Kvill CE
Installation manual
1
Mount ceiling bracket with 3x screw
(not provided).
Perform electrical installation on the
2
terminal block main side. Cable from
behind or from the side.
Aura Light AB, Sweden
Phone customer service +46 (0)20 32 30 30
info@auralight.com, www.auralight.com
Ø D
TYPE
(mm)
Kvill 400 CE
250
Kvill 550 CE
350
Kvill 750 CE
490
D
2x side entry for cable.
2020-08-17
I-153
