Heinz Keystone Quick Start Manual

Quick Start Guide
for Keystone Automatic Dispenser
1

Unpack your lid and power supply.

Determine where the unit will be placed and plugged in.

2
The lid assembly comes with the power supply attached
to the lid.
If your power source is below the counter,
and you need to route the cord through an opening,
please follow these steps:
A- Snap the strain relief out from the back of the lid.
B- Unplug the power supply from the outlet on the board.
C- Remove the cord through the opening in the lid.
D- Route the cord through the opening in the counter.
E- Insert the cord through the opening;
plug the connector into the outlet on the board.
F- Snap the strain relief back into the opening in the lid.
A- Load the dispenser base with product and pump.
3
B- Use your hands to press on the dome to manually pull
product into the pump (priming the pump).

Place lid on the dispenser base.

4
Make sure that the lid snaps into place.
Be careful not to pinch the cord in the lid.
Do not stretch the cord or lift the lid by the cord.
*
There is a flashing red light in the lens that goes out
when the lid is positioned correctly. If the light is still
flashing after you've installed the lid, reposition the
lid until the flashing light is no longer visible.
Place a dish under the discharge point. Hold your hand
5
over the sensor. You should hear the motor start and
dispense product. You may need to repeat this process
several times to complete priming the pump. You must
remove and replace your hand from the sensor in order for
it to dispense the next portion.
Your unit is now ready to provide safe touchless dispensing
of premium condiments to your customers.
Heinz Dispensing Solutions 1-855-57HEINZ (1-855-574-3469) | email at heinzdispensers@knepperpress.com
1
2A
3A
*
4
2B
2F
3B
5
