Wacom ESP-110-01-5 Product Specifications

Wacom ESP-110-01-5 Product Specifications

Aes stylus with 2 side switch
Hide thumbs

Advertisement

Quick Links

Download this manual
CUSTOMER
Lenovo (Japan) Ltd.
CUSTOMER'S ACCEPTANCE
(Based upon the contents of this specification and related notes)
Authorized Signature
Printed Name
Title
Date
This information shall only be used for the specific project of the customer.
No disclosure is permitted to a third party without written consent of Wacom Co., Ltd.
Approved
Checked
Kaneda
2015.07.17
PRODUCT
SPECIFICATIONS
CUSTOMER'S TYPE NO.
Wacom TYPE NO.
Checked
Designed
Aoki
Sakamoto
2015.07.17
2015.07.17
WACOM CONFIDENTIAL
TENTETIVE
SD60G97209
ESP-110-01B-5
Wacom Co., Ltd.
2-510-1 Toyonodai, Kazo-shi,
Saitama, 349-1148, Japan
Drawing No.
A4A-621A002
Ｐ
１
Rev.
X

Advertisement

loading
Need help?

Need help?

Do you have a question about the ESP-110-01-5 and is the answer not in the manual?

Questions and answers

Related Manuals for Wacom ESP-110-01-5

Summary of Contents for Wacom ESP-110-01-5

  • Page 1 Printed Name Title Date This information shall only be used for the specific project of the customer. No disclosure is permitted to a third party without written consent of Wacom Co., Ltd. Wacom Co., Ltd. 2-510-1 Toyonodai, Kazo-shi, Saitama, 349-1148, Japan...
  • Page 2 WACOM CONFIDENTIAL Contents SCOPE ......................................2 MODEL NO. AND MODEL NAME ..............................2 ENVIRONMENTAL SPECIFICATION ............................2 Guaranteed environment ..............................2 Testing environment ................................2 COSMETIC, SHAPE, DIMENSIONS AND MASS ........................2 Cosmetic ....................................2 Shape and dimensions ................................. 2 Mass ......................................
  • Page 3 Normal temperature (Temperature : 20 to 30°C), No condensation Cosmetic, Shape, Dimensions and Mass 4.1 Cosmetic Noticeable scratches, discoloring or uneven color are allowed. Wacom Co., Ltd. sets inspection standard. 3 grade. Depends on the limit sample in case we defined. 4.2 Shape and dimensions Diameter: 6.5 [mm] (body), Length : 126.7[mm] (Refer to 9.
  • Page 4 OptionPen: EMC test and DoC by Wacom. EU/EFTA System: EMC test and application of certification by a customer. South Korea OptionPen: EMC test and application of certification by Wacom. Taiwan BSMI The EMC standard is not applicable to the product.
  • Page 5 Taiwan RF test and application of certification by Wacom. As the results of Wacom investigation, the following countries do not require RF standard test. Australia, Canada, China, Japan, New Zealand, EU/EFTA, South Korea, USA, Argentina, Brazil, Chile, Hong Kong, India, Israel, Malaysia, Mexico, Philippines, Russia, Singapore, Thailand, Turkey, Angola,...
  • Page 6 WACOM CONFIDENTIAL Characteristics [TBD] Function 6.1.1 Oscillating frequency 1800 [kHz] ±10% 6.1.2 Switch operation Pen tip : Pressure infomation is detected as continuous signal. Side switch : ON / OFF switching is detected. 6.1.3 Pressure resolution 2048 level 6.1.4 Operation mode EDLC voltage 2.7~ 0.9 [V] : To be operable the active mode...
  • Page 7 WACOM CONFIDENTIAL Electrical and power supply specification 6.2.1 Raiting Raiting voltage : 3.3[V], Raiting current : 400 [mA] 6.2.2 Power source EDLC 0.7 [F]（No replacement) 6.2.3 Charging method CC-CV charging 6.2.4 Charging specification Input voltage: 3.3 [V] Input current: Less than 350 [mA] EDLC charging voltage: 2.65 [V] (typ)
  • Page 8 WACOM CONFIDENTIAL Discharge characteristic [TBD] 6.2.9 Discharge curve (Reference) [TBD] Measurement condition - AES stylus: Typical sample - Charging time: 300 [sec] Level1 2.26 Level2 1.65 Level3 1.13 Level4 0.99 Level5 time [min] Charge level and usage time(Reference) [TBD] Charging time 15 [sec]...
