Summary of Contents for Soliday FIXED SUNSAILS
- Page 1 FIXED SUNSAILS •INSTRUCTION MANUAL • SAFETY INSTRUCTIONS • MOUNTING TIPS • MATERIAL- AND CARE INSTRUCTIONS • PRODUCT GUARANTEE www.soliday.eu s u n s a i l s...
- Page 2 THE ART OF SHADE Congratulations! You made a good choice! A Soliday sunsail is a quality product. Practical de- sign for extensive shadowing, combined with the architecture of clear lines and shapes of modern architektur design form interior design. With Soliday you count on a sun- sail professional with the largest offer in Europe.
-
Page 3: Table Of Contents
Step 6 – Mounting the sunsail Material- & care notes Sunsail made of Austronet Sunsail made of Austrosail Sunsail made of Austrosail Nano Soliday stainless steel masts Soliday aluminum masts Questions that might arise after the purchase FAQ/ general emerging issues General warranty &... -
Page 4: Soliday Sunsail Product Description
The side- edges of a Soliday sunsail are seamed with a robust circular strap. The strap ser ves as hanging point on the sail corners and is responsible for the optimal distribution of forces of the sunsail in an evenly stretched condition. -
Page 5: Mounting Instruction, Accessories And Advice
Mounting instruction, accessories and advice STEP 1 – SAIL TYPES The sail form and the characteristic of the sunsail are significantly de- termined by the height of the attachment points. The classic saddle sail is a ver y modern shape, where the diagonal points are in about the same height and the sail corners are pulled down strongly on the left and the right. -
Page 6: Step 3 - Determining The Attachment Points
In the beginning give special attention to the fully installed sunsail. Soon you will notice the behavior in all weathers. With strong wind the sail must be dismounted. Using Soliday security clamps additionally heightens the safety. Infor - mation on page 14, resp. on www.soliday.eu... - Page 7 Mounting instruction, accessories and advice Stainless steel wall plate For robust attachment on brickwork measurement : 15x15 cm distance of the holes: 11 cm inner diameter drilling: 12,5 mm SCHRITT 4 – MONTAGE DER BEFESTIGUNGSPUNKTE AN WÄNDEN The resilience of the attachment points is dependent on the struc- Stainless steel wall plate 25x5 cm ture.
-
Page 8: Step 5 - Mounting Of Additional Attachment Points
Telescope mast • Made of aluminum • Individually adjustable mast height Possibilities to stiffen the mounting Possibilities to stiffen the mounting from 200 cm to 350 cm • Integrated gliding carriage for a practical height adjustment of the sunsail from 0 to 350 cm •... -
Page 9: Instruction For Concrete Foundations
Mounting instruction, accessories and advice INSTRUCTION FOR GROUND FUNDAMENTS WITH SOLIDAY GROUND SLEEVE 1. Embed the fundament. The chart shows you guidelines for the size of the fundament. Dig at least 80 cm deep because of frost protection. SAIL LENGTH & WIDTH... -
Page 10: Step 6 - Mounting The Sunsail
STEP 6 – SUNSAIL ATTACHMENT TYPES So that a Soliday sunsail obtains its shape, it is necessar y to optimally tension the sunsail between the attachment points. The classic Soliday sunsail has a concave cutting of the side edges and is delivered with an integrated belt strap. - Page 11 The Soliday strap ratchet is made of high quality PES web- bing and a stainless-steel ratchet, suitable for long-term outside use.
- Page 12 TENSIONING DEVICE: WITH A 6 MM PES ROPE AND A PROFESSIONAL TENSIONER Simple and ver y effective tensioning of a sunsail that can be detached anytime. Beware: for security reasons the rope must be additionally se- cured with a half pelt, resp. with a knot after the clamp. Distance attach- ment point –...
- Page 13 On the high-quality guide rail there is a smooth-running sliding carriage with a pulley. The sliding carriage can easily be adjusted variably with a hand movement on a length of 1,5 m. Under the sliding rail the 6 mm rope is wedged in with a Soliday security clamp. Beware When mounting a sunsail with a Soliday security clamp make sure not to use any D-rings, resp.
- Page 14 Achtung: Zur Sicherheit muß nach der Klemme das Seil zusätzlich mit einem halben Schlag are valid despite the use of a Soliday security bzw. mit einem Knoten nochmals gesichert werden. clamp and should implicitly be followed.
-
Page 15: Material- & Care Notes
Therefore, the ma- terial is exposed to a much higher strain. The utilized materials at Soliday are selected according to stringent rules and functional requirement profiles. Our materials are technical knittings and fa- brics with the best requirements for sun protection. -
Page 16: Sunsail Made Of Austrosail
Under circumstances it water repellent. Suitable care products can also be found in can happen that small dashes our internet shop under www.soliday.eu. of color, resp. weaving flaws occur. From our present point The cloths may not be exposed to strong mechanical use. - Page 17 As innovative pioneers for sunsails Soliday constantly tests new sunscreen fabrics with even better characteristics. Should your Soliday fabric not be mentioned here, you can find the cur- rent material- ser vice- and care indications in the internet under www.soliday.eu/Segeltuch...
-
Page 18: Soliday Stainless Steel Masts
Af ter cleaning use a care oil (available in any construction market) – about 3 times yearly. This way you are sure of perfect cleaning, caring and look of your Soliday sail mast. -
Page 19: Questions That Might Arise After The Purchase
4 % of the original edge length. All Soliday sunsails are provi- ded with a concave cut to achieve a perfect form with a minimum of sagging. - Page 20 Correct Wrong Wrong The consequence is wrinkling The sunsail is lying beyond the center and cannot be tensioned properly. The consequence is wrinkling. 3. DOES THE SUNSAIL WRINKLE STRON- GLY IN TENSIONED CONDITION? In opposition to a wooden plate or a roof, sail cloth is a flexible ma- terial.
-
Page 21: Product Guarantee
Product guarantee THE SOLIDAY PRODUCT GUARANTEE The manufacturer guarantees the free of charge correction of defects that are due to material- or manufacturing errors. When noticing a defect, you are obligated to immediately notif y Plaspack Netze GmbH, Dr. Grobben- Straße 1, A - 4690 Schwanenstadt. -
Page 22: Product Guarantee For Sunsail Cloths
The manufacturer reser ves the right to return freight unpaid in the case of not unauthorized guarantee submission. The Soliday warranty ser vices are free of charge in the first 2 to 3 years af ter the purchase. - Page 23 In the case of return deliver y get in contact with our Soliday ser vice the ar t. The company Plaspack Netze address Tel.: 0043 (0) 7673 – 2478 – 0 for technical information and GmbH does not assume responsibility and consultation.
- Page 24 CURTAINS PRIVACY PROTECTION s u n s a i l s SOLIDAY by Plaspack Netze GmbH . Dr. Grobben-Straße 1 . A-4690 Schwanenstadt . Austria Tel.: +43(0)7673/ 2478-0 . Fax: +43 (0) 7673/ 2478-266 . E-Mail: office@soliday.at . www.soliday.eu SOLIDAY is a registered brand name of the company Plaspack Netze GmbH ®...
