Summary of Contents for artisan HP 700 Series

  • Page 1 Artisan Technology Group is your source for quality new and certified-used/pre-owned equipment SERVICE CENTER REPAIRS WE BUY USED EQUIPMENT • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell your excess, underutilized, and idle used equipment at our full-service, in-house repair center We also offer credit for buy-backs and trade-ins •...
  • Page 2 HP 9000 Series 700 Workstations Technical Reference Manual Model 712 (SYSTEM) Printed in USA January, 1994 Revision 1.0 Downloaded from www.Manualslib.com manuals search engine...
  • Page 3 ______________________________________________________________________________ Notices Information in this document is subject to change without notice. Hewlett–Packard makes no warranty of any kind about this manual, including, but not limited to, the implied warranties of merchantablility and fitness for a particular purpose. Hewlett–Packard shall not be liable for errors contained herein or direct, indirect, special, incidental or consequential damages about the furnishing, performance, or use of this material.

  • Page 4: Printing History

    Printing History New Editions of this manual incorporate all material updated since the previous edition. Update packages may be issued between editions and contain replacement and additional pages to be merged into the manual by the user. The manual printing date and part number indicate its current edition. The printing date changes when a new edition is printed.
  • Page 5 TABLE OF CONTENTS Chapter contents Downloaded from www.Manualslib.com manuals search engine...
  • Page 6 Downloaded from www.Manualslib.com manuals search engine...
  • Page 7 Downloaded from www.Manualslib.com manuals search engine...
  • Page 8 LIST OF TABLES Downloaded from www.Manualslib.com manuals search engine...
  • Page 9 viii Downloaded from www.Manualslib.com manuals search engine...
  • Page 10 LIST OF FIGURES Downloaded from www.Manualslib.com manuals search engine...

  • Page 11: General Information

    General Information Product Overview Features Functionality Operating system HP–UX 9.03 (or later) PA–RISC PA7100–LC Model 712/60 Model 712/80 Frequency 60 MHz 80 MHz Performance SPECint92 58.1 84.3 SPECfp92 122.3 X11Perf Cache 64 KB 256 KB Time source Battery–backed Real–Time Clock Memory 4 slots 16 MB minimum required...
  • Page 12 Internal External System Board Graphics Product No. Type Resolution Refresh Rate HP A2882A 11.8–inch Flat panel 1024 by 768 75 Hz HP D1196A 15–inch Color 1024 by 768 70 Hz HP A2287A 17–inch Color 1024 by 768 75 Hz HP A4032A 17–inch Color 1280 by 1024 Multi–Mode...
  • Page 13 System Board Interfaces PS/2 Keyboard and Mouse Interfaces HP Parallel Interface RS–232 Serial Interface. Small Computer Systems Interface (SCSI–2) Ω Local Area Network Interface. Supported AUI LAN Adapters and Devices LAN Adaptor Network Devices HP 28641B ThinLAN Transceiver HP 28692A ThinLAN Hub Plus HP 28673A 10:10 LAN Bridge HP 28683A Fiber Optic Transceiver HP 30241A 10Base4 ThickLAN MAU...
  • Page 14 Audio Interface Ω µ Ω Ω Ω Caller ID Call Waiting Conference Calling Data Rate conversion and mixing Call Recording and Voice Mail A multitude of DTMF–based applications Downloaded from www.Manualslib.com manuals search engine...
  • Page 15 HP–UX HP–UX Operating Systems and Languages Operating system: HP–UX 9.03 or later. HP–UX complies with the UNIX System V Interface Definition X/Open and POSIX Specifications and will be fully compliant with Operating Systems Foundation (OSF) Languages C/ANSI C FORTRAN 9000 Pascal HP C++ C++ Developer...
  • Page 16 Manual Title Part Number Service Handbook; HP 9000 Model 712 Workstations A2615–90602 Servicing Hewlett–Packard Workstation Monitors 5960–1511 Downloaded from www.Manualslib.com manuals search engine...
  • Page 17 Manual Title Part Number HP Apollo 9000 Series 700 Model 712 Owner’s Guide A2615–90616 HP 9000 Model 712 Hardware Installation Guide A2615–90600 HP A2655A CD–ROM Drive Installation Guide A2615–90603 HP A4021A DDS–Format Tape Drive Installation Guide A2615–90604 HP A4020A SCSI Disk Installation Guide A2615–90605 HP A4068A Floppy Disk Drive Installation Note A2615–90606...
  • Page 18 Approvals With Internal Mass Storage Temperature Altitude Operating: 3050m (10,000 ft) Non–operating: 4600m (15,000 ft) Shock Vibration Noise Output Downloaded from www.Manualslib.com manuals search engine...
  • Page 19 Product Configuration MTBF Model 712 16 MB, no mass storage 9.30% 10.75 years Model 712 16 MB, with mass storage 13.3% 7.5 years Downloaded from www.Manualslib.com manuals search engine...
  • Page 20 Mechanical Downloaded from www.Manualslib.com manuals search engine...
  • Page 21 Description Drawing Number System Board Blank D–A2263–66510–51 System Board Schematic D–A2263–66510–40 Video RAM Board Blank B–A2263–26520–51 Teleshare Board Blank D–A2263–66530–51 Token Ring Board Blank D–A2263–66531–51 Embossed Nameplate B–A2263–84005–10 Downloaded from www.Manualslib.com manuals search engine...

