- Page 1 QUALITY, RELIABILITY, & PURE BLISS MATCHED COMPONENT SPEAKER SYSTEM ABC6003N / ABC6002N / ABC5002N / ABC4002N OPERATING INTSTRUCTIONS PLEASE RETAIN MANUAL FOR FUTURE USE AND REFERENCE...
- Page 2 With four levels of play, one is right for you to get started in the Audiobahn family. Our Technical Department and entire staff look to strive above and beyond the rest of the pack by going that extra mile to help you out.
-
Page 3: Table Of Contents
Other information can be located by using the table of contents. We at Audiobahn Inc. have worked very hard to make sure that all of the information in this manual is current, but, as we are costantly finding new ways to improve our product, this information is subject to change without notice. -
Page 4: Introduction
Congratulations on your purchase of the worlds finest brand of car audio products. Here at Audiobahn Inc. we are devoted to making our musical reproduction the vert best, and we are pleased you have chosen our product. Through years of engineering expertise, hand craftsmanship, and critical testing procedures, we have created a wide range of products that reproduce music with all the clarity and richness you deserve. -
Page 5: Features And Specifications
ABC6003N: 320 RMS POWER 640 ACH POWER ABC6002N: 200 RMS POWER 400 ACH POWER ABC5002N: 160 RMS POWER 320 ACH POWER ABC4002N: 120 RMS POWER 240 ACH POWER FREQUENCY ABC6003N: 30Hz - 25kHz ABC6002N: 30Hz - 25kHz ABC5002N: 35Hz - 25kHz... -
Page 6: Mounting And Setup
Mounting ABC4002N / ABC5002N / ABC6002N Amplifier Tweeter Amplifier Midwoofer ABC6003N Amplifier Midwoofer Woofer Tweeter Amplifier... - Page 7 The red arrows in the diagram above (1, 2) point to the tweeter attenuation. Setting the switch to position (1) sets the attenuation to 0dB. Setting the switch to position (2) sets the attenuation to -3dB. ABC4002N / ABC5002N / ABC6002N ABC4002N / ABC5002N / ABC6002N...
-
Page 10: Choosing A Location
Avoid areas that do not provide a flat, sturdy mounting surface. Audiobahn series speakers are designed to fit into almost any factory location. Again, if at all possible it is recommended that you use a factory location. This applies mostly to later model vehicles. For those earlier models that do not have factory locations or are limited to front locations, it is recommended that you choose an are with sufficient airspace. -
Page 11: Installation
Installation Note: Audiobahn strongly recommends that you operate your system at low volumes prior to the completed installation of your Audiobahn speakers. This will allow a test of the speaker before securing it to its permanent location. Caution: Make sure that all speaker wiring is fully protected from cuts, tears and possible wear. All short circuits developing as a result could severely damage the source unit or possibly the amplifier as well as the speakers themselves. -
Page 12: Wiring
Wiring Wiring Audiobahn recommends using at least 18-gauge wire with your new speaker system. Thinner gauge wire may easily be severed and can cause damage to your system should any bare wires come in contact with the vehicles chassis. Makes sure that your audio system is off while installing and connecting your new Audiobahn Speakers. -
Page 13: Securing The Speaker
Securing the Speaker Securing the Speaker Once you have tested your system and confirmed that it is operating properly, turn off your system and prepare for the final mounting of the speakers. 1) Position the speaker into the mounting hole and confirm the correct mounting location and hole placement. -
Page 14: Troubleshooting
Troubleshooting In the event that your Audiobahn speakers appear to require service we ask that you first do a little trouble shooting to determine if the problem is actually the speaker, or a problem located in a different part of the vehicle such as the amplifier, wiring, fusing or possibly the source unit. -
Page 15: Warning And Disclaimer
Using a fuse of different type or rating may result in damage to this system which is not covered by the warranty. Disclaimer Specifications are subject to change without notice. For the most updated Specifications call Audiobahn, your local Authorized Audiobahn Dealer, or check the Audiobahn website. www.audiobahninc.com... -
Page 16: Warranty
Dealer look at the product to confirm the source of the problem. Any product found to have a manufacturer defect will be replaced with a new piece of the same or similar model, or repaired at the discretion of Audiobahn. Any product found to have no manufacturer defect will be returned to the sender at their cost.
