DIGITAL MEDIA PLAYER
USER MANUAL
SMPV-2GBUB
PLEASE READ THIS OPERATING MANUAL COMPLETELY BEFORE OPERATING THIS UNIT
AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE

Advertisement

loading

Related Manuals for Audiovox SMPV-2GBUB

Summary of Contents for Audiovox SMPV-2GBUB

  • Page 1 DIGITAL MEDIA PLAYER USER MANUAL SMPV-2GBUB PLEASE READ THIS OPERATING MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE...
  • Page 2 ® DEAR JENSEN CUSTOMER Selecting fine audio equipment such as the unit you've just purchased is only the start of your musical enjoyment. Now it's time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association's Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level.
  • Page 3 The serial number of this product is found on the unit. You should note the serial number of this unit in the space provided as a permanent record of your purchase to aid in identification in the event of theft of loss. Model Number: SMPV-2GBUB Serial Number:...
  • Page 4 NOTE Do not throw the product into fire to avoid danger of explosion. Do not immerse into water or get soaked since the battery charging function will be lost. Please fully charge the battery before using this device. When charging the battery the Power Switch should be in the ON position. Do not charge rechargeable batteries longer than 4 hours.
  • Page 5 malfunction to your PC and Player. Do not plug in an earphone or audio cable during file downloading. Downloading can be delayed if there are too many folders or files. The order of music files displayed on the Windows Explorer is not the order of actual music playback.
  • Page 6 FEATURES Supports MP3, WMA, WAV format music View JPEG formatted pictures Supports AMV video format. (conversion program included). Built in MIC Energy Saver mode, auto off function Various EQ, repeat modes Support multi-languages Plug and Play for Win2000, Win XP & Vista, Mac OS 9.xx and above...

  • Page 7: Compliance With Fcc

    COMPLIANCE WITH FCC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 8 Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

  • Page 9: Location Of Controls

    LOCATION OF CONTROLS...

  • Page 10: Lcd Display

    LCD DISPLAY...
  • Page 11 Downloading Music, Movie & image to Your SMPV-2GBUB Player Connecting to your Personal Computer: 1. Connect the unit to your computer USB port using the provided USB cable. 2. The unit will turn itself on automatically. 3. “CONNECT” will appear on the LCD screen indicating the connection with the computer was established successfully.
  • Page 12 corner of system tray of your Windows desktop to bring up the list of USB Mass Storage Device attached to your computer. 2. From the device list, choose the Drive designator that corresponds to the Player, for example Drive (H :). 3.
  • Page 13 OPERATION INSTRUCTIONS Buttons used for “MENU” and “PLAY / PAUSE” functions can be controlled in 3 different ways: 1. Tap - press the button briefly then release it immediately. 2. Press - press and hold the button for about 2 seconds then release it. 3.
  • Page 14 2. Listening To Music 1. After turning on the Player, the Player will enter Music Mode. 2. Tap the MODE Button once to initialize the music play function and then tap the PLAY Button to start playback. The playback screen is displayed. 3.
  • Page 15 song, press and hold the to fast forward or fast rewind. 6. Tap and hold the PLAY Button to switch off the Player. 7. To power off the Player, slide the POWER Switch to the OFF position. 2.1 Listen to your music 2.1.1 Setting Repeat There are 7 play modes available: Normal, Repeat One, Folder, Repeat Folder, Repeat All, Random and Intro.
  • Page 16 2.1.3 Setting Tempo rate: There are 16 levels from -8 to +8. -8 is the lowest, +8 is the fastest and 0 means normal speed. Under music setting mode, select the tempo sub-menu by tapping the MODE Button. Tapping to select the rate of playing. Exit Exit from the play mode setting.
  • Page 17 Button to confirm. The selected file will be deleted. If “No” is selected, you will exit the file delete mode. 2.2.3 Delete all: After choosing the Delete all submenu, tap to select “Yes” and tap the MODE Button to confirm to delete all files. If you choose “No”, you will exit the delete mode.
  • Page 18 Please make sure that the video converted can be played on your computer, if not, it will not be able be played by SMPV-2GBUB. For information on using the AMV converter, please refer to the separate “AMV Converter User Quick Start Guide”.
  • Page 19 3.1.2 Tap the PLAY Button to play the movie. 3.1.3) Press and hold the MODE Button to return to the main menu. 3.2 Pause mode When in movie playback mode, tap the PLAY Button to pause. 3.2.1 In the pause mode, tap the PLAY Button again to continue playing. 3.2.2 Tap VOL+/VOL- key to increase/decrease the volume.
  • Page 20 3.3 Deleting movie files Delete 1: 3.3.1 In the movie pause mode, tap the MODE Button to enter the Movie submenu. 3.3.2 Tap the to select Delete and tap MODE Button to confirm. All the movies will be shown in the Display. 3.3.3 Tap the to select the movie to delete and tap MODE Button to confirm.
  • Page 21 In video pause mode 3.5.1 Tap the MODE Button to enter Movie submenu. 3.5.2 Select Repeat and then tap the MODE Button to enter. 3.5.3 Tap to select the mode you prefer and tap the MODE Button to confirm. Exit Choose exit to return to the Video control screen.

