Summary of Contents for Burmester 948
- Page 2 Dear Audiophile, Thank you for choosing this Burmester audio component. We sincerely appreciate your trust in us. You have purchased a unit which excels in musical fidelity and combines uncompromising manufacturing quality with technical innovation and the highest degree of operating flexibility.
-
Page 3: Table Of Contents
C O N T E N T S THE CONCEPT UNPACKING AND SETTING UP FUNCTIONAL OVERVIEW OF FRONT AND REAR PANEL CONNECTIONS OPERATING CONTROLS ERROR PROTECTION GENERAL INSTRUCTIONS TECHNICAL SPECIFICATIONS... -
Page 4: The Concept
CAUTION: The power conditioner 948 is very heavy. To avoid injury during unpacking and set-up, this should only be done by persons who are accustomed to handling such weights. The power conditioner 948 is shipped inside a plastic protective cover. Make sure that children do not play with it to avoid the danger of suffocation. -
Page 5: Functional Overview Of Front And Rear Panel
(18) AC outlet MAINS OUT 3 (13) AC mains switch (19) Remote input terminal to turn (14) AC mains terminal the power conditioner 948 on remotely (15) AC outlet MAINS OUT 2 (20) AC outlet MAINS OUT 4 (16) AC outlet MAINS OUT 2 (21) AC outlet MAINS OUT 4 * Picture shows European version, AC outlets may vary for other countries. -
Page 6: Connections
CAUTION: Before connecting the unit please check, if the input voltage of the 948 is equal to the local voltage of your wall outlet. Make sure, the ground lead in your power outlet is working correctly. A missing or faulty ground is extremely dangerous! In case of doubt, contact a licensed electrician. - Page 7 The remote input terminal (19) is located on the rear panel beneath the AC mains terminal (14). This input offers the possibility to switch the 948 on or off from your preamp or D/A converter. To use this function, the remote in terminal of the 948 has to be connected with the remote output terminal of the preamp or D/A converter with a suitable cable.
-
Page 8: Operating Controls
Pressing the display button (9) again, turns the display back on. ERROR PROTECTION The power conditioner 948 has a sophisticated protection circuitry which is designed to protect the unit in case of a failure. Overheating In the event, that the unit exceeds the maximum allowable operating temperature, the overheat protection automatically switches off the DC compensation. -
Page 9: General Instructions
The fuses are located inside the unit and should be changed only by a qualified technician. Voltage Check before operating the 948 to see if the voltage setting shown on the back panel below the AC mains input conforms to voltage of your household power supply. Any change should only be done by an expert. -
Page 11: Technical Specifications
TECHNICAL SPECIFICATIONS Dimensions Width x Height x Depth 482 x 155 x 400mm (19.0 x 6.1 x 15.7 inches) Weight 13kg (28.6 lbs) Mains voltage and fuses for 200V - 240V 50/60Hz 2 x slo 1A E ; 3 x slo 250mA E for 100V - 127V 50/60Hz 2 x slo 3.15A E ;...
