Sitech GCS900 HEX Field Reference Manuals

Hide thumbs

Advertisement

Quick Links

Download this manual
Field Reference Guides
GCS900 HEX
Version 13.13
SITECH Rocky Mountain
www.sitechrockymtn.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the GCS900 HEX and is the answer not in the manual?

Questions and answers

Summary of Contents for Sitech GCS900 HEX

  • Page 1 Field Reference Guides GCS900 HEX Version 13.13 SITECH Rocky Mountain www.sitechrockymtn.com...
  • Page 3 SITECH TECHNOLOGY DEALER TRAINING CHECKLIST System: GCS900 HEX Version: 13.1 Training Checklist Page # □ CB460 Control Box Layout □ HEX Training Display Settings □ Check Bucket Wear □ Load Design □ Verify System Accuracy □ Verify Sensor Accuracy □...
  • Page 5 SITECH TECHNOLOGY DEALER TRAINING CHECKLIST System: GCS900 HEX Version: 13.1 Training Checklist Page # □ CB460 Control Box Layout □ HEX Training Display Settings □ Check Bucket Wear □ Load Design □ Verify System Accuracy □ Verify Sensor Accuracy □...
  • Page 7 SITECH TECHNOLOGY DEALER Field Reference Guide Table of Content GCS900 HEX Version: 13.1 Field Reference Guide Page # CB460 Control Box Layout HEX Training Display Settings Check Bucket Wear Load Design Verify System Accuracy Verify Sensor Accuracy Vertical Offset Horizontal Offset...
  • Page 11 SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 HEX Training Display Settings Version: 13.1 The Control Box must be in Manager’s Mode 1. Press “Menu” 2. Select “GNSS Accuracy” and Press “OK” 3. Press and Hold “F6 ” and Press “F2” Medium Mode 4.
  • Page 12 20. Press “OK” 21. Select Beeper and Press “OK” 22. Press “F1” and Uncheck each Item checked 23. Press “F1” to select On Grade and Below Grade 24. Press “OK” 25. Select “Save Settings” and Press “OK” 26. Select “Display Settings” and Press “OK” 27.
  • Page 13 SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Check Bucket Wear Version: 13.1 1. Press “Menu” 2. Select “Bucket Wear” and Press “OK” 3. Measure J to J1 4. Enter Distance and Press “OK” 5. Press “ESC” to return to operating screen...
  • Page 14 SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Load Design Version: 13.1 1. Press “Menu” 2. Select “Select Design” and Press “OK” 3. Use Arrows to highlight Design and Press “OK” 4. Press “ESC” to return to the operating screen...
  • Page 15 SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Verify HEX System Accuracy Version: 13.1 Verify the system accuracy by checking into Bench Point 1. Move machine to Bench Point 2. Position Bucket Tip over Bench Point 3. Press “Next” until Text Screen 2 is displayed 4.
  • Page 16 SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 HEX Sensor Accuracy Test Version: 13.1 1. Place Bucket in vertical position with teeth pointing down on a point on a solid surface 2. Record Cut/Fill 3. Uncurl Bucket and position Boom and Stick so teeth touch the same point 4.
  • Page 17 SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 HEX Vertical Offset Version: 13.1 1. Press “F4” to enter Horizontal and Vertical Offset 2. Press “F6” until Vertical Offset is displayed at the top left of screen 3. Enter Vertical Offset and Press “F2”...
  • Page 19 SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 HEX Horizontal Offset Version: 13.1 1. Press “F4” to enter Horizontal and Vertical Offset 2. Press “F6” until Horizontal Offset is displayed at the top left of screen 3. Press “F1” Alignment: 4. Use Arrows to Select [Plan Line] if list is displayed and Press “OK”...
  • Page 20 6. Press “OK” and enter Offset distance 7. Press “F2” Select Offset to be Left or Right of the line (-3.00 is Left) 8. Press “OK” to return to operating screen 9. Horizontal Offset is highlighted in red 10. Press “F1” to change Bucket Left, Right or Center...
  • Page 21 SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Vertical Guidance Version: 13.1 1. Press “Menu” 2. Press “Guidance Method” and Press “OK” 3. Change Adjust cut to avoid overcut: to “NO” 4. Press “F1” for Change Method 5. Select Method from list and Press “OK”...
  • Page 22 SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 HEX Cut and Fill Site Map Version: 13.1 1. Press “Menu” and select “Mapping/Recording Settings” Press “OK” 2. Change “Mapping for the main screen views” to “Yes” scroll down list 3. Change , “Minimum height mapping “Yes” and “Bucket tip mapping” to “Arm retracting”...
  • Page 23 SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 HEX UTS Set-up Version: 13.1 1. Press “Menu” 2. Press “F4”Mode select “3D UTS” and Press “ESC” 3. Press “F6” to Start UTS 4. Verify Auto search: Yes 5. Press “F4” to Start UTS 6.
  • Page 24 SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Lane Guidance Version: 13.1 1. Move Bucket Tip with Focus over Lane to be Extended 2. Press “F3” for Lane Guidance 3. “F3” turns Lane Guidance Off and On...
  • Page 25 SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Create New Bucket Version: 13.1 1. Press “Menu” 2. Select “Select Bucket” and Press “OK” 3. Press “F2” Create New 4. Enter Bucket name: and Press “F6” 5. Select Yes or No Tilt Bucket and Press “F6”...
  • Page 26 SITECH TECHNOLOGY DEALER Field Reference Guide Connect to WiFi GCS900 Version: 13.1 1. Press “Menu” 2. Press “F2” Installation 3. Select “Connectivity Settings” then press “OK” 4. Select “Wi-Fi Network” then press “OK” 5. Press “F1” New 6. Select the Wi-Fi you wish to connect to press “OK”...
  • Page 27 SITECH TECHNOLOGY DEALER Field Reference Guide TCC Settings GCS900 Version: 13.1 1. Press “Menu” 2. Press “F2” Installation 3. Select “Connectivity Settings” then press “OK” 4. Select “Connected Community Settings” then press “OK” 5. Enter “Device Password” then press “Next”...
  • Page 28 SITECH TECHNOLOGY DEALER Field Reference Guide Configure Remote Assistant GCS900 Version: 13.1 1. Press “Menu” 2. Press “F2” Installation 3. Select “Connectivity Settings” then press “OK” 4. Select “Remote Assistant Configuration” then press “OK” 5. Enter “Support Number” 6. Press “F1” Force Upgrade 7.
  • Page 29 SITECH TECHNOLOGY DEALER Field Reference Guide Wireless Data Sync GCS900 Version: 13.1 1. Press “Menu” 2. Press “F2” Installation 3. Select “Connectivity Settings” then press “OK” 4. Select “Wireless Data Sync” then press “OK” 5. Press “F1” Start 6. When synchronization is complete Press “ESC”...
  • Page 30 SITECH TECHNOLOGY DEALER Field Reference Guide Start Remote Assistant GCS900 Version: 13.1 1. Press “Menu” 2. Select “Remote Assistant” then press “OK” 3. Press “F1” Start 4. Once icon appears at the bottom of the screen the machine is connected 5.
  • Page 31 SITECH TECHNOLOGY DEALER Field Reference Guide Connect to IBSS Base Station GCS900 Version: 13.1 The Control Box must be in Manager’s Mode 1. Press “Menu” 2. Press “F2” Installation 3. Select “Connectivity Settings” then press “OK” 4. Select “GNSS Base Configuration” then press “OK”...
  • Page 32 Service and Support www.sitechrockymtn.com (866) 903-2335 Service Center Locations: SITECH Rocky Mountain 2420 Uravan Street Aurora Co 80011...
