Summary of Contents for Axess X Wireless Series
- Page 1 Installation Manual...
- Page 2 Access tags can be linked to alarm codes to be able to arm and disarm the alarm. Clear Interface Memory When powering up for the first time and the aXess readers do not show the correct LEDs short the “RESET” jumper (see fig 3) for three seconds.
- Page 3 Hold down [*] until beep Enter Master user code [1] [2] [3] [4] [*] aXess control menus are: o Menu 32 “Add/Edit Card” by typing in the tag number o Menu 33 “Add/Edit Card” by Swiping the tag o Menu 34 “...
- Page 4 Reader Feedback Each access reader has three different colour LEDs, Red, Yellow, Green and a buzzer to communicate feedback to users of the system depending on the type of reader Figure 1: aXess Reader LEDS Green Yellow X-Series aXess 700-560-01E...
- Page 5 Following Partition's ON if comms to panel Door Left Open Beep (if door Door Left Open ARM LED is good. switch connected and configured) Tag held in field Not Available (Arming Time) X-Series aXess 700-560-01E...
- Page 6 Door Left Open Beep (if door Door Left Open ARM LED is good. switch connected and configured) Tag held in field Following Partition's Slow Flash Following Relay None (Arming Time) ARM LED Diagrams Figure 2: Interface Inputs Wiring Diagram X-Series aXess 700-560-01E...
- Page 7 Figure 3: Tag Reader Wiring Diagram Figure 4: Jumpers Mode Jumper Term Jumpers Used if Wiegand device Do not short attached Reset Jumper Clears all memory X-Series aXess 700-560-01E...
- Page 8 X-Series aXess 700-560-01E...
