Page 3: Table Of Contents
Introduction ........................ 7 CHAPTER 1 Welcome ........................ 7 Safety & Environmental ..................8 Cross Contamination ....................8 How the QuantiFit2 Works ..................10 CHAPTER 2 Fit Factor Explanation ..................10 Instrument Setup ..................... 12 CHAPTER 3 What's Included? ....................12 Unpacking ...................... - Page 4 Contents Update Software ....................35 OHD Logic Software ....................36 CHAPTER 10 Installation ........................ 37 CHAPTER 11 Wizard ........................38 CHAPTER 12 Software Updates ....................40 CHAPTER 13 Home Screen ......................41 CHAPTER 14 Test Creator ......................42 Add Person ......................43 Past Due Viewer ....................
- Page 5 Contents Software License Agreement ................65 Appendix A: Specifications ..................66 CHAPTER 23 Appendix B: Import Personnel Template .............. 67 CHAPTER 24 Appendix C: Terminology ..................68 CHAPTER 25 Appendix D: CNP Diagram ..................70 CHAPTER 26 Appendix E: Regulations ..................71 CHAPTER 27 Appendix F: Fit Test Adapters ................
-
Page 7: Introduction
Or, at a later time, data can be imported into Logic software (when Logic and the QuantiFit2 have been set up for merging or synchronizing data). The instrument is not compatible with FitTrack Gold, which comes with the original Quantifit. -
Page 8: Safety & Environmental
The QuantiFit2 does not trap air in its system either before, during or after a fit test. The QuantiFit2 does not push air into the mask. The QuantiFit2 pulls air away from the test subjects mask and vents it out of the system. - Page 9 EPA approved disinfectant as these have been shown to efficiently inactivate over 99% of microorganisms (to include COVID-19) within a minute. The adapter should be dry before use in a fit test. The QuantiFit2 tubing should be carefully wiped down with an EPA approved disinfectant.
-
Page 10: How The Quantifit2 Works
When the challenge pressure is reached, if there isn’t a leak, the QuantiFit2 doesn’t remove any more air from the respirator. If there is a leak, air enters the respirator. The QuantiFit2 then removes air from the respirator until the challenge pressure returns to the targeted value. This process continues for 8 seconds, and then the test step ends. - Page 11 FF1 = The fit factor for the first exercise; and FF2 = The fit factor for the second exercise; and FFN = The fit factor for the nth exercise Chapter 2 | How the QuantiFit2 Works | Fit Factor Explanation...
-
Page 12: Instrument Setup
E. USB Cable F. Tube Assembly G. Additional Storage Unpacking The QuantiFit2 case can contain all of the necessary materials for performing fit tests. There are no consumables required to be purchased or used. Chapter 3 | Instrument Setup |... - Page 13 · Spare batteries · Cords, cables and tubes o Carefully lift out the QuantiFit2 by holding the handle and the bottom of the instrument · Place the instrument on a solid, level surface with ample surface room · Connect the power supply into the back of the instrument, and the power cord to a wall outlet (unless using a battery that has been properly charged) ·...
-
Page 14: Instrument Front Connections
Instrument Setup Instrument Front Connections A. Carrying Handle B. Color Touch Screen C. Clear Tube Connection D. Gray Tube Connection E. Blue Tube Connection F. Verification Connection for Gray Tube G. Verification Connection for Clear Tube H. Verification Connection for Blue Tube I. -
Page 15: Instrument Back Connections
H. Battery Pack (optional) or Cover – When using an optional battery pack to operate the QuantiFit2, it will be inserted here. When no battery pack is purchased, this cavity will be filled with a blank cover. I. Bluetooth Module (not shown) - When purchased with the Bluetooth function, the QuantiFit2 can wirelessly connect to a computer with Bluetooth capability. -
Page 16: Connecting Tubes
The battery may be charged while connected to power whether using the QuantiFit2 or not. o An optional battery charger is available to charge the battery outside of the QuantiFit2. o When fully charged, the battery typically yields approximately four hours of normal-use testing. - Page 17 Instrument Setup o Lithium Battery Hazards (From OSHA Safety and Health Information Bulletin SHIB 06-20- 2019): · Lithium batteries are generally safe and unlikely to fail, but only so long as there are no defects and the batteries are not damaged. When lithium batteries fail to operate safely or are damaged, they may present a fire and/or explosion hazard.
