Summary of Contents for PRESERVATECH MINI ONE XL
- Page 1 MINI ONE XL - MANUAL MINI ONE XL ORIGINAL INSTRUCTIONS Year: 2019 Manufacturer: Preservatech Europe sp z o.o. Równa 1, 85-846 Bydgoszcz, Poland info@preservatech.eu www.preservatech.com...
-
Page 2: Table Of Contents
MINI ONE XL - MANUAL Table of Contents ..........................2 ABLE OF ONTENTS INSTALLATION ............................3 PACKING LIST ............................ 4 GENERAL DESCRIPTION ........................5 INSTALLATION GUIDE ........................5 OPTIONS FOR INSTALLATION: ....................5 LOCALISATION: ..........................5 POWER SUPPLY: ........................... 5 WATER FEED AND DRAIN: ...................... -
Page 3: Installation
MINI ONE XL - MANUAL INSTALLATION Please carefully read all the information in this manual to ensure proper operation of the Mini One humidity generator. MAIN UNIT AIR PUMP WATER RESERVOIR www.preservatech.com... -
Page 4: Packing List
MINI ONE XL - MANUAL PACKING LIST Standard package consists of: Mini One XL unit Air pump with (1 pc) silicone hose (1, 2 or 3 pcs) as per order Up to 100 meters air connector hose. 6,8,10 or 14 Quantity as per mm diameter. -
Page 5: General Description
MINI ONE XL - MANUAL GENERAL DESCRIPTION The system consists of a humidity control unit capable of generating a steady flow of conditioned air at a stable required humidity of 30% to 90% RH at normal indoor temperatures, at pressures suitable for distribution to museum display cases or archives storage rooms. -
Page 6: Water Feed And Drain
Water valve is supplied with a push in type compression fitting for a 6mm Ø hose which is connected to a reverse osmosis system (supplied by Preservatech) and further with the “Water Fill” fitting on the front of the machine. -
Page 7: Air Pumps
CONNECTION OF AIR HOSES TO THE CASE. The Mini One XL is a positive pressure device which is connected to the case(s) by a single or multiple hoses. Depending on the size and distance of the cases, Ø6, Ø8, Ø10 and Ø14 mm hoses may be used with a maximum length up to 100 meters. -
Page 8: Sensor Connection
SENSOR CONNECTION Digital RHT sensor supplied with Mini One XL is built inside brass housing Ø 9/32”. Cable can be up to 120 meters long. Preservatech supplies a standard 10 meter long sensor unless otherwise specified by client. -
Page 9: Ventilation
NOTE: Although all Mini One XL machines are ready to connect a 4" (100 mm) exhaust hose and hose termination, they are not included in the standard shipment and must be ordered separately. -
Page 10: Overflow Port
As the unit removes moisture from the air, the water vapor condensed will be deposited in the treatment tank reservoir. Humidity that is removed from the vitrine when the Mini One XL is in dehumidifying mode may drip from the unit at the overflow port. -
Page 11: Touch Screen Display
MINI ONE XL - MANUAL TOUCH SCREEN DISPLAY Touch screen is divided into a few areas with different purposes. Below is an explanation of all the display areas. Display will turn off after 10 minutes of being idle. Lightly tap the display to turn it back on. -
Page 12: Programming
MINI ONE XL - MANUAL PROGRAMMING After pushing “Programming Button” (H) display will change to programming mode. Display will show a list of parameters enabling the user to change certain ones. Use the slider on the right side of the display to go to the next parameter. - Page 13 If a machine is set as a master, this parameter must correpond with the slave machine(s). Must be different then master machine communication address. See chapter Master-Slave Configuration for a more in depth explanation. Language Choice between English and Chinese. Config For Preservatech staff usage only. Access secured with password. www.preservatech.com...
-
Page 14: Network Configuration
MINI ONE XL - MANUAL NETWORK CONFIGURATION To use the rhmonitoring.com service, machine must be set to work with the local Wi-Fi network. Two parameters must be known before setting up: Wi-Fi SSID (name of local WIFI network) and access password for this network. Setting can be done with any Wi-Fi enabled smartphone. -
Page 15: Using Data Logger
Please see "Programming" chapter for instructions how to set Time and Date. SHIPPING AND STORAGE The Mini One XL should be stored in a clean area with temperature between 5°C – 30°C and relative humidity below 80%. All cables, hoses and attachments must be disconnected and machine should be placed within a clear plastic bag once properly dried. -
Page 16: Limited Microclimate Generator Warranty
Preservatech at the address below, who will provide you with instructions. Service must be performed by a qualified service technician, or with the express permission of Preservatech If service is performed on the units by anyone other than an authorized service depot or agent, all obligations of Preservatech under this warranty shall be at an end. -
Page 17: Declaration Of Conformity
MINI ONE XL - MANUAL DECLARATION OF CONFORMITY DECLARATION OF CONFORMITY Product: Mini One XL Humidity Generator Description: Constant humidity generator designed for controlling relative humidity inside a museum display cases. Manufacturer: Preservatech Europe sp z o.o. Rowna 1, 85-846 Bydgoszcz...
