Duraline Systems DuraSprayer Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DuraSprayer and is the answer not in the manual?

Questions and answers

Related Manuals for Duraline Systems DuraSprayer

Summary of Contents for Duraline Systems DuraSprayer

  • Page 3 DuraSprayer™ OPERATING MANUAL Thank you and Congratulations on your choice of the DuraSprayer™, a revolutionary disinfectant delivery system that uniquely combines the technology of foggers, misters, refillable sprayers and prepackaged aerosols. This refillable unit eliminates the need for costly prepackaged aerosols by mechanically generating the most optimum-sized, uniform disinfectant particles.

  • Page 4: Table Of Contents

    Table of Contents OPERATING INSTRUCTIONS Page 1 DIAGNOSIS AND FIELD SERVICE Page 8 DISINFECTANTS Page 11 PARTS AND SERVICE Page 14 EQUIPMENT SPECIFICATIONS Page 15 WAND Parts - detailed Page 16 Item#’s, Product Codes and Descriptions Page 17 CABINET Parts - detailed Page 18 Item #’s, Product Codes and Descriptions Page 19...

  • Page 5: Operating Instructions

    OPERATING INSTRUCTIONS Handle with care. Do not place the unit where vibration and surface conditions would allow it to fall. Keep the unit on the ground when in use. 1. Always wear personal protective equipment (PPE) When filling these units always wear protective eyewear and protective gloves.
  • Page 6 Check with manufacturers for details on certification. 3. Filter Disinfectant and Fill Tank. Remove Fill Cap. Filter disinfectant by pouring slowly into fill neck and through the in-tank filter to remove any debris that may clog or damage the DuraSprayer™ equipment. Page 2...
  • Page 7 Turning the cap clockwise, hand-tighten until firmly secured. 5. Plug in / Turn on Power. Plug the DuraSprayer™ into a three-prong grounded, 110/115-volt electrical source. Use a three-prong grounded heavy-duty extension cord, not longer than 50 feet, when operating this unit (Cord Not Included).
  • Page 8 Contact your chosen distributor information on disinfectants currently labeled for use in equipment such as DuraSprayer™ A. Apply disinfectant according to label instructions. B. Position the applicator tip on desired target. C. Depress the trigger to apply disinfectant. Page 4...
  • Page 9 The compressed air is environmentally safe and much more effective than chemical propellants. The continuous free flowing air stream allows for deeper penetration of the target areas. The comfortable precision wand is balanced, easy to use, and easy to maintain. This unique wand is based on a common industry design making it simple to repair with easy access to replacement parts.
  • Page 10 The aerosols that you’ve probably used in the past were driven by propellant. Therefore, you saw larger particles and most of the material DuraSprayer™ that that of the propellant. The utilizes no propellant. All you are seeing is the disinfectant that has been sheared into micron sized particles.
  • Page 11 13. Transporting the Unit. Transport the DuraSprayer™ in an upright position. Take care not to damage the Integrated Crack & Crevice Tip by positioning the Red Tip Protector Cap over tip of wand.

  • Page 12: Diagnosis And Field Service

    DIAGNOSIS AND FIELD SERVICE 1. The unit is running and air is flowing from the tip, but no chemical aerosol is being produced. A. Make sure the tank contains disinfectant. B. Check 15’ Twin Tubing for kinks, crimps, twists, or other factors that would obstruct chemical flow to the wand.
  • Page 13 Also, be sure that all orifices in the fluid cap are free of debris. Replace tip assembly and follow operating instructions to generate aerosol. F. If no liquid flow or pin stream, inspect fluid cap by removing tip and removing any debris from all orifices. 2.
  • Page 14 5. Unit is turned on but motor just hums and does not start. If none of these solutions corrects your problem, there may be something more serious wrong with the unit. For additional technical assistance please contact Duraline Systems, Inc. Help Desk at 877-561- 0500. Page 10...

  • Page 15: Disinfectants

    Refer to the disinfectant label for specific instructions and other precautions. 2. Observe Label Directions. Do not operate the DuraSprayer™ with disinfectants that are not labeled for aerosol, fog, or mist applications. Read the disinfectant label to determine if the disinfectant is EPA-approved for use in this type of equipment.
  • Page 16 • Everyone in the treatment area must wear an approved respirator during treatment and when re-entering a treated area when the aerosol may still be present. • Turn off all pilot lights or sources of open flame. Ventilation systems and air moving systems should be turned off. Appliances that routinely create high heat should be turned off.
  • Page 17 Call Today: 1-877-561-0500 we accept: SERVICE If the DuraSprayer™ requires factory service be sure to drain the tank, back flush the wand and hose, and pack the unit in its original carton and packing material for shipping. If the original carton is not available, pack the unit a durable box and protect the unit as best you can.

  • Page 18: Parts And Service

    DuraSprayer™ SPECIFICATIONS 13.5” Length 6.75” Width 7.00” Height Weight (empty) 16 lbs. Weight (full) 17.5 lbs. Shipping Weight 21 lbs. Tank Capacity 28 oz. (Only fill to 20 oz.) Operating Pressure (air) 20 psi Operating Pressure (liquid) 9-20 psi Motor 110 v AC, 60 Hz, 2.5 amps, 275 watts...

  • Page 19: Equipment Specifications

    DuraSprayer™ Wand - 12” or 18” Page 15...

  • Page 20: Parts - Detailed

    ITEM DESCRIPTION 12” or 18” Wand Complete 3000112 or 3000118 300183 Integrated Stainless Extended C & C Tip 30005 Stainless Fluid Cap “O” Ring for Fluid Cap 30006 30007 Exit Hose Shank 30008 Adapter Body 12” or 18” Poly Tubing for Wand 30009-12 or 18 8010009 Teflon Seat...

  • Page 21: Item#'S, Product Codes And Descriptions

    DuraSprayer™ Details Page 17...

  • Page 22: Parts - Detailed

    ITEM DESCRIPTION 300029A Aluminum Cabinet 300029B Aluminum Tank for Cabinet Cabinet Panel – 1 300029C 300029D Cabinet Panel - 2 “D” Ring 300030 3000313 Compressor 8010032 Flanged Electrical Inlet 8010035 Plastic Hose Clamp 300034 Compressor Mount / Isolator 300133 Compressor Intake Air Filter 1/8”...

  • Page 23: Item #'S, Product Codes And Descriptions

    DuraSprayer™ Details Page 19...

  • Page 24: Parts - Detailed

    ITEM DESCRIPTION 300064 Drop in Tank Filter #10 Sheet Metal Screws – Not Shown 300071 Shoulder Strap – Not Shown 300073 Diaphragm for Compressor – Not Shown 8010068 “O” Ring for Tank Cap 300070 300080 Shipping Box (w / inserts) - Not Shown 8010075 Manifold Complete 1/4”...

  • Page 25: Item #'S, Product Codes And Descriptions

    Duraline Systems, Inc.’s obligation under this warranty policy is limited to the repair or replacement of the unit. All returns will be tested per Duraline Systems, Inc. factory criteria. Units found not defective, under the terms of this limited warranty, are subject to the charges paid by the returnee.
  • Page 28 Duraline Systems, Inc. 39 Western Highway West Nyack NY 10994 (877) 561-0500 Phone (845) 353-2095 Fax www.duralinesystems.com Copyright© 2015 Duraline Systems, Inc.