-
Page 18: Daily Verification
Instrument Setup Daily Verification The daily verification is required for each day of testing. The purpose is to confirm that the instrument is working properly. The daily verification test measures the leak rate of the leak orifice on the triple tube assembly at various pressure levels, and confirms that the diaphragm pump and other processes are working correctly. -
Page 19: Startup Wizard
PC or other sources, you must first load all people into the included OHD Logic Software and then transfer the data to the QuantiFit2 via a USB thumb drive or the provided USB cable. -
Page 20: Navigation
Startup Wizard Operator o For every test performed on the QuantiFit2, an operator must be assigned to the record. o The Operator screen is used to add/edit operators in the database. o Enter one or more operator. Additional operators may be added in the Instrument Setup section. - Page 21 Startup Wizard There are five major modules to select from: People/Test: Where people are added, edited, or imported, and where tests are initiated. Seal Check: Holding this button will close off the air flow in the respirator so that the test subject can do a user seal check.
- Page 22 DOWNLOAD – For loading people into SAVE – The green checkmark will save the QuantiFit2 from the OHD Logic the information entered on the screen software EDIT – allows the operator to change SEAL CHECK – Allows the test subject to...
-
Page 23: People
Company is intended to create a division among the test subjects who are entered into the on-board database. o To add a company to the QuantiFit2 database, type in a company name when adding a test subject to the database. - Page 24 CAUTION: After deletion, a test subject cannot be restored. Download o The download feature allows test subjects to be uploaded in bulk. o This can be done through a CSV file from the OHD Logic software. o See 24 Appendix B: Import Personnel Template for import template requirements.
- Page 25 People Test Screen o The test screen prompts the operator or test subject to select or fill in the details of the test. o This includes Respirator, Size, Operator, and if the respirator used for testing is a surrogate respirator or the respirator actually assigned to the test subject (required only for the HSE regulation).
-
Page 26: Performing A Test
Performing A Test · Instructing the test subject: The general instructions below can teach the operator and test subject basic steps to follow during the fit test. Follow all applicable regional and industry- specific guidelines or regulations. o If the respirator has an inhalation valve at the place where a fit test adapter will be connected to the respirator, it must be removed or propped open. - Page 27 Performing A Test § Remain still for the duration of the test. · If not using auto start, § Instruct the test subject to take a comfortable breath and hold it, and then press the green button on the screen §...
-
Page 28: Reports
Reports Reports may be printed at the time of the test, or any time after the testing has been completed. The following reports are available on the QuantiFit2: o Individual Fit Test Report · A single-page report that contains all required data for a respirator fit test record. - Page 29 Reports § Printed directly to an approved printer Chapter 7 | Reports |...
