FORTEZA FMC 24 Description Manual & Service Instruction

Local microwave protective detector (50m, 100m, 200m)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
JSC FORTEZA
FORTEZA FMC 24 (50m, 100m, 200m)
Local Microwave Protective Detector
Forteza FMC 24 (50m, 100m, 200m)
Description Manual & Service Instruction
No. 2014-11-19
(updated 09-2015)
2014
Please visit our internet sites:
www.forteza.com
or
www.forteza.eu
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FMC 24 and is the answer not in the manual?

Questions and answers

Summary of Contents for FORTEZA FMC 24

  • Page 1 JSC FORTEZA FORTEZA FMC 24 (50m, 100m, 200m) Local Microwave Protective Detector Forteza FMC 24 (50m, 100m, 200m) Description Manual & Service Instruction No. 2014-11-19 (updated 09-2015) 2014 Please visit our internet sites: www.forteza.com www.forteza.eu Page 1...

  • Page 2: Table Of Contents

    FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) CONTENTS DESCRIPTION AND OPERATION ............1.1. Purpose ......................1.2. Specifications ....................1.3. Sensor components..................1.4. Operation principle ..................1.5. Sensor structure ..................... 1.6. Adjustment, control and indication parts ............INSTALLATION AND ADJUSTMENT PROCEDURE ......

  • Page 3: Description And Operation

    1. DESCRIPTION AND OPERATION The present description manual and service instruction contains information about the operation of the local microwave protective detectors series FMC 24 (50m 100m 200m) below the detector. In this document there is information required for the correct operation (use, transportation, storage and maintenance) of the detector.
  • Page 4 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) Current consumption 45 mA maximum - Tx 10 mA maximum - Rx 35 mA maximum Individual point relay parameters: Switching voltage 30 V maximum Switching current 0,1 A maximum Alarm contact resistance 100 Ohms maximum “dead”...
  • Page 5 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) Fig.1.1. Detection zone L- Length of a sector h- Height of detection zone b- Width of detection zone 1.2.3. In Fig.1.1 and Table 1.1 the height (h) and the width (b) of the detection zone are given for the middle of the sector.

  • Page 6: Sensor Components

    FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) snow up to 0,5 m (without additional adjustment); grass up to 0,3 m; the influence of ultra-short waves emissions of the range 150-175 MHz and the power up to 40 W at the distance 6 m maximum.

  • Page 7: Sensor Structure

    FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) depend on: height and weight of the intruder, place of the sector crossing, its relief and speed of the movement. 1.4.3. The signal on Rx input can be changed under the influence of other interference...
  • Page 8 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) Fig.1.2 1-support - 1 item 8-cable - 1 item 2- bracket - 1 item 9-ring - 1 item 3- figured washer - 2 items 10-nut M6 - 1 item 12-bolt M6*16 – 1 item...

  • Page 9: Adjustment, Control And Indication Parts

    FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) 1 – frequency channels switches 1 – frequency channels switches 2 – tamper circuit "TAMPER" 2 – tamper circuit "TAMPER" 3 – indicator "LED" 3 – socket "RS 485" 4 – marking of cable cords 4 –...

  • Page 10: Installation And Adjustment Procedure

    1.6.2. The adjustment, the control and the sensor indication is performed by the controls of the receiver LED indication and BUZZER sound, software FORTEZA FMC oftware on PC. 1.6.3. Manual adjustment: calibration of detector signal using LED indication and Buzzer;...

  • Page 11: Tx And Rx Mounting

    FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) 2.1.2. The detector can be mounted if the width of the sector is less. In this case if “Calibration mode” voltage is less than 10 mV, it is necessary to change Rx and Tx position relative to the support.
  • Page 12 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) overlapping of the sectors detection zones (see fig. 2.1 and 2.2). The overlapping is necessary to eliminate the possibility of the sector overcoming under or above Tx (Rx) unit near the support.
  • Page 13 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) support mounting is given in fig. 2.3. In the snowy regions the superstructure of the support should be 1500 mm minimum. 1 - support; 2 - plastic plug; 3 - hole for the cable input inside the support;...
  • Page 14 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) Fig.2.4 2.2.4. Lay the main cables according to the project of the security system. It is recommended to use multicore cables with the core screen or metal sheath. The cable core section is chosen on condition that the supply voltage is not less than 9 V for every sensor unit.

  • Page 15: Sensor Connection

    FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) Notes. 1. If the upper part of the fence is protected with physical protection devices, it is necessary to use the bracket of 500 mm. If the upper part of the fence is not protected with barbed wire, it is recommended to use the bracket of 350 mm.

