
prepared to assist you in the installation of your cabinet
and to acquaint you with its operation and maintenance.
This manual has been prepared to assist you in the
installation of your Ice Vault and to acquaint you with
its operation and maintenance.
We dedicate considerable time to ensure that our
products provide the highest level of customer
satisfaction. If service is required, your dealer can
provide you with a list of qualified service agents. For
your own protection, never return merchandise for credit
without our approval.
We thank you for selecting a Perlick product and assure
you of our continuing interest in your satisfaction.
GENERAL INFORMATION
Warranty
To register your product, visit our web site at www.
perlick.com. Click on "Commercial", then "Service".
Click on the link "Warranty Registration Form". You
must complete and submit this form or the installation
date will revert back to the ship date.
Please record the purchase date and the dealer's name,
address and telephone number below.
Model Number: _____________________________
Serial Number: ____________________________
Purchase Date: _____________________________
Dealer Name & Address
___________________________________________
___________________________________________
__________________________________________
Phone Number_______________________________
MODEL
8000B
C
US
R290 Hydrocarbon
Refrigerant
Form No. Z2643
Rev. 11.24.2020
Advertisement
Table of Contents
Summary of Contents for Perlick 8000B
- Page 1 Dealer Name & Address your own protection, never return merchandise for credit ___________________________________________ without our approval. ___________________________________________ __________________________________________ We thank you for selecting a Perlick product and assure Phone Number_______________________________ you of our continuing interest in your satisfaction. Form No. Z2643 Rev. 11.24.2020...
-
Page 2: Table Of Contents
Read and understand all information in this manual before attempting the installation. All plumbing and electrical work must be performed by a qualified technician and conform to all applicable state and local codes. Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice... -
Page 3: Cabinet Specifications
Refrigerant Charge (g) REFRIGERATION SPECIFICATIONS Compressor H.P. 1/6 H.P. Total Heat of Rejection 205 BTU/hr At 75°F ambient (BTU/h) Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice Form No. Z2643 Rev. 11.24.2020... -
Page 4: Preparing Cabinet For Use
CFC’s, or HCFC’s. - Lower Limit: 1.7% by vol. (37 g/m3) - Upper Limit: 9.5% by vol. (177 g/m3) - Ignition Temperature: 470 °C Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice... -
Page 5: Placing The Cabinet
Use a damp cloth with mild detergent and water to clean the inside and outside of the cabinet. Dry thoroughly. Figure 2: Digital Temperature Controller Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice Form No. Z2643 Rev. 11.24.2020... -
Page 6: Installation
METAL WASHER LOCK NUT RUBBER WASHER VALVE STEM CARDBOARD WASHER RETAINING NUT LOCK NUT Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice RELEASE FOR PRODUCTION 7/15/2015 REVISIONS SCALE 1:10 Perlick Corporation... - Page 7 • Insert ice cream cabinet into opening as shown, making sure there are no voids in sealant where top flange meets the countertop. Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice Form No. Z2643 Rev. 11.24.2020...
-
Page 8: Wiring Diagrams
Ice Cream Cabinet Installation & Operation Manual Wiring Diagram BLACK (L) BLACK (L) RED (COMP) BLACK (L) WHITE (N) WHITE BROWN BLACK BLUE Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice... -
Page 9: Replacement Parts
Items Not Shown Power cord & Wiring harness 1028207 Suction line and capillary tube assembly 1027764 Refrigerant charge (grams R290) Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice Form No. Z2643 Rev. 11.24.2020... -
Page 10: Spec Drawings
Milwaukee, WI 53223 THIS DOCUMENT/PUBLICATION/SOFTWARE/DRAWING CONTAINS PROPRIETARY INFORMATION WHICH IS THE PROPERTY OF THE PERLICK CORPORATION. IT MAY NOT BE REPRODUCED OR TRANSMITTED IN ANY FORM, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING, RECORDING, OR USED IN ANYINFORMATION STORAGE, TRANSMISSION, OR RETRIEVAL SYSTEM, WITHOUT WRITTEN PERMISSION FROM THE PERLICK CORPORATION COPYRIGHT 2001 PERLICK CORPORATION. - Page 11 Ice Cream Cabinet Installation & Operation Manual Notes Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice Form No. Z2643 Rev. 11.24.2020...
- Page 12 Form No. Z2643 Rev. 11.24.2020 8300 West Good Hope Road • Milwaukee, WI 53223 • Toll Free 800.558.5592 • Fax 414.353.7069 • www.perlick.com...