  • Page 22: System Board

    System Board BootRom Version xxx.x Memory Size: xx MB Press <ESCAPE> to stop boot sequence. Downloaded from www.Manualslib.com manuals search engine...
  • Page 23 PROCESSOR BOARD Memory Slot Memory Slot Memory Slot Memory Slot Power Supply SCSI Drive Flexible Disk Drive Downloaded from www.Manualslib.com manuals search engine...
  • Page 24 LAN Adaptor Network Devices HP 28641B ThinLAN Transceiver HP 28692A ThinLAN Hub Plus HP 28673A 10:10 LAN Bridge HP 28683A Fiber Optic Transceiver HP 30241A 10Base4 ThickLAN MAU Function Data Type: IEEE 802.3, Ethernet 1.0 Data rate: 10 Mbits/second Connector types: AUI LAN –...
  • Page 25 Function Data Type: RS–232C Baud rate: 50 to 454k Up to 227k input w/handshaking Word size: 5 to 8 bits Parity Odd, even, one, zero, none Device Type: 1 per interface connector Connector Type: 9–pin male D–sub connector Downloaded from www.Manualslib.com manuals search engine...
  • Page 26 Function Data Type: Centronics, NACK and BUSY handshakes Data rate: >400 Kbytes/second with DMA 250 Kbytes/second sustained Device Limit: Connector Type: 25–pin female DB25 connector; IBM PS/2 6 bit resolution. Sampling rate up to 48 KHz. 1/8–in. connectors for the mono microphone, stereo line in, and stereo headset out. Downloaded from www.Manualslib.com manuals search engine...
  • Page 27 Application Unit or Mass Storage Device Recommended Bus Address High Use/Priority Root Hard Disk Drive Most Used Hard Disk Drive Least Used Hard Disk Drive Other devices DDS Tape Drives Medium Use/Priority CD ROM Disk Drives Optional Use (the 712 will not support a Low Use/Priority SCSI Floppy) Function...
  • Page 28 Downloaded from www.Manualslib.com manuals search engine...
  • Page 29 Figures 2–3 and 2–4 show the system board dimensions and keepouts. Downloaded from www.Manualslib.com manuals search engine...
  • Page 30 1.208 MAX CPU Heatsink Dimensions in inches Downloaded from www.Manualslib.com manuals search engine...
  • Page 31 Downloaded from www.Manualslib.com manuals search engine...
  • Page 32 Pin No. Signal Pin No. Signal Pin No. Signal EPR_D[2] Ground GSC[17] Ground ADDV_L Ground Spare2 EGRANT_L GSC[21] Ground EREQUEST_L GSC[22] Spare3 GSC[23] Ground LS_L GSC[6] INTERRUPT_L GSC[27] GSC[7] ART2EXP GSC[28] GSC[8] Ground GSC[29] SYNC4H Ground GSC[12] Ground TYPE[3] GSC[13] SYNC4L TYPE[2] GSC[14]...
  • Page 33 Pin No. Signal Pin No. Signal Pin No. Signal CFSYNC AUD_SDIN p12V Ground Ground AUD_RESET_L CSDOUT AUD_FSYNC Ground Ground Ground AUD_SDOUT TSPARE Ground PWR_RST_L AUD_SCLK AUD_ALEX_HER CSCLK Ground DATA_ENABLE AUD_DNC CSDIN Ground Ground Ground Pin No. Signal Pin No. Signal Pin No.
  • Page 34 Pin No. Signal Pin No. Signal Pin No. Signal Analog Ground (No Connect) Green Analog Ground (No Connect) Blue Analog Ground Horizontal Sync Reserved (No Connect) Vertical Sync Digital Ground Digital Ground (No Connect) Pin No. Signal Pin No. Signal Pin No.
  • Page 35 Pin No. Signal Pin No. Signal Pin No. Signal Ground Ground Ground TK00 Ground Ground Ground Ground DRTN Ground Ground Ground Ground Ground Ground Ground Ground Downloaded from www.Manualslib.com manuals search engine...
  • Page 36 Phone number for ordering new or exchange parts 1–800–227–8164. Downloaded from www.Manualslib.com manuals search engine...
  • Page 37 Ref. No. Exchange Part Number Description A2263–69510 CPU, 60 MHz A2263–69511 CPU, 80 MHz A2577–69001 4 MB SIMM A2578–69001 8 MB SIMM A2576–69001 16 MB SIMM A2575–69001 32 MB SIMM A2084–69002 1.0 GB Disk A2084–69001 525 MB Disk A2615–69001 260 MB Disk Ref.
  • Page 38 Downloaded from www.Manualslib.com manuals search engine...

