Avee Ave325 Setup Instructions & User Manual

TECHNICAL SPECIFICATIONS

Document version: 3.1 - August 27 2020
Valid for products: Ave325,Avee335, Avee340
Software version 3.0
Connector headphone:
Bose ™ QC25 ™ & QC35 ™ 2.5mm four pin audio
Sony ™ WH-1000XM3 ™ 3.5mm four pin audio
Connector AC interface cable USB C
Bias voltage accepted 9-16VDC
Microphone type Noise reduction
Microphone output signal 0.7 V RMS @ 1khz / 74dB SPL
Adjustable in 6 steps 20-100%
Maximum level is 1.5V RMS
Minimum level is 0.2V RMS
Speaker audio level Adjustable in 6 steps / 10-100%
Start-up mode speaker Configurable
Maximum volume on restart is default
setting.
Mono/stereo detection Mono, automatic or Stereo always
Automatic is (default setting)
Configurable with the Avee BlueLink and
from the Avee add-on.
Stereo detection signal level 0.2V RMS
Adjustable using the Avee BlueLink
Firmware Upgradeable with the Avee BlueLink

FACTORY SETTINGS

Start-up mode speaker Maximum volume on restart.
Microphone output signal 0.7V RMS (step 4)
Mono & stereo setting: Mono
DISCLAIMER
Avee is an unlicensed third-party accessory and is not affiliated with Bose
™
Sony .
Bose ™ or Sony ™ does not approve or endorse the products manufactured by
Avee.
Follow the instructions in this user guide to install the Avee add-on to your
headphones.
Step 1:
the base of your headphones including the area
surrounding the input jack. Ensure that you
remove any residue that is adhered to the
headphones. Let dry.
Step 2:
strip.
The magnetic adhesive strip has the adhesive side facing the headphone, and
Step 3:
headphone and firmly press it in place for
minimum 30 seconds. Once attached, carefully
unplug it to reveal the adhesive magnetic tape
applied to the headphones. Press firmly on the
tape to ensure all edges of the tape have adhered
™ or
to the headphones.
The Avee Aviation Microphone
Setup Instructions & User Guide
Using the cleaning wipe supplied, clean
Remove the adhesive strip protective backing from the add-on magnetic
two magnets facing the Avee add-on.
This feature enables the Avee to be
easily detached & attached from the
headphone.
Guide the add-on to the base of the left