  • Page 22: Start Recording

    Before recording, tap the MODE Button to enter the Record submenu to preset the record quality. Local folder: Users can choose the Root or Record folder here. REC type: To choose the record type in this menu. The record options are Fine REC, Long REC, Fine VOR, Long VOR. Fine REC: Shortest record time, but the record quality is the best.

  • Page 23: Low Battery

    Low battery When recording, if the battery power is low, the System will save the current recorded file, stop recording and show LOW BATTERY. Please charge the battery if this condition occurs. About Display Errors 1. Record file is full When the recording file reaches 99 units or the flash space is full, “the record file is full”...
  • Page 24 5. LINE IN Recording Connect your iPod or other audio source and the Line In jack on SMPV- 2GBUB with a patch cable (not included) From the main menu, select Record and tap the MODE Button to enter the record control mode. Before recording, tap the MODE Button to enter the Record submenu to choose the record quality.
  • Page 25 Exit: Return to the record standby interface. 6. Playing Recordings The Line In and MIC recordings can be played in the Voice mode. From the main menu, select Voice. 6.1 Settings Repeat Mode Setting 6.1.1 There are 7 play modes available: Normal, Repeat One, Folder, Repeat Folder, Repeat All, Random and Intro.
  • Page 26 setting mode and select Repeat. Tap the MODE Button to enter. And then tap to select the mode you prefer and tap the MODE Button to confirm. 6.1.2 Tempo rate setting: There are 16 levels from -8 to +8. -8 is the slowest, +8 is the fastest and 0 means normal speed.
  • Page 27 Playing Records 6.2.1 Tap the MODE Button to enter the Voice play screen. 6.2.2 Tap to select your desired recorded file and tap the Play Button to play 6.2.3 Tap VOL +/ VOL- to adjust the volume. 6.2.4 To stop tap the Play Button once. 6.2.5 To turn the Player off tap and hold the Play Button.
  • Page 28 the MODE Button to confirm. Deleting file: In voice playback stop mode, tap MODE Button to enter the submenu, select Delete and tap MODE Button to confirm. Tap to select the file you want to delete and then tap the MODE Button to confirm. Tap to select Yes or No, and then tap MODE Button to execute.
  • Page 29 6.4 Error display 6.4.1 No record file This error message will be displayed when the file is no longer available on the Player. 6.4.2 Illegal file When the record file is damaged or the file is not a record file, the Player can’t play the file 7.
  • Page 30 7.1.2 Tap the MODE Button to enter the picture list. 7.1.3 Tap the button to choose your desired picture and tap PLAY Button to display 7.1.4 Tap the button to browse pictures in sequence（only suitable for “Manual play”）. 7.2 Setting Play Mode 7.2.1 In the picture list, tap the MODE Button to enter Photo submenu, 7.2.2 Tap the button to select “play set”.
  • Page 31 and tap the MODE Button to confirm. 7.2.4 If Auto play is selected, tap the to 10 seconds. Tap the MODE Button to confirm. 7.3 Deleting Files 7.3.1 From the picture list, tap the MODE Button to enter the submenu. 7.3.2 Tap the to choose “Delete”...
  • Page 32 8. System Setting Choose Setup from the main menu and tap the MODE button to enter the Setup submenu. There are 7 options: Record time, LCD set, Language, Power off, Online Mode, Memory info., Firmware version. to select the setting option and then tap the MODE Button to confirm. Press and holding the MODE Button will take you back to the Setup menu.
  • Page 33 Setting Record time 8.1.1 After entering the Setup menu, tap the MODE Button to enter Setup submenu and select Record time and tap MODE Button to enter. 8.1.2 Tap the “VOL+/VOL-” key to select the item you want to change. 8.1.3 Tap key to modify the item you selected.
  • Page 34 8.2 LCD setup Black mode: this sets a fixed period of time ranging from 6 ~ 30 seconds, so if no buttons are pressed for the chosen time, the screen of the Player will turn black automatically. If “0” is selected, the LCD will stay on and not go off. 8.3 Language setting Users can choose one of the 25 languages in this mode.
  • Page 35 Sleep time: means that if no buttons are pressed during the chosen time, the system will go into sleep mode automatically. Choose from 10-120 minutes. If “0” is selected, the unit will remain on. Note: Sleep mode is only valid one time after it has been set. The system will delete the setting automatically after it works.
  • Page 36 8.6 Memory info Choose this to check the useable memory information in the following format: Usable memory in MB <percentage of memory used> 8.7 Firmware version Choose this to show the current software version of the unit. 8.8 Exit Exit back to the main menu. 9.
  • Page 37 2. Tap the MODE button to enter the E-book menu. 3. Tap to select the desired text file to read. 4. Tap PLAY button to enter text interface 5. Tap to turn the pages in sequence...
  • Page 38 6. While reading, tap the MODE Button to enter the Bookmark setting mode. 9.1 Adding Bookmarks. 9.1.1 Tap to choose “Bookmark Add” and LCD will return to the text interface automatically. 9.1.2 Tap to turn to the passage where you want to add the bookmark. 9.1.3 Tap the Mode Button to confirm and the LCD will return to Bookmark setting mode.