  • Page 39: Card Specifications

    Expansion Slot Cards Card Specifications HP A4011A HP Token Ring/9000 Card Description The HP A4011A HP Token Ring/9000 Card (ITR) is a industry–standard IEEE 802.5. Features Physical Specifications Environmental Specifications Power Consumption (Max.) Ordering Information Downloaded from www.Manualslib.com manuals search engine...
  • Page 40 HP A4012A Teleshare Card Description Features **Note: Some of the features listed such as Caller ID and DTMF–based applications might not be supported by all international phone systems. Detailed Information Physical Specifications Downloaded from www.Manualslib.com manuals search engine...
  • Page 41 Environmental Specifications Power Consumption (Max.) 6.5 Watts Ordering Information Downloaded from www.Manualslib.com manuals search engine...
  • Page 42 HP A4013A Serial Card Description Features Physical Specifications Environmental Specifications Power Consumption (Max.) Pin and Signal Assignment Pin No. Signal Pin No. Signal Pin No. Signal Ground Ordering Information Downloaded from www.Manualslib.com manuals search engine...
  • Page 43 Recommended Cables: Downloaded from www.Manualslib.com manuals search engine...
  • Page 44 HP A4014A LAN/Serial Card Description Features LAN–AUI Pin No. Signal Pin No. Signal Pin No. Signal CI–S CO–A CI–A CO–S DO–A CI–B CO–B DI–S DO–B Ground DI–A DO–S Ground DI–B Serial Software selectable baud rate Interrupt capability through status or modem signal lines 9–pin male D–sub connector Pin No.
  • Page 45 Environmental Specifications Power Consumption (Max.) 5.0 Watts Ordering Information Recommended Cables: Downloaded from www.Manualslib.com manuals search engine...
  • Page 46 HP A4015A X.25/Serial Card Description Features X.25 X.25 supports 1.2 to 19kbs. X.25 supports implementation of the LAP–B data–link protocol Pin No. Signal Pin No. Signal Pin No. Signal Prot. Ground Not Connected Not Connected Not Connected Not Connected Not Connected Not Connected Not Connected Not Connected...
  • Page 47 Environmental Specifications Power Consumption (Max.) Ordering Information Recommended Cables: Downloaded from www.Manualslib.com manuals search engine...
  • Page 48 HP A2878A 2nd Monitor Card Description Features 1024 by 768 by 8 bit color at 60 Hz. to 75 Hz. 1280 by 1024 by 8 bit color at 60 Hz. to 72 Hz. 15 pin VGA style connection NGLE compatible. Support of the following VESA timings: 1280 by 1024 at 75 Hz.
  • Page 49 Power Consumption (Max.) Ordering Information Recommended Cables: Downloaded from www.Manualslib.com manuals search engine...

  • Page 50: Internal Mass Storage

    Internal Mass Storage SCSI Bus Application Unit or Mass Storage Device Recommended Bus Address High Use/Priority Root Hard Disk Drive Most Used Hard Disk Drive Least Used Hard Disk Drive Other devices DDS Tape Drives Medium Use/Priority CD ROM Disk Drives Optional Use (the 712 will not support a Low Use/Priority...