  • Page 9 WACOM CONFIDENTIAL 6.2.11 ID specification 1) Device ID (16 bits) Device ID shows the device function and design. Part No. Value Function Design ESP-110-01B-5 EDLC battery Lenovo ID ESP-110-02B-5 0x0011 ASIC control 6.5Φ ESP-110-03B-5 2) Unique ID (35 bits) Unique ID consists of Vendor ID (5 bits) and Serial ID (30 bits).
  • Page 10 WACOM CONFIDENTIAL 6.2.12 Tip switch average pressure curve (reference) Note) The equipment used for measurement is prepared by Wacom Co., Ltd. Above curve shows on a brand-new stylus. Drawing No. Rev. Page A4A-621A002 Rev. Contents Sign Date...
  • Page 11 WACOM CONFIDENTIAL 6.3 Environmental characteristics Item Test condition Specification 6.3.1 Operational Environment The following tests are carried out during operation No malfunction (1) high temperature 40°C 4hrs (2) high temperature, high humidity 40°C, 80% 4hrs (3) low temperature 5°C 4hrs (4) high temperature, low humidity 40°C, 30%...
  • Page 12 WACOM CONFIDENTIAL 6.4 Durability Item Test condition Specification No malfunction 6.4.1 Operating life (1) Operating speed : 5 times/sec time of (2) Applied pressure : 2.94 [N] puressure (3) Operating cycle : 2,000,000 times switch 6.4.2 Operating life (1) Operating speed...
  • Page 13 Wacom shall inform changes in the specifications herein and changes affect the product quality prior to such changes. However, in order to maintain or improve service e.g. lead time and delivery, Wacom may make minor design changes without notice as far as such changes will not interfere specifications herein or quality of the product.
  • Page 14 WACOM CONFIDENTIAL Exchanging nib Pen parts name How to remove the nib shaft if hard to pull off. 1. Remove it in the same way as exchanging battery 1 and 2. 2. Turn the front unit clockwise wearing non-slip rubber groves.
  • Page 15 WACOM CONFIDENTIAL 6. After inserting the nib, make sure if it withdraws when pushing tip. If the nib doesn’t move up and down, remove it and insert it again. Projecting about 3mm. Make sure there is stroke. Exchanging the nib 1.
  • Page 16 WACOM CONFIDENTIAL Stylus drawing DIMENSION TOLERANCES /寸法区分 /許容公差 0.5～3 ±0.2 6 or less ±0.2 30 or less ±0.4 120 or less ±0.7 315 or less ±1.0 ESP-110-01-5 Drawing No. Rev. Page A4A-621A002 Rev. Contents Sign Date...
  • Page 17 WACOM CONFIDENTIAL Packing specification 10.1 Product packing Drawing No. Rev. Page A4A-621A002 Rev. Contents Sign Date...
  • Page 18 WACOM CONFIDENTIAL Rating Label 11.1 Rating label for Pen body Size: (38x 8 [mm]) 11.2 Pasting position Drawing No. Rev. Page A4A-621A002 Rev. Contents Sign Date...
  • Page 19 Digit 20-23 (Serial number) : “0001 to 9999” (decimal system). Starts from “0001”. Production date change increments it by one. * Barcode format is CODE39. 12.2 Product label (100x40[mm]) Contents : Electronic Styli Wacom P/N : ESP-110-01B-5 Q'ty / Box (pcs) : 50 Wacom Co., Ltd. Drawing No. Rev.
  • Page 20 WACOM CONFIDENTIAL 12.3 Carton label for Wistron ・Large (4S label) ・Small (3S label) ・Barcode format is CODE128 ・Size: (60x30mm) ・TRACE ID : Lot number of shipment date Refer to 19. Lot number coding in next page. ・Barcode format is CODE128 ・Size: (100x80mm)
  • Page 21 WACOM CONFIDENTIAL 12.4 RoHS label for Wistron ・Size (60x30mm) Lot number coding On Pen body ① ② ③ ➀Production Year: The last one digit of the year. ➁ Production Week: The week number of a production date, based on a week starting on Sunday.
  • Page 22 WACOM CONFIDENTIAL Revision list Rev. Date Description Designed Remarks Jul-17-2015 Tentative version Nakajima Page 14 15 Rev. Page Drawing No. Page Rev. A4A-621A002...
