- Page 1 QUALITY, RLIABILITY, & PURE BLISS DIGITAL HYBRID AMP STYLE 12 FARAD CAPACITOR BANK W/DISTRIBUTION BLOCKS ACAP651N OPERATING INTSTRUCTIONS PLEASE RETAIN MANUAL FOR FUTRE USE AND REFERENCE...
- Page 2 With four levels of play, one is right for you to get started in the Audiobahn family. Our Technical Department and entire staff look to strive above and beyond the rest of the pack by going that extra mile to help you out.
-
Page 3: Table Of Contents
Table of Contents Table of Contents INTRODUCTION CAPACITOR INTRODUCTION SPECIFICATIONS CHARGING / DISCHARGING INSTALLATION AND WIRING ADJUSTMENTS AND TROUBLESHOOTING WARNING / DISCLAIMER WARRANTY 10-11... -
Page 4: Introduction
Congratulations on your purchase of the worlds finest brand of car audio products. Here at Audiobahn Inc. we are devoted to making our musical reproduction the very best, and we are pleased you have chosen our product. Through years of engineering expertise, hand craftsmanship, and critical testing procedures, we have created a wide range of products that reproduce music with all the clarity and richness you deserve. -
Page 5: Capacitor Introduction
Capacitor Introduction When installed properly, your new stiffening capacitor will provide years of dependable service. There are many benefits of adding a stiffening capacitor. The most significant benefit is the capacitors ability to improve bass performance in your sound system. This is possible due to the voltage stabilizing effects of the capacitor. -
Page 6: Specifications
Specifications Model: ACAP651N DIGITAL HYBRID AMP STYLE 12 FARAD CAPACITOR BANK W/DISTRIBUTION BLOCKS Capacitance ...……...12,000,000 micro farad (12 Farad) Working Voltage ...…….…...24DC Surge Voltage ...………28DC E.S.R. (Equivalent Series Resistance)...0.0015 ohm @120hz/ 25°C Capacitance Tolerance...± 10% DETAILED FEATURES: a) 3 digit hi-end blue lighted amperage display meter and DC voltage meter that can measure 1 AMP and 0.1 DCV range. - Page 7 Charging CHARGING THE CAPACITOR AND WIRING: The capacitor must be charged before connecting the power and ground cables to the capacitor. Failure to charge the capacitor will result in a large spark generated from the rapid inflow of current which can cause damage to the unit or serious injury.
-
Page 8: Discharging The Capacitor
Discharging DISCHARGING THE CAPACITOR: When you want to remove or disconnect the capacitor from the system you must discharge the capacitor. It will be safe to release the power of the capacitor. To Discharge the capacitor: With the battery power disconnected, place the light bulb or resistor across the capacitor’s positive and negative terminals until the light goes out or for three minutes if using a resistor. -
Page 9: Installation And Wiring
Installation and Wiring Please make sure that you have correctly and successfully charged your capacitor. Above is a diagram showing how the layout should be for multiple amplifiers. The Remote-Turn-On block is used to turn the capacitor on. The Remote-Turn-On block is also used as a distribution block to connect all your amplifiers and / or other processors to a central location. -
Page 10: Troubleshooting
Troubleshooting Should you encounter a problem with your capacitor, you can follow the steps below to make sure that it is working properly. 1. Follow all power (+) and ground (-) connections to and from the capacitor. Make sure there are no kinks in the wire and no cuts either. If there is a problem in the wiring, make sure to use new wire and place the wire in a good location where it will not be roughed up and abused. -
Page 11: Warning / Disclaimer
Using a fuse of different type or rating may result in damage to this system which is not covered by the warranty. Disclaimer Specifications are subject to change with out notice. For the most updated Specifications call Audiobahn, or your local Authorized Audiobahn Dealer, or check the Audiobahn website. www.audiobahn.com... -
Page 12: Warranty
You must receive prior authorization and an RA# before sending in any complete enclosure). Audiobahn will only replace L.E.D.(s) found to be defective at the time of purchase. Audiobahn warranties do not cover the following: Any product not purchased from an Authorized Audiobahn Dealer (including Internet... -
Page 13: Contact Information
Dealer look at the product to confirm the source of the problem. Any product found to have a manufacturer defect will be replaced with a new piece of the same or similar model, or repaired at the discretion of Audiobahn. Any product found to have no manufacturer defect will be returned to the sender at their cost.
