Digimerge DBD13 Quick Start Manual

Camera Specifications
Image Sensor High Resolution 1/4" Sensor
Video Format / Pixels NTSC: 656(H) x 492 (V)
Horizontal Resolution 480 TVL
Internal; 2:1 Interlace
Sync. & Scan. Systems
S/N Ratio 48dB
Iris & Shutter Speed AES; 1/60 ~ 1/50,000 sec.
Minimum Illumination 3.0 LUX
Video Output Comp. 1.0 Vpp @ 75ohm
Lens / Lens Mount 3.6 mm F2.0/ Fixed
FOV (diagonal) 73 Degrees
Termination Video: BNC Female
Power: Barrel Female
IR / Night Vision Range N/A
Power Requirement 12V DC
Power Consumption 100 mA max
Operating Temp. 14°F ~ 122°F
(-10°C ~ 50°C)
Weight (with stand) 0.50 lbs / 0.23 kg
Dimensions 4.7" x 4.7" x 3.3"
LxWxH 118 mm x 118 mm x 83 mm
(with dome)
Dimensions:
IT'S ALL ON THE WEB!
Product Information
User Manuals
Quick Start Guides
VISIT
www.digimerge.com
Digimerge Technologies Inc.
Copyright © 2010 Digimerge Technologies Inc.
As our products are subject to continuous improvement,
Digimerge reserves the right to modify product design,
specifications and prices, without notice and without
incurring any obligation. E&OE
3-AXIS COLOR DOME CAMERA
Specification Sheets
Software Upgrades
Firmware Upgrades
Copyright
HIGH RESOLUTION
MODEL:
QUICK START GUIDE
English Version 1.0
www.digimerge.com
©
2010 Digimerge Technology Inc.
DBD13
