Laserco Tech4Pets T4P-4GPETTRAC Manual

4g pet tracker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Please read the instruction manual before use to install the
SIM card and use the product properly.
Before first use, fully charge the battery.
Do not turn on the tracker until the SIM card has been installed
following the instructions outlined in the manual.
PACKAGE CONTENTS
1 x 4G Smart Pet Tracker
1 x Collar Case
1 x Charge Cable
1 x User Manual
Manual
4G Pet Tracker
(T4P-4GPETTRAC)
Note:
USB Adaptor and SIM
Card are not included

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tech4Pets T4P-4GPETTRAC and is the answer not in the manual?

Questions and answers

Summary of Contents for Laserco Tech4Pets T4P-4GPETTRAC

  • Page 1 Manual 4G Pet Tracker (T4P-4GPETTRAC) Please read the instruction manual before use to install the SIM card and use the product properly. Before first use, fully charge the battery. Do not turn on the tracker until the SIM card has been installed following the instructions outlined in the manual.

  • Page 2: Setting Up The Tracker

    SETTING UP THE TRACKER Install a standard Nano SIM card (4G SIM for LTE network) according to the SIM card installation method. The SIM card needs to enable voice, SMS, data services and caller ID service. Remove the 2 screws then you can use the SIM card pin tool to remove the cover (please be careful not to damage the coating).

  • Page 3: Apn Settings

    APN SETTINGS The APN settings are not required for most mobile providers but if you have just purchased a new SIM you may need to follow these instructions to set it up: To test you can send below SMS command to check if there is APN problem: pw,123456,ts# You will get SMS reply that includes following:...
  • Page 4 For mobile operators who do not require user name and password as authentication, the username and password values should be left blank (just replace with commas). With this data, we can manually configure the APN by sending the following SMS message to the SIM number in the device (by entering the specific values of the Operator): pw,123456,apn,APN name,username,password,PLMN# Example 1:...
  • Page 5 TRACKER DIAGRAM SIM Card Slot SOS Button Power Button Reset Button Note: If the GPS tracker fails to turn on correctly, use the “Reset” button. After pressing the “Reset” button, the GPS tracker system will be forcibly turned off, and the settings will remain unchanged. Please charge the GPS tracker battery after the unit has turned off to get the tracker back to normal operation.

  • Page 6: Using The App

    USING THE APP Scan the following QR code, download and install the App Option 1 Search “SeTracker” in Option 2 App Store - Apple or Google Play Note: During installation, the phone prompts whether to trust the APP or whether to allow prompt access to the phone’s location, etc. Please select trusted and allow all the time.
  • Page 7 REGISTERING THE TRACKER AND LOGGING IN Open the App; new users will need to register a new account by clicking on the bottom right “Register” button and complete the registration steps. Please note that you will need to select the right area you are located in, for example if you’re in Australia, you need to select “Area”...
  • Page 8 CONNECTING THE GPS TRACKER TO YOUR APP ACCOUNT After successful registration, log in to the account, under Add Device select “Please Scan” option. Use the phone’s camera to scan the QR code on the back of the Tracker. TIP: The Registration QR code is the 15-digit registration number found on the QR sticker on the back of the tracker (it is not the IMEI barcode number).
  • Page 9 ADDING OR DELETING THE DEVICE How to add the device to your account: ME > Device list > Add device > put the registration code of Tracker. How to delete the device from your account: ME > Device list > Edit > Delete > OK ADDING A SECONDARY USER ACCOUNT Follow previous steps on another phone to register a new account and scan the QR code on the back of the tracker to add the device.

  • Page 10: App Features

    APP FEATURES LOCATION UPDATE SETTING This setting determines how often data is updated from the Tracker to the APP. In the APP select ME > Location Update Schedule NOTE: If the GPS tracker keeps still without movement, it will not update location to save battery.

  • Page 11: Geo-Fencing

    GEO-FENCING The Geo-fence feature sends a push notification if the tracker has left the safe zone. This feature requires GPS interval setting in mode 0, which is the standard mode. In the APP select MAP > Geo-fence icon to check the location history. Next tap the PLUS icon then tap the screen in the area you want to set the Geo-fence around.
  • Page 12 You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. www.laserco.com.au...
