USER'S MANUAL
/ MODEL S2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro S2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Suiff Pro S2

  • Page 1 USER’S MANUAL / MODEL S2...
  • Page 2: Table Of Contents

    ....10 AUTOMATIC SWITCH-OFF FEATURE ................13 CHARGING THE BATTERY ....................14 BLUETOOTH RECOMMENDATIONS ................15 ® CHOOSING THE RIGHT PLACE TO USE SUIFF ............15 SAFETY INFORMATION ..................... 16 EXERCISES AND RECOMMENDATIONS ................18 ® HOW TO ANCHOR THE SUIFF PRO SENSOR ..............19...
  • Page 3 ® product. This means you have a challenge ahead. Let us be part of it and help you rise to it. To use your SUIFF PRO sensor with a mobile device, please install the SUIFF PRO App on ® ®...
  • Page 4: Our Goal

    We aim to help physical conditioning and rehabilitation professionals, providing technological equipment that can add value to their patient treatment and services. THE SUIFF® PRO EQUIPMENT The SUIFF ® PRO equipment consists of the SUIFF ® PRO sensor and its training accessories: The SUIFF ®...
  • Page 5: The Suiff® Pro Sensor

    The sensor records force measurements and sends them to a mobile device, a smartphone or ® ® tablet. The exclusive SUIFF PRO mobile App receives and processes the data sent by the SUIFF PRO sensor and presents it to the user in real time. The SUIFF ®...
  • Page 6: Suiff® Pro Sensor Details

    USER’S MANUAL SUIFF® PRO SENSOR DETAILS Anchor handles Aluminium alloy. On/off button To attach the device to a wide Switch on – click. variety of exercise machines in a Switch off – Hold for 3 sec. fast and easy way.
  • Page 7: Correct Use Of The Suiff® Pro Sensor

    MAXIMUM ALLOWED LOAD PRO sensor is 180 kg. ® The maximum traction load allowed by the SUIFF If this maximum load of 180 kg is exceeded, the device’s measuring system or its internal sensor might be affected leading to incorrect functioning.
  • Page 8: Led Modes

    USER’S MANUAL LED MODES Upper led Upper led Lower led Green light flashing Permanent blue light Red light flashing Sensor on Sensor connected to mobile Low battery, recharge battery device...
  • Page 9: Click Patterns

    USER’S MANUAL CLICK PATTERNS ® To start the SUIFF PRO sensor, press the power button once. The upper smart led will start blin- king green, which indicates the device is on. To switch the SUIFF ® PRO sensor off, press the power button for three seconds until the upper smart led goes off.
  • Page 10: Connecting The Sensor With The App And Calibrating To Zero

    ® mobile device to start training. To pair your SUIFF PRO sensor with your mobile device: A. Go to DEVICE LIST (1) and find your SUIFF ® PRO sensor on the DEVICE LIST, select it and follow the instructions provided to connect and calibrate your SUIFF ®...
  • Page 11 ® PRO sensor with your mobile device, the sensor automatically carries out a quick and simple calibration process to zero. Please, to zero calibrate your device, make sure (as indicated in the SUIFF ® PRO App) you do not apply any traction force on the handles of the sensor as this could affect the accuracy of force measurements.
  • Page 12 USER’S MANUAL Manual Adjustment to Zero From the LIVE SESSION screen, you can readjust to zero whenever you like. That means that the sensor must show a force of 0 Newtons (N). It is basically the same process of calibrating to zero that is carried out automatically after connec- ting your device but, in this case, it is done manually.
  • Page 13: Automatic Switch-Off Feature

    0 with the sensor lying on a flat surface and applying no force to it. In this way, your sensor will also record its own weight (~120 g). However, since the SUIFF® PRO sensor is so light, this adjustment will hardly affect the exact levels of force measurements.
  • Page 14: Charging The Battery

