ITOH DENKI PM380LS User Manual

Brushless motor for light load conveying, motor driven roller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Brushless Motor for Light load conveying.
PM380/427LS
Motor Driven Roller
〈 User Manual 〉
Read this manual before use
Thank you for purchasing PM380/427LS (hereinafter referred
to as "this product").
＊Applicable driver is not included.
For more details about applicable driver(CBL-402F), please download the user
manual from our web page.
ITOH DENKI
https://itohdenki.co.jp/english/support/manual.html
ying.
Before using this product, carefully read this user manual and fully
understand the content.
Keep this document readily accessible for future reference.
Home > Download/Support > User Manual
ITOH DENKI
ITOH DENKI
ITOH DENKI
＊The photo is unit with V-pulley option.
Convey
POWER MOLLER
No.572

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PM380LS and is the answer not in the manual?

Questions and answers

Summary of Contents for ITOH DENKI PM380LS

  • Page 1 Keep this document readily accessible for future reference. For more details about applicable driver(CBL-402F), please download the user manual from our web page. Home > Download/Support > User Manual ITOH DENKI https://itohdenki.co.jp/english/support/manual.html ITOH DENKI ITOH DENKI ITOH DENKI POWER MOLLER No.572...

  • Page 2: Introduction

    Check and/or test by your own risk or your responsibility. About description In this manual, the Brushless Motor for Handling Light Loads “PM380/427LS” is described as MDR. of the product “PM380LS” and “PM427LS” are described separately, when needed.

  • Page 3: Procedures From Installation To Operation

    Procedures from installation to operation PM380/427LS  User Manual 2. Procedures from installation to operation Procedures from installation to operation Read this manual Start using only after you have understood the product’ s functions, and safety precautions. Advance preparation Prepare the 24 VDC power supply, such as DC power supply units.

  • Page 4: Table Of Contents

    INDEX PM380/427LS  User Manual INDEX Introduction …… 2 Procedures from installation to operation …… 3 Safety precautions …… 5 3-1. General precautions …… 7 3-2. Precautions on installation …… 9 3-3. Precautions on wiring …… 9 3-4. Precautions on maintenance and inspection ……  10 Advance preparation ……  11 Check Product ……  14 Installation ……  17...

  • Page 5: Safety Precautions

    3.  Safety precautions PM380/427LS  User Manual  3.     Safety precautions Refer to 5. Check Product (P.15) for parts name.
  • Page 6 Danger level PM380/427LS  User Manual 3. Safety precautions Danger level To prevent hazards to users and/or others, and/or damage to property in advance, we explain important precautions to be followed securely as below. ■ We categorize the degree of hazard and/or damage that may result if a user   disregards the description, and operates the product improperly, using and   explaining the following symbols.

  • Page 7: General Precautions

    General precautions PM380/427LS  User Manual 3. Safety precautions 3-1. WARNING General precautions Do not use the product near places subject to explosive, flammable gas, and/or corrosive atmosphere, and/or combustible materials. Failure to follow this could result in explosion, fire, electric shock and/or injury. When using the product in places where serious accidents and/or damage may possibly occur, install backup and/or fail-safe functions systematically.
  • Page 8 General precautions PM380/427LS  User Manual 3. Safety precautions 3-1. CAUTION General precautions Securely wire each cable to connection parts. Improper wiring could result in electric shock and/or malfunction. Do not turn on/off relays and/or contactors near power cables, signal cables, and/or driver cards. Failure to follow this could result in malfunction due to noise generation.

  • Page 9: Precautions On Installation

    Precautions on installation PM380/427LS  User Manual 3. Safety precautions 3-2. CAUTION Precautions on installation When handling, wear protective equipment, such as gloves. Since this product consists in large part of metal, careless handling could result in hands getting injured. Make sure to use the recommended tightening torque to tighten fixing screws of the mounting bracket.

  • Page 10: Precautions On Maintenance And Inspection

    Precautions on maintenance and inspection PM380/427LS  User Manual 3. Safety precautions 3-4. WARNING Precautions on maintenance and If any abnormalities are found, do not use this product inspection until the causes have been eliminated completely . Using this product with unattended abnormalities could result in not only damage to the devices, but also unexpected accidents.

