- Page 1 0474 EN 250 EROGATORI SEAC SUB REGULATORS SEAC DIVING PRO S.r.l. Via D. Norero, 29 16040 S. Colombano Certenoli (Ge), Italy. Tel. ++ 39 (0185) 356.301 Fax ++39 (0185) 356.300...
- Page 2 In case of any problem please contact an are for illustration use only and should not authorised SEAC SUB dealer or in case of dif- be regarded as a guide to dismantling or ficulty contact SEAC SUB. Note: All service repairing your regulator.
- Page 3 1st stage and the high pressure hose connection. SORIUS and SORIUS 1000 The SORIUS 1000 regulator is designed with a REGULATORS - 2nd STAGE 300 bars working pressure. When it is used with pressures over 200 bars it is advisable to...
- Page 4 which is highly resistant to impacts, abrasions, The "downstream" valve also provides maxi- ultraviolet rays and chemical agents. mum safety as it is also able to work in case of Incorporating silicone membranes and valve 1st stage overpressure, by releasing the exces- seat with internal component parts in chrome sive pressure, and allowing the diver to plated brass and stainless steel.
- Page 5 We suggest that with high quality materials specifically tested you contact an authorised SEAC SUB dealer in sea water it is necessary to apply care to who will be happy to arrange for the mainte- avoid corrosion and deposits due to salt water.
- Page 6 0474 EN 250 EROGATORI SEAC SUB REGULATORS PARTI DI RICAMBIO SPARE PARTS COMPOSANTS REPUESTOS ERSATZTEILE...
- Page 7 SORIUS First stage 1000 regulator 1) Handgrip S500025 2) Yoke S500028 3) Snap ring S500029 4) Cone-shaped filter S500030 SORIUS 1000 yoke nut S500031 SORIUS 6) First stage 1000 body S710009 7) LP port plug S500042 8) HP port plug S500054 9) O-Ring 2031 S101017...
- Page 8 First stage SORIUS and SORIUS ADJ regulator Handgrip S500025 Yoke S500028 Snap ring S500029 Cone-shaped filter S500030 First stage diaphragm S500039 LP port plug S500042 Diaphragm retainer ring S500040 HP port plug S500054 Spring nut plate S500041 O-Ring 2031 S101017 Setting spring S500044 O-Ring 108...
- Page 9 Second stage SORIUS and SORIUS 1000 regulator Second stage body S770001 Lever support lock S770002 Second stage diaphragm S770003 Cover SORIUS S770004N Cover SORIUS 1000 S760002 Purge button flat spring S770005 Purge button S770006 Label S770007 Mouthpiece strap S500023 Mouthpiece...
- Page 10 Second stage SORIUS ADJ regulator SORIUS ADJ second stage body S800007 Lever support lock S770002 Second stage diaphgragm S770003 SORIUS ADJ cover S800002 Purge button flat spring S770005 Purge button S770006 Label S770007 Mouthpiece strap S500023 Mouthpiece Exhaust valve S500009 Exhaust tee S770008 Elastic stop nut...