    Connect the micro USB cable to your SUIFF ® PRO sensor. Connect the other end of the cable to a USB device or a USB power outlet. Make sure the charger is compatible with the SUIFF ® hardware. Recommended operating voltage 5 V...
  • Page 15: Bluetooth Recommendations

    Make sure you have at least 1 metre of free space around you so you can use the SUIFF ®...
  • Page 16: Safety Information

    Before doing an exercise, make sure the device is properly anchored to the accessories you are using and there is no risk to your health. ® • For a correct functioning, hold the SUIFF PRO sensor using its anchoring handles. ® ®...
  • Page 17 Do not hit your eyes, ears or any other part of your body with the device. • In case of developing a skin eruption or an allergic reaction, stop using the device and consult your dermatologist. Important! Before using the sensor, always check that the SUIFF ® • PRO carabiners and the fabric and seams of the EXPRESS SUIFF ®...
  • Page 18: Exercises And Recommendations

    • ® Read all the instructions before using the SUIFF PRO sensor and its accessories. Incorrect or excessive training may cause health problems. Use SUIFF ® equipment under professional supervision. • If you feel pain or vertigo while training, stop exercising and cool down. This is particularly important for those people who have had some health problem.
  • Page 19: How To Anchor The Suiff® Pro Sensor

    PRO carabiner (1). Your EXPRESS SUIFF® ® flat sling is now correctly secured to a fixed point. Finally, attach one of the handles of the SUIFF® PRO sensor (1) to the carabiner. Your sensor is now correctly attached to the fixed point.
  • Page 20 FLAT SLING ARE IN GOOD C O N D I - ® TION. WARNING! WHEN USING ACCESSORIES OR PARTS THAT ARE NOT INCLUDED IN THE SUIFF ® PRO KIT (HANDLES, RIGID STRAPS, SUSPENSION TRAINING SYSTEMS, ETC.) MAKE SURE THAT THE CARABINERS ARE IN GOOD CONDITION AND CAN SAFELY WITHSTAND THE TRACTION...
  • Page 21: Maintenance

    USER’S MANUAL MAINTENANCE In order to get the best performance of your SUIFF ® PRO sensor and its accessories, please follow the following care recommendations. ® Switch the SUIFF PRO sensor off before cleaning it. TYPE OF MAINTENANCE FREQUENCY RESPONSIBLE PROCEDURE ®...
  • Page 22: Problem Solving

    ® PRO mobile App indicates that there is a sensor connected (see DEVICE LIST in the App menu) but the sensor is not connected, make sure it is not ® connected to another SUIFF sensor nearby. • If your SUIFF ®...
  • Page 23 ® • If the sensor still cannot register the level of force or if you think the SUIFF sensor is measuring levels of force that are very different from usual, this may mean that the CALIBRATION TO ZERO, which happens right after connecting the sensor to your mobile device, was not done correctly.
  • Page 24: Waste Electrical And Electronic Equipments

    Please use appropriate household waste recycling centres to dispose of any electrical and elec- tronic equipment. Contact your council or seller to find your nearest household waste recycling centre. To the extent permitted by local norms and regulations, neither SUIFF ® nor its providers will in any event be liable for any direct, indirect, special, accidental or emerging damage.
  • Page 25: Disclaimer

    WARRANTY WARNING! FOR SAFETY REASONS, ONLY PERSONNEL AUTHORISED BY THE MANUFACTU- RER CAN DISASSEMBLE, FIX OR MODIFY ANY COMPONENT OF THE SUIFF PRO SENSOR ® OR OF ITS ACCESSORIES. FAILING TO DO THIS COULD DAMAGE THE PRODUCT AND THE USER.
  • Page 27: Customer Service

    USER’S MANUAL CUSTOMER SERVICE SUIFF ® ESTEL SL Can Noguera 19 Nau 1 I 2 08630 Abrera, Barcelona (España) support@suiff.com Follow us on: © 2018 SUIFF. All rights reserved.
