Summary of Contents for OMEGA AIR AirWatt
- Page 1 Installation and operating manual AirWatt External Heat Recovery Please read the following instructions carefully before installing indicator into service. Trouble free and safe operating of the unit can only be guaranteed if recommendations and conditions stated in this manual are respected.
- Page 2 AirWatt - Installation and operating manual Components Part 1 Plate chiller 2 Thermostat head 3 Temperature sensor (input/output) 4 Connection oil/water...
-
Page 3: Technical Data
AirWatt - Installation and operating manual Technical data MAXIMUM COMPRESSOR SIZES CONNECTIONS HEAT DIMENSIONS WEIGHT POWER CAPACITY OLJE VODA [kW] [kW] C[mm] [kg] [mm] [mm] 15 - 22 AirWatt 22 G 1'' 12 - 17,5 1/4” 26 - 37 AirWatt 37 G 1'' 20,8 –... -
Page 4: General Safety Instructions
AirWatt - Installation and operating manual Introduction External heat recovery system AirWatt is intended for professional use. This user manual provides all necessary information for dimensioning, installation, safe operation and maintenance. It should be read thoroughly and carefully. Obey all safety instructions. -
Page 5: Principle Of Operation
Recovered heat may represents significant savings and reduced load on environment. Principle of operation AirWatt has two separate piping systems, through which flows water or oil. Device is connected to oil circuit in compressor. Inside built in plate heat exchanger oil cools and water gains heat. - Page 6 AirWatt - Installation and operating manual Connection Place AirWatt on flat surface. Connect oil circuit and water installation on the device as demonstrated on the picture below. Oil circuit installation requires special interference with compressor construction. Only authorized personnel are allowed to install the unit.
-
Page 7: Maintenance
AirWatt - Installation and operating manual Maintenance • Once a month check the device for possible defects. • All maintenance work must be performed by qualified and trained professional. • Before any work on installation, turn of the compressor, lock the power supply and depressurize the system. - Page 8 AirWatt - Installation and operating manual Settings Change of target temperature 1. In order to change the target flow temperature, press the left or right button (A) 2. Press the middle button shortly to confirm new target temperature (B). Advanced Settings: 1.
- Page 9 AirWatt - Installation and operating manual Maximum Flow Temperature 1. To change the maximum flow temperature press middle button the joystick for 5 seconds to reach advanced settings. 2. Choose menu “Max” by pressing the middle button OK. 3. Decide the maximum flow temperature by pressing the left or right button OK.