-
Page 30: Daily Verification
Run a daily verification whenever the triple tube assembly is changed. o Troubleshooting: · If the instrument passes the daily verification, this confirms that the QuantiFit2 is working properly. · If the instrument does not pass the daily verification, troubleshooting information will be diplayed. -
Page 31: Settings
Auto Start o Auto Start is turned on by default. o When this features is turned on, the QuantiFit2 assesses when the test subject is ready for the test to begin. o The test subject takes in a breath and holds it until the circle in the lower right corner turns green. -
Page 32: System Info
Redon Delay is the number of seconds to delay the QuantiFit2 while the test subject redons the respirator so that auto start is not analyzing samples while the redon is taking place. -
Page 33: Admin Menu
Admin Menu The Admin Menu is a directory for settings that could potentially cause unwanted changes to the QuantiFit2. These settings should be changed only by a person who has been trained and understands the purpose of each setting. Setup Operators o Operator setup is necessary to record those people who will be running the tests. -
Page 34: Change Regulation
There are numerous reset options according to which information needs to be reset. Clear People List will remove all of the people in the current database. This would be helpful if another entity will use the QuantiFit2, or to upload a fresh list of names for a new year of testing. -
Page 35: Update Software
This option will not erase any of the information listed above. Reset to Factory Settings will remove all data on the Quantifit2 and it will operate as though it is the very first time the unit is powered up. -
Page 36: Chapter 10 Ohd Logic Software
OHD Logic Software OHD Logic Software is intended to be driven by icons, and each icon function can be viewed by mousing-over the icon. In the case of the icons on the left sidebar, the Menu icon at top left can be clicked, and the menu will pop-out to display the names next to each icon. -
Page 37: Installation
Installation OHD Logic Software is to be installed on a PC running Windows software version 10 or greater. PC requirements: o Processor Speed: 1.0 GHz or greater o RAM: 1 GB or greater o Disc Space: 16 GB The installation must be completed by someone logged onto the PC who has administrative privileges. -
Page 38: Wizard
Appendix B 8. Add Quantifit2 a. In order to use the Quantifit2 through OHD Logic software, it must first be registered to the software b. The Quantifit2 must be powered on, and the connection may be by either Bluetooth or USB cable c. - Page 39 Wizard Chapter 12 | Wizard |...
-
Page 40: Software Updates
Software Updates OHD Logic software will be updated periodically to enhance features, add features, or fix bugs. In the Settings section, there is an option to automatically receive updates. If this is not turned on, whenever the Update menu is selected, the software will check to see if an update is available and there will be an option to update or not. -
Page 41: Home Screen
Home Screen After initial setup, most people can do any task required directly from the Home Screen. This includes running tests, adding people, adding respirators, viewing test statistics, and identifying those people who are due for testing. Each of the modules seen on the Home Page can be collapsed by clicking on the no-view icon. -
Page 42: Test Creator
Home Screen Test Creator To perform a fit test, it must be launched from the Test Creator. The Test Creator is a simple guide to record pertinent test information and to initiate the test. o Operator · Add first name and last name to the operator selection. -
Page 43: Add Person
QuantiFit2 · Use the drop-down menu to select the instrument you want to use for testing. · If a QuantiFit2 has not been registered to the software, this will need to be done through the Settings/Devices menu. · If only one unit is registered, this field will be populated with that instrument. -
Page 44: Past Due Viewer
Home Screen § List - when predetermined selections are required. · The list can be modified at any time. If a field is removed, the data contained in that field will not be deleted, and can be seen if that field is activated again. ·... -
Page 45: People
People The people list shows the people in the currently selected company who have not been made inactive. The All Companies box can be checked for a list of people throughout all companies. Users can be made inactive if they have left their position, or no longer require fit testing. -
Page 46: Company
Company · Many QuantiFit2 users will have only one company, while others might have dozens, depending on the needs for testing. · The purpose for a Company is to create a division within the database. o The company name will appear on the top of the fit test reports. -
Page 47: Tests
The test screen is where any active test can be viewed. This may be one test, or it may be for an operator who is controlling multiple instruments. The QuantiFit2 allows users to run countless machines simultaneously through the OHD Logic software (as many machines as an operator is capable of overseeing), with flexibility on the start time for any test. - Page 48 Operator sets up the test." · If the daily verification check has not been completed for the day, the QuantiFit2 will prompt the user to perform this check. · When the test is initiated, the test subject will see "Please review this information. If correct, press the blue arrow to continue."...