  • Page 11: Advance Preparation

    4.  Advance preparation PM380/427LS  User Manual 4.  Advance preparation...
  • Page 12 The other devices need to be prepared PM380/427LS  User Manual 4. Advance preparation Wiring image AC power Controller,  such as PLC Breaker Safety circuit 24V DC  power supply unit CBL-402F CBL-402F ■ As for the sensor input, and input/output signals of driver cards, adopt the number of inputs/outputs based on operation. ■ The safety circuit includes the emergency stop equipment and magnet contactor.
  • Page 13 Emergency stop equipment PM380/427LS  User Manual 4. Advance preparation ③ Control devices Devices to control this product, such as PLC ④ Safety relay ⑤ MDR extension cables Necessary when the installing location of the MDR is far from that of the driver card. ■ CBL-402F：6-pin D shaped connector extension cable     ...

  • Page 14: Check Product

    5. Check Product PM380/427LS  User Manual 5.  Check Product...
  • Page 15 (Refer to P.16) Lable for Model number Cable Model description sample PM380LS−60−500−D−024−□ ① Type of MDR ・PM380LS … Tube diameter φ38mm ・PM427LS … Tube diameter φ42.7mm ② Nominal speed ・60m/min ③ Tube length ・200mm to 800mm ＊Spring loaded shaft on 219mm or shorter tube of Waterproof option is not available.
  • Page 16 Checking accessories PM380/427LS  User Manual 5. Check Product Checking appearance ①  Check any abnormalities, such as traces of scratches, dents, dirt, and/or corrosion (rust) on    MDR. ②  Confirm parts that are supposed to be included such as screws. ＊If any abnormalities are found, contact the supplier immediately. Checking accessories Confirm received mounting bracket was correct from following.

  • Page 17: Installation

    6. Installation PM380/427LS  User Manual  6.  Installation...

  • Page 18: Preparation For Install Mdr

    Preparation for install MDR PM380/427LS  User Manual 6. Installation 6-1.   Preparation for install MDR dimensions Standard 11.1 11.1 Hexagon shaped Hexagon shaped shaft on attaching shaft on Motor side side Tube length Motor cable length 11.1 V-ribbed pulley specifications 11.1 Hexagon shaped Hexagon shaped shaft on Motor shaft on attaching...

  • Page 19: Install The Mdr

    Install the MDR. PM380/427LS  User Manual 6. Installation 6-2.   ■ Use proper mounting brackets produced by ITOH DENKI to tighten shaft of Install the MDR MDR. If the shaft rattles or spins free inside the frame, it could result in cable damage and/or damage to the MDR.
  • Page 20 Install the MDR PM380/427LS  User Manual 6. Installation Pass the cable and shaft through hole M5 Toothed washer nut or of mounting bracket and mount the Stainless nut M5 mounting bracket to the frame. Cable ■ Loosen (remove) attached nut ( in fig) in advance ○...

  • Page 21: Maintenance/Inspection

    7. Maintenance/Inspection PM380/427LS  User Manual 7.  Maintenance/Inspection...
  • Page 22 MDR inspection PM380/427LS  User Manual 7. Maintenance/Inspection   MDR inspection MDR inspection Items to be checked Countermeasures References Screws and/or Nut of mounting Tighten Screws or Nut by proper P.20 bracket is loose. torque. There are errors (abnormal sound and/or operation failure) when Replace MDR, if necessary. −...

  • Page 23: Specifications

    Specifications PM380/427LS  User Manual Specifications...

  • Page 24: Product Specifications

    ＊Since the dedicated driver card CBL-402F has the degree of protection of IP20, do not install in     places subject to water.  (Refer to the CBL-402F User Manual) Size Weight Static load Thrust load 1.0kg 50kg 1.1kg 45kg 1.2kg 40kg PM380LS 1.3kg 35kg 1.4kg 30kg 1.5kg 25kg 1.6kg 20kg Product weight 30kg 1.3kg 75kg 1.4kg...
  • Page 25 ■ Headquarters: Itoh Denki Co.,Ltd. 1146-2, Asazuma-Cho, Kasai, Hyogo 679-0105 Phone: +81  ( 0 ) 790 47 1225     Fax: +81  ( 0 ) 790 47 1328   www.itohdenki.co.jp ■ Europe, Middle East, Africa: Itoh Denki Europe SAS Phone: +33  ( 0 ) 4 50 03 09 99     Fax: +33  ( 0 ) 4 50 03 07 60   www.itoh-denki.com ■ North & South America: Itoh Denki USA, Inc Phone: +1 570 820 8811     Fax: +1 570 820 8838  ...
