- Page 1 QUALITY, RLIABILITY, & PURE BLISS FLIP DOWN ACTIVE MATRIX TFT-LCD MONITORS AVM730IRV / AVM809IRV / AVM104IRV OPERATING INTSTRUCTIONS PLEASE RETAIN MANUAL FOR FUTRE USE AND REFERENCE...
- Page 2 With four levels of play, one is right for you to get started in the Audiobahn family. Our Technical Department and entire staff look to strive above and beyond the rest of the pack by going that extra mile to help you out.
-
Page 3: Table Of Contents
Table of Contents Table of Contents INTRODUCTION UNPACKING YOUR MONITOR SYSTEM SAFETY PRECAUTION PECIFICATIONS SYSTEM FEATURES AND CONTROLS REMOTE CONTROL FUNCTIONS INSTALLATION OSD FOR AVM730IRV OSD FOR AVM104IRV WARNING / DISCLAIMER WARRANTY 9-10 12-13 15-16... -
Page 4: Introduction
Congratulations on your purchase of the worlds finest brand of car audio products. Here at Audiobahn Inc. we are devoted to making our musical reproduction the very best, and we are pleased you have chosen our product. Through years of engineering expertise, hand craftsmanship, and critical testing procedures, we have created a wide range of products that reproduce music with all the clarity and richness you deserve. -
Page 5: Unpacking Your Monitor System
If any item(s) are missing from the list below, please contact the dealer you purchased the equipment from immediately. The Audiobahn Flip Down Systems Include: Monitor with Flipdown Housing 7.2" TFT-LCD Monitor in AVM730IRV 10.4"... -
Page 7: Pecifications
Operating Voltage (DC) 1 Vp-p (positive) 75 Ohms Video Signal Pixel Configuration Video Input AVM730IRV AVM104IRV 7.2" (16:9) 10.4" (4:3) 1152 (H) x 234 (V) 1920 (H) x 480 (V) 45 / 45 / 10 / 30 (L/R/T/B) 30 / 20 / 45 / 45 (L/R/T/B) -
Page 8: System Features And Controls
System Features and Controls 3-Position Dome Light Off / Auto / On Up / Down Keys These multipurpose keys are used to increase or decrease the selected parameter, such as contrast, color and so on. Mode This button brings up the menu screen for adjustment of a range of monitor parameters such as color, tint and so on. -
Page 9: Remote Control Functions
Remote Control Functions Power Turns on the power to the monitor Mode This button brings up the menu screen for adjustment of a range of monitor parameters such as color, tint and so on. Up / Down Keys These multifunction keys are used to increase and decrease the selected parameter, such as contrast, color and so on Swithces the monitor between AV1 and AV2. -
Page 10: Installation
Installation YELLOW(RCA): Video 1 input WHITE(RCA): Video 2 input Power Connection for the monitor RED: Ignition switch (+12 volt) BLACK: Ground RED(RCA):Right audio input for IR circuit. WHITE( NOTE: Because of frequencyinterference, using multiple monitors in your vehicle with built in IR can create distortion to the audio of the headphones.) NOTE: (+12 volt) RED wire and Ground wire have to be connected for wireless IR circuit... -
Page 11: Installation
Installation Step1: Use mounting bracket (A) to cut out the size of ceiling to provide a mounting surface which the housing of the flip down monitor can be attached. Step2: Use tapping screws or rivets on position (B) for mounting bracket (A) on the vehicles roof. -
Page 13: Osd For Avm104Irv
OSD for AVM104IRV 1. Press "Power" on the monitor or remote to turn on the monitor. 2. Press "Mode" on the monitor or remote to display the on screen adjustment menu as shown below: Color Miscellaneous Exit 3. Press "UP" or "DOWN" on the monitor or remote to select the setting to adjust. Then press "Mode"... -
Page 14: Osd For Avm104Irv
OSD for AVM104IRV Translucent: After selecting Translucent by using the Mode button, use UP or DOWN to turn translucent on or off. The Miscellaneous selection opens a submenu with additional parameters. Selecting Miscellaneous reveals the following screen: Signal Source Reset... -
Page 15: Warning / Disclaimer
Using a fuse of different type or rating may result in damage to this system which is not covered by the warranty. Specifications are subject to change with out notice. For the most updated Specifications call Audiobahn, or your local Authorized Audiobahn Dealer, or check the Audiobahn website. -
Page 16: Warranty
You must receive prior authorization and an RA# before sending in any complete enclosure). Audiobahn will only replace L.E.D.(s) found to be defective at the time of purchase. Audiobahn warranties do not cover the following: Any product not purchased from an Authorized Audiobahn Dealer (including Internet... - Page 17 Dealer look at the product to confirm the source of the problem. Any product found to have a manufacturer defect will be replaced with a new piece of the same or similar model, or repaired at the discretion of Audiobahn. Any product found to have no manufacturer defect will be returned to the sender at their cost.