  • Page 51: Mass Storage Devices

    Mass Storage Devices HP A4067A 1 Gbyte Hard Disk Drive Capacity Formatted: 1,050,347,520 Bytes Performance Seek Times Track to track: 2.5 ms Average: 10 ms Maximum: 25 ms Disk Speed/Rotational Latency Average Latency: 5.56 msec or less Disk Speed: 5400 RPM minimum Data Transfer Rates Internal (disk) Burst:...
  • Page 52 HP A4066A 525 Mbyte Hard Disk Drive Capacity Formatted: 525,000,000 Bytes Performance Downloaded from www.Manualslib.com manuals search engine...
  • Page 53 Environmental Requirements HP A4065A 260 Mbyte Hard Disk Drive Capacity Performance Downloaded from www.Manualslib.com manuals search engine...
  • Page 54 Environmental Requirements Downloaded from www.Manualslib.com manuals search engine...
  • Page 55 HP A4068A 3.5–in. Flexible Disk Drive(PC Interface) Capacity and Performance Feature Low Density High Density High Density Data Capacity: Unformatted: 1.0 MB 2.0 MB 1.6 MB Formatted 720KB 1.474 MB 1.228 MB @ 9 sectors/track @18 sectors/track @ 15 sectors/track Internal Data Buffer: 31KB 31 KB...

  • Page 56: Power Requirements

    Electrical Information Power Requirements Voltage 260 MB 525 MB 1 GB Floppy Drive +5 V .75A .75A 1.0A 0.3A ave. +12 V .65A 0.7A Downloaded from www.Manualslib.com manuals search engine...
  • Page 57 Connector Pinouts Pin No. Signal Description DB[0] Data Bus (LSB) DB[1] Data Bus DB[2] Data Bus DB[3] Data Bus DB[4] Data Bus DB[5] Data Bus DB[6] Data Bus DB[7] Data Bus (MSB) DB[P] Data Bus Parity Termpwr Terminator Power Reserved Not Used (GND) Indicates message available for drive Not Used (GND)

  • Page 58: External Mass Storage

    External Mass Storage SCSI Bus Application Unit or Mass Storage Device Recommended Bus Address High Use/Priority Root Hard Disk Drive Most Used Hard Disk Drive Least Used Hard Disk Drive Other devices DDS Tape Drives Medium Use/Priority CD ROM Disk Drives Optional Use (the 712 will not support a Low Use/Priority...
  • Page 59 Mass Storage Devices HP A2657A 1 Gbyte Hard Disk Drive Capacity Formatted: 1,050,347,520 Bytes Performance Environmental Requirements Downloaded from www.Manualslib.com manuals search engine...
  • Page 60 HP A2655A CD ROM Disk Drive Capacity Performance Downloaded from www.Manualslib.com manuals search engine...
  • Page 61 Environmental Requirements Reliability and Life Data Downloaded from www.Manualslib.com manuals search engine...
  • Page 62 HP A2656A DDS Tape Drive Capacity Data Capacity: 2 GB; 90 meter (295 feet) tape Performance Environmental Requirements Downloaded from www.Manualslib.com manuals search engine...
  • Page 63 Cassette Drive Meaning Cassette (un)loading Cassette loaded/online Read/Write States Cassette loaded/Activity Cassette loaded/offline Cassette (un)loading Write– Cassette loaded/online Protect Cassette loaded/Activity States Cassette loaded/offline Media wear (caution) High humidity/No terminator Error States Self–test (normal) Self–test (failure) Meaning Green Amber Pulse Green Pulse Amber Downloaded from www.Manualslib.com...
  • Page 64 Model 712 Packaging Chassis Downloaded from www.Manualslib.com manuals search engine...

  • Page 65: Shipping Carton

    Shipping Carton Box Specifications Carton Markings and Placement 21” 1” or more System Processor 1.25” as much as 11” 11” .25” System Processor 1” 6.2” 12” .125” 7.5” 1” 4.25” 1.5” .5” 1” Downloaded from www.Manualslib.com manuals search engine...
  • Page 66 Downloaded from www.Manualslib.com manuals search engine...

  • Page 67: Functional Information

    Power Supply Functional Information Power Supply Specifications Voltage Current +5.1 V dc 11.5 A +12.0 V dc 1.0 A +3.3 V dc 1.0 A +5.0 V dc (SCSI) 0.5 A Input Power 110 W Max Input Input Voltage (115V range) 90–132VAC Input Current (115V range) 2.7A RMS max.

  • Page 68: Led Indicator

    Description Max Power (Watts) CPU* Cache* Buffers* Graphics* Core I/O and PDH* SCSI Term Power* (internal) Audio* Active RAM (32 Mbytes)* Standby RAM* System board Total 712/60 23.6 System board Total712/80i 29.8 –––––––––––––––––––––––––––––– ––––––––––– Expansion Slot Keyboard & Mouse Disk Drive (One 3.5 in) 13.4 Flexible Disk Drive SCSI Term Power (external)

  • Page 69: Electrical Information

    Electrical Information Connector Pinouts Terminal Voltage/Signal Wire Gauge Color Load Current START_PWR_DOWN_L white POWER_ON_L blue +5 Volt orange Ground black +12 Volt 0.15 Ground black +5 Volt orange +3.3 Volt yellow +5 Volt (SCSI) violet Ground black +5 Volt orange Terminal Voltage/Signal Wire Gauge...