  • Page 39: Deleting Bookmarks

    9.2Deleting Bookmarks 9.2.1 In bookmark setting mode select “Bookmark Delete”, the bookmark list Will appear on the screen. 9.2.2 Tap to highlight the bookmark which you want to delete. 9.2.3 Tap the MODE button to execute. The LCD will return to the passage. Setting Play Mode 9.3.1 From the E-book list, tap the MODE Button to enter the text play list.
  • Page 40 Delete All 9.5.1 From the E-book list, tap the MODE Button to enter text play list. 9.5.2 Tap to choose “Delete All” and the MODE Button to enter this option. 9.5.3 Tap to choose Yes or No, if yes is selected all the E-book files will be deleted.
  • Page 41 Technical specifications Music format Video format Picture format Storage capacity Display Record mode Output frequency range Battery specification PC slot System requirement MP3 WMA. WAV 1.8” TFT color display , 128 x 160 pixels 85dB MIC internal record 20 Hz -22 kHz 3.7V rechargeable lithium battery USB2.0 Win2000/XP/Vista or Mac OSX 9 and up...

  • Page 42: Troubleshooting Guide

    TROUBLESHOOTING GUIDE If you experience difficulties in the use of this media Player, please check the following or call 1-800-777-5331 for Customer Service. Problems Unit does not turn on No display when I turn on the unit. No sound coming from the earbuds or speaker Possible Solutions Make sure the Power Switch is set to ON.
  • Page 43 Record Time always reverts to default setting Strange Characters Displayed on the Screen Unable to Download Music My computer goes wrong when I disconnect the Player Can’t see the files which have been stored in the Player Try not to set POWER On/Off switch to “Off”. Set unit to sleep mode by tapping PLAY button instead.
  • Page 44 90 DAY LIMITED WARRANTY AND SERVICE (VALID IN THE U.S.A ONLY) SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free from defective materials or factory workmanship for a period of 90 days from the date of original customer purchase and provided the product is utilized within the U.S.A.
  • Page 45 This warranty is valid only in accordance with the conditions set forth below: 1. The warranty applies to the SPECTRA product only while: a. It remains in the possession of the original purchaser and proof of purchase is demonstrated. b. It has not been subjected to accident, misuse, abuse, improper service, usage outside the descriptions and warnings covered within the user manual or non-SPECTRA approved modifications.
  • Page 46 This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. TO OBTAIN SERVICE please remove all batteries (if any) and pack the unit carefully and send it prepaid by insured parcel post or UPS to SPECTRA at the address shown below.
  • Page 47 It is recommended that you contact SPECTRA first at 1-800-777-5331 or by e-mail at info@spectraintl.com for updated information on the unit requiring service. In some cases the model you have may be discontinued and SPECTRA reserves the right to offer alternative options for repair or replacement.