-
Page 49: Settings
These credentials either will be assigned to Operator or Administrator status. § Operator status allows a person to log into OHD Logic and run tests, reports, add people, and all of the regular functions of a fit testing program. -
Page 50: Options
Date Format allows the Administrator to select the type of date format preferred. (MM/DD/YYYY, DD/MM/YYYY, YYYY/MM/DD) o Allow Reporting When this feature is allowed, the software will send errors to OHD. This will help OHD to continue to refine the software, and it may help with troubleshooting issues. -
Page 51: Respirators
Respirators Respirator List OHD Logic Software comes with a pre-populated list of respirators. Every effort is made to keep this respirator list up to date, but if a respirator that is being used does not appear on the list, it may be added. -
Page 52: Respirator Sizes
About In the About section, information is included for: · OHD Contact Information Address: 2687 John Hawkins Pkwy, Hoover, AL 35244, USA Phone: +1-205-980-0180 Website: www.ohdglobal.com Email: sales@ohdglobal.com,... -
Page 53: Chapter 19 Reports
A report for the current day's verification or a date range of daily verifications. When a report is saved, it can be found as a PDF inside the Reports Folder. Click on the button to open the Reports Folder. By default, this can be found at: This PC:\Documents\OHD\OHD Logic\Reports. -
Page 54: Chapter 20 Troubleshooting
When the traceline does not lift above the bottom of the graph, this indicates that there is a large leak between the QuantiFit2 and the person wearing the respirator. This would be related to a leak in the integrity of the respirator, a poor donning, or poor fit of the respirator. - Page 55 Failure to reach challenge pressure Like the large leak, when the traceline does not reach the challenge pressure line, this indicates that there is a moderate leak between the QuantiFit2 and the person wearing the respirator. 1. Check all connections for proper attachment.
- Page 56 Traceline way above challenge pressure line The QuantiFit2 traceline goes opposite of the direction of the pressure. If the line is above the challenge pressure line, that means that there is too much negative pressure. In this case, a test subject is most likely sucking in a breath during the test.
-
Page 57: Failing Fit Factors
When fit factors are consistently low, the respirator may be a poor fit for that person. If the graph looks normal and the fit factor is low, that means that the QuantiFit2 is successful in meeting the challenge pressure, but a large volume of air is required to be removed to achieve that targeted pressure, which means the leak is too large. -
Page 58: Trouble Passing Fit Test
If the QuantiFit2 finishes passes the daily verification procedure, this assures that the instrument is operating properly and measuring within tolerance. c. If the QuantiFit2 is not able to complete the Daily Verification Check, service will be needed. Please contact OHD customer service. -
Page 59: Verification Check Errors
The transducer needs factory calibration. o Blockage of exhaust port. Possible Solution: o Turn QuantiFit2 off at the power switch, wait 15 seconds, power on the Quantifit, and retry Verification Check. Chapter 20 | Troubleshooting | Trouble Passing Fit Test... - Page 60 Troubleshooting o Remove and replace all tubes. o Contact OHD to evaluate problem or to arrange return for factory calibration. Chapter 20 | Troubleshooting | Verification Check Errors...
-
Page 61: Chapter 21 Service
CAUTION: The QuantiFit2 is intended to be serviced only by authorized service personnel. Troubleshooting and service procedures should only be performed by qualified technicians. o If the QuantiFit2 appears to be tampered with, this may render the warranty null and void. o For service and operation questions, contact OHD: service@ohdglobal.com, +1.205.980.0180. - Page 62 Service · Extends Service Life – The heart of the QuantiFit2 is a mechanical piston type pressure engine. Included in the calibration procedure are pressure engine checks. The pressure engine is completely disassembled, cleaned, and lubricated where warranted. · Upgrades – The calibration process includes upgrades to the latest firmware versions and modifications as needed.
-
Page 63: Chapter 22 Terms & Conditions
Terms & Conditions Standard Terms and Conditions Claims Return Procedure Every product returned to OHD, for service, repair, or Our routine method of shipment is via returned for refund/credit must be calibration, we recommend using United common carrier, FOB origin. Upon... - Page 64 Terms & Conditions you must first contact OHD technical © Copyright OHD agrees to a limited All written requests must be submitted to support department at +1 205-980- copyright release that allows you to the contact information as follows: 0180. You will be required to provide...