  • Page 16: Sensor Adjustment With The Buildin Adjustment Control And Indication Parts

    FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) Fig. 2.5 Warning: Do not open the detector’s housing, because it may damage the device!!! Note: Always use separated cables for the power supply circuit as the cables for the alarm signal circuit to avoid unexpected alarms.
  • Page 17 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) 2.4.1.2. Direct Rx and Tx against each other using a sight leaf situated on the antennas sides. 2.4.1.3. Tighten the bolts 12 and 9 of Rx and Tx; 2.4.2. Main adjustment of Tx and Rx 2.4.2.1.
  • Page 18 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) “LED” and BUZZER is switched ON. 2.4.2.7. Tx and Rx are adjusted on the angle of the place and the azimuth according to the buzzer signals and “LED” blinking’s (on the RX). Two persons are necessary for the detection zone calibration.

  • Page 19: Software Installation And Detector Adjustment

    USB device and installs the driver on COM-port. If the driver is not installed automatically, the computer asks to install the driver. Follow IIIIIII You can find driver in Forteza FMC SOFT file. Please visit our internet sites: www.forteza.com...
  • Page 20 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) Fig.2.7 Fig.2.8 Please choose the folder COM-PORT from the earlier unzipped file in the window Search. Please visit our internet sites: www.forteza.com www.forteza.eu Page 20...
  • Page 21 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) Fig.2.9 Fig.2.10 Please visit our internet sites: www.forteza.com www.forteza.eu Page 21...
  • Page 22 1) Connect the programming extension cable throw converter to the receiver socket “RS- 485” using the connection cable from FORTEZA RS- 485/USB kit. (see Table 8.1) 2) Connect the programming converter RS-485 to connection cables RS A or RS B (white and green) from RX 8-cable (see Table 2.2)
  • Page 23 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) 2.5.3.3. After choosing the proper com port, the communication with the device starts automatically. Fig.2.12 2.5.3.4. In the left side of the screen you can see the current setting parameters. They have the following meaning: Detector: Information about detectors model FMC, operation frequency 10 (10.525...
  • Page 24 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) Sensitivity: It means the sensitivity of detection. You can only set sensitivity in ‘Manual’ Setup method. In most of the cases sensitivity setting is not recommended. Speed: It is the motion speed range which is identified by the detector.
  • Page 25 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) 2.5.4.4. Here you can see the received signal from the transmitter on a dynamically changing scale. The maximum value of the current positioning is always signed. If you are close to the maximum value of the current positioning, the changing lane becomes green. It means the positioning made well.
  • Page 26 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) Fig.2.14 2.5.5.3. Setup Method: Auto in most of the case ‘Auto’ mode and default sensitivity value is recommended. The most important is to set the proper ‘Zone length’ according to the installation site, sensitivity value will be set up automatically. You can send your setting to the receiver with ‘Apply’...
  • Page 27 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) of 1-2 m and make a pause from 5 to 7 sec. Otherwise, the results of the previous passage can influence on the next one. Fig.2.16 2.5.5.5.You can change the minimum detected speed in m/s (Vmin), the maximum detected speed in m/s (Vmax).
  • Page 28 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) Fig.2.17 Select method: Manual Fig.2.18 Sensetivity window is active, zone length is deactive. Please visit our internet sites: www.forteza.com www.forteza.eu Page 28...
  • Page 29 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) Fig.2.19 After select 50 and press apply threshold level is changed, higher theshold - sensitivity is lower. 2.5.5.7. Set the sensitivity with the “approved” passages. Do these passages in “full height” and “bent” on different distances from Tx and Rx. It is recommended to begin doing these “approved”...

  • Page 30: Trial Operation

    At the end of running the program, an additional report – archive (logs) is created; c). Program (1.48.0.0 version) is compatible not only with FMC series microwave detectors but also with Forteza PC detectors manufactured previously. The innovation shall significantly facilitate the work when adjusting detectors, help to locate the reasons for “problematic areas”...

  • Page 31: Safety Measures

    FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) - the absence of foreign objects in the protected sector. 3.2.2.2. Every quarter: - carry out all monthly works; - check the cables and cable connections. 3.2.2.3. The grass height is controlled during seasonal works. If the grass height is over 0,3 m, the grass should be mown down.
  • Page 32 FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) 3. Receiver indicator lights No operation signal from Press AGC button LED will blinks, sound is missing. continuously (more than 15 Transmitter or lower than 2.5 1.Check power supply on Tx. sec), the relay contact is open 2.Check...

  • Page 33: Storage

    FORTEZA JSC FORTEZA FMC 24 (50m, 100m, 200m) one specified in the manual and this reduces an input signal. Animals circulate in the sector. The Rx sensitivity is too high. 7. The detector does not Rx sensitivity is too low.

  • Page 34: Certificate

    1 item; Kit of tools and accessories 1 kit; 2. ACCEPTANCE CERTIFICATE The sensor “Forteza FMC 24”___________№_________ meets performance specifications of the Description Manual & Service Instruction No. 2014-11-19 and it is considered as operable. Date of issue _________201_ .
