NAVIGATOR DVB-T/H
CABLE CONNECTIONS FOR NAVIGATOR DVB-T/H
Antenna 2 (not used for
Cigar lighter power supply (to connect to
Band-L option)
the external battery or other 12 V source )
Antenna 1
Crossover (B) or
straight (A)
Headphone's
BNC cable (N)
GPS cable (I)
Ethernet cable
output
!
Warning: So as to ensure measurements are correct, always leave both antennas plugged in
Navigator ® and AUDEMAT -AZTEC ® are registered trademarks of AUDEMAT -AZTEC Company.
Advertisement
Table of Contents
Summary of Contents for Audemat-Aztec NAVIGATOR DVB-T/H
- Page 1 NAVIGATOR DVB-T/H CABLE CONNECTIONS FOR NAVIGATOR DVB-T/H Antenna 2 (not used for Cigar lighter power supply (to connect to Band-L option) the external battery or other 12 V source ) Antenna 1 Crossover (B) or straight (A) Headphone’s BNC cable (N)
- Page 2 (B) ou droit (A) Sortie Câble BNC (N) Câble GPS (I) écouteurs Attention : les 2 antennes doivent être branchées en permanence pour que les mesures soient correctes Navigator ® et AUDEMAT -AZTEC ® sont des marques dépos ées par AUDEMAT-AZTEC, SA.