-
Page 65: Software License Agreement
OHD, LLLP Software. Except as set forth in the loss) arising out of the use of or (OHD). If you do not agree to the preceding sentence, you may not inability to use this OHD product, terms set forth in this License copy the Software. -
Page 66: Chapter 23 Appendix A: Specifications
USB Interface 4 Type A Ports (Keyboard, USB Memory, Printer) ....................4 1 Type B Port (PC Communication) ........................1 PC Requirements for OHD Logic Software Operating System ........................ Windows 10 or newer Processor Speed ........................1.0 GHz or greater RAM ............................... -
Page 67: Chapter 24 Appendix B: Import Personnel Template
Appendix B: Import Personnel Template To import a list of names directly into the QuantiFit2, an Excel spreadsheet must be filled out with specific headers (see below). Fields can be empty and will be empty on the unit. When importing data from the OHD Logic Software, the data will be formatted perfectly for import. -
Page 68: Chapter 25 Appendix C: Terminology
Appendix C: Terminology Air-purifying respirator (APR) a respirator with Escape-only respirator a respirator intended to a filter, cartridge, or canister that removes be used only for emergency exit. specific air contaminants by passing ambient air Filter or air purifying element a component through a purifying element. - Page 69 Appendix C: Terminology Loose-fitting facepiece a respiratory inlet Pressure demand respirator a positive pressure covering that is designed to form a partial seal atmosphere-supplying respirator that admits with the face. breathing air to the facepiece when the positive pressure is reduced inside the facepiece by Maximum use concentration (MUC) the inhalation.
-
Page 70: Chapter 26 Appendix D: Cnp Diagram
Appendix D: CNP Diagram Chapter 26 | Appendix D: CNP Diagram |... -
Page 71: Chapter 27 Appendix E: Regulations
Appendix E: Regulations OSHA (Occupational Safety and Health Administration) o 5-Step Protocol i. Face Forward ii. Bend Over iii. Shake Head iv. Redon 1 v. Redon 2 o Challenge Pressure/Modeled Breathing Rate i. Half Face: 0.58/53.8 ii. Full Face: 0.58/53.8 iii. - Page 72 Appendix E: Regulations ix. Head Up Test x. Head Down Test xi. Talking Exercise xii. Face Forward Test xiii.Bend at Waist Exercise xiv.Face Forward Test xv. Normal Breathing Exercise xvi.Face Forward Test o Challenge Pressure/Modeled Breathing Rate · Half Face: 0.58/53.8 ·...
-
Page 73: Chapter 28 Appendix F: Fit Test Adapters
OHD testing adapters must be maintained with great care. Any dents or cracks that can occur will lose the ability to keep an air-tight seal, which would make it inadequate for testing. - Page 74 Appendix F: Fit Test Adapters a. The adapters must be kept clean and in good shape. b. Disconnect and reconnect all tubes to make sure the connectors “snap” into place. Hold the assembly by the tubes rather than the metal connector. c.
- Page 75 Controlled Negative Pressure Login Timeout Cross Contamination Current Date Current Time Maintenance Cycle Count Modeled Breathing Rate Daily Verification 18, 30 Negative Pressure Respirator Daily Verification Reports NIST Calibration Dark Mode Date Format Delete Download OHD Logic Software Operator 19, 49 Operators...
- Page 76 OSHA Index UK-HSE Parameter Update Parameters Update Software Password Updates Past Due Upload Past Due Viewer Product Support Verification Check Qualitative Fit Test Quantitative Fit Test WARNING: Warranty Regulation Regulations Reports Zero Fit Factor Respirator SCBA Search Search Field Security signature Signature Capture Software Version...