  • Page 70: Parts List

    Parts List Ref. No. New Part Number Description Notes 0950–2356 Power Supply A2263–62003 A2263–40002 Power Supply Cover Downloaded from www.Manualslib.com manuals search engine...
  • Page 71 Monitors Monitor Control Location and Physical Dimensions The figures (8–1 thru 8–5) and tables (8–1 thru 8–5) in this chapter provide the monitor control location and physical dimensions for the following monitors: Downloaded from www.Manualslib.com manuals search engine...
  • Page 72 1 Power ON/OFF Button 2 Power LED 3 Brightness Front Toggle Rear Video Cable Power Cable Downloaded from www.Manualslib.com manuals search engine...
  • Page 73 Height 35.6 cm, 27.4 cm w/o stand (14.8 in) Width 33 cm (13 in) Depth 15.2 cm, 7.6 cm w/o stand (6 in, 3 in) Weight 5.5 Kg (12 lb) External Power Module 383.5 gr. (13.5 oz.) Downloaded from www.Manualslib.com manuals search engine...
  • Page 74 1 Degauss Front 2 Geometry 3 Width 4 Height 5 Horizontal Position 6 Vertical Position 7 Brightness 8 Contrast 9 Power–On LED 10 Power ON/OFF Button Rear Video Cable Power Connector Downloaded from www.Manualslib.com manuals search engine...
  • Page 75 Height 36.6 cm (14.4 in) Width 35.4 cm (13.9 in) Depth 40.0 cm (15.8 in) Weight 14.0 Kg (31 lb) Downloaded from www.Manualslib.com manuals search engine...
  • Page 76 1 Brightness 2 Contrast 3 Power ON/OFF Button Front Rear Video Connector Power Connector Downloaded from www.Manualslib.com manuals search engine...
  • Page 77 Height 43.8 cm (17.2 in) Width 40,8 cm (16.0 in) Depth 44.2 cm (17.4 in) Weight 21.0 Kg (46.2 lb) Downloaded from www.Manualslib.com manuals search engine...
  • Page 78 Downloaded from www.Manualslib.com manuals search engine...
  • Page 79 Height 41.4 cm (16.3 in) Width 40.6 cm (16 in) Depth 45.0 cm (17.7 in) Weight 22 Kg (48.4 lb) Downloaded from www.Manualslib.com manuals search engine...
  • Page 80 1 V–STAT 2 H–STAT 3 V–CENT 4 Brightness 5 Contrast 6 Power–On LED Front 7 Power ON/OFF Button RGB Cable Rear Connectors Power Connector Connect video cable to bottom three RGB connectors. Downloaded from www.Manualslib.com manuals search engine...
  • Page 81 Height 47.4 cm (18.7 in) Width 48.0 cm (18.9 in) Depth 50.5 cm (19.9 in) Weight 32.5 Kg (71 lb) Downloaded from www.Manualslib.com manuals search engine...

  • Page 82: Keyboard Layout

    Keyboard Layouts Dimensions The Model 712 workstation supports 13 different language keyboards. Each keyboard comes with a 7.5 foot mini–DIN style cable. The physical characteristics are as follows: Length: 467 mm (18.4 in) Width: 184 mm (7.25 in) Height: 48 mm (1.9 in) Weight: 1.09 kg (2.4 lb) Japanese version:...
  • Page 83 Downloaded from www.Manualslib.com manuals search engine...
  • Page 84 Downloaded from www.Manualslib.com manuals search engine...
  • Page 85 Downloaded from www.Manualslib.com manuals search engine...
  • Page 86 Downloaded from www.Manualslib.com manuals search engine...
  • Page 87 Downloaded from www.Manualslib.com manuals search engine...
  • Page 88 Downloaded from www.Manualslib.com manuals search engine...
  • Page 89 Downloaded from www.Manualslib.com manuals search engine...
  • Page 90 Downloaded from www.Manualslib.com manuals search engine...
  • Page 91 Downloaded from www.Manualslib.com manuals search engine...
  • Page 92 Downloaded from www.Manualslib.com manuals search engine...
  • Page 93 Downloaded from www.Manualslib.com manuals search engine...
  • Page 94 Downloaded from www.Manualslib.com manuals search engine...
  • Page 95 Downloaded from www.Manualslib.com manuals search engine...
