- Page 1 QUALITY, RLIABILITY, & PURE BLISS 7" MONITOR WITH IR HEADSET AND HEADREST MOUNTING BRACKET AVM170TP OPERATING INTSTRUCTIONS PLEASE RETAIN MANUAL FOR FUTRE USE AND REFERENCE...
-
Page 3: Table Of Contents
Table of Contents Table of Contents INTRODUCTION MONITOR INTRODUCTION SAFETY BEFORE USING THE MONITOR FEATURES SPECIFICATIONS SAFETY PRECAUTION HEADPHONE AND CONTROLS AVHK1 MOUNTING INSTRUCTIONS CONTROLS AND FUNCTIONS CONNECTIONS INSTALLATION CHANGING BATTERIES WARNING / DISCLAIMER WARRANTY 14-19 20-21 25-26... -
Page 5: Monitor Introduction
Monitor Introduction... -
Page 6: Safety
Safety y f i y l l o l l o l l... - Page 7 Safety...
- Page 8 Safety...
-
Page 9: Before Using The Monitor
Before Using The Monitor... -
Page 10: Features
Features Full Function on-screen display (OSD) Three A/V inputs (Composite AV1/AV2/AV3) AV1: Audio and Video (For use with most audio video equipment) AV2: Video only (For use with a backup camera or other device with video output only to the monitor) AV3: Video Only (For use with devices with video output only to the monitor such as a gaming system where the audio goes throughthe main car audio system) -
Page 11: Specifications
Specifications... -
Page 13: Headphone And Controls
Headphone & Controls AVH1 SPECIFICATIONS FM system carrier frequency: Right channel 2.8MHz / Left channel 2.3MHz Light weight design for comfort fit Automatic muting design on receiving headphones Volume control and ON / OFF power switch Speaker size: 40mm mylar cone Impedance: 32 Ohms 15% Effective use range (maximum): About 10 meters Power source: (2) AAA batteries... -
Page 14: Avhk1 Mounting Instructions
AVHK1 Mounting Instructions Adjust the legs of the bracket to fit your headrest (Fig.1) Slide Monitor onto the bracket, then tighten bracket to keep monitor in place.(Fig.2) Then replace headrest to keep monitor bracket in place (Fig.3) Figure 1 Figure 2 Figure 3... -
Page 15: Included Components
Included Components Your monitor package should include the following: TFT LCD 7” Monitor Remote Monitor Stand Headrest Shroud AV Cable Owner’s Manual Headrest Bracket AV3 Cable IR Headphones... -
Page 16: Controls And Functions
Controls and Functions Turns the monitor On / OFF Will mute the audio output of the monitor Resets all seettings to factory defaults Changes source selection to AV1 inputs Changes source selection to AV2 inputs Changes source selection to AV3 inputs Opens the Menu OSD Moves Menu selection left Moves Menu selection right... - Page 17 Controls and Functions Brightness: Adjusts the brightness setting of the monitor Contrast: Adjusts the contrast setting of the monitor Color: Adjusts the color setting of the monitor Tint: Adjusts the tint setting of the monitor Up and Down: Flips the image shown on the screen up and down Mirror: Reverses the image shown on the screen left to right 16:9 &...
-
Page 18: Changing Batteries
Changing Batteries... -
Page 19: Wiring Diagram
Wiring Diagram +12V Power (RED) Ground (BLACK) Left Audio Input (Red) Video Input 1 (Yellow) Video Input 2 (Yellow) Video Input 3 (Yellow) Left Audio Input (White) -
Page 22: Warranty
Dealer look at the product to confirm the source of the problem. Any product found to have a manufacturer defect will be replaced with a new piece of the same or similar model, or repaired at the discretion of Audiobahn. Any product found to have no manufacturer defect will be returned to the sender at their cost. -
Page 23: Tech Notes
TECH NOTES... - Page 24 TECH NOTES...
