General Guidelines
• It is the user's responsibility to read and follow all instructions.
• Keep these instructions with the product at all times and review before each use.
• It is the responsibility of this product's owner to furnish the instructions to any
person that borrows or purchases the product.
• Inspect the product before use to ensure it is assembled properly and all parts are in
safe working order and free of defects.
• Never modify this product in any way.
• All circumstances cannot be addressed in these instructions. Please use common
sense and practice general safety measures when using this product.
• Parts and/or instructions are subject to change without notice.
Do not exceed the 800 lbs weight capacity.
•
Length
Width
Height
Maximum Weight Capacity
Rev. 062118
4 Post Aluminum Truck Rack
Instructions for Part # ATR-RACK-V2
Technical Specifications
Property
DiscountRamps.com • 1-888-651-3431
Specification
13.8in.
70.5in.
36.5in.
800lbs.
Page 1
Advertisement
Table of Contents
Summary of Contents for DiscountRamps Apex ATR-RACK-V2
- Page 1 • Parts and/or instructions are subject to change without notice. Do not exceed the 800 lbs weight capacity. • Technical Specifications Property Specification Length 13.8in. Width 70.5in. Height 36.5in. Maximum Weight Capacity 800lbs. DiscountRamps.com • 1-888-651-3431 Rev. 062118 Page 1...
- Page 2 10 locking washer(22),Square nut(18) ST4.8×16 cross recessed pan head tapping screws(23) T- nuts(24)，10 flat washer(17),10 spring washer(16),Square nut(18) Tools Required: 17mm Wrench (1 pc.) 6mm Allen Wrench (1 pc.) Tape Measure (1 pc) DiscountRamps.com • 1-888-651-3431 Rev. 062118 Page 2...
- Page 3 ASSEMBLY/PARTS DIAGRAM DiscountRamps.com • 1-888-651-3431 Rev. 062118 Page 3...
- Page 4 (5), is not level and The upper connecting parallel to rear leg rail base (5), is level and mount (3), because it is parallel to rear leg rail facing wrong mount (3). direction. DiscountRamps.com • 1-888-651-3431 Rev. 062118 Page 4...
- Page 5 M10x25 Button Head Screws (14), can be tightened to lock the crossbar in place on the support arms. Repeat the same process for the rear rack assembly. Equal overhang on both sides DiscountRamps.com • 1-888-651-3431 Rev. 062118 Page 5...
- Page 6 Mounts, securely affixing both crossbar assemblies to the truck bed rails as shown. WARNING! ALL EIGHT C-CLAMPS MUST BE PROPERLY INSTALLED AS SHOWN FOR SAFE OPERATION OF THIS RACK. Position clamps at least 4” apart DiscountRamps.com • 1-888-651-3431 Rev. 062118 Page 6...
- Page 7 ④ Your installed rack should now resemble this diagram. Check to make sure all hardware has been securely tightened. Congratulations, your rack is now ready for use. Please remember to haul your loads safely. DiscountRamps.com • 1-888-651-3431 Rev. 062118 Page 7...
- Page 8 DiscountRamps.com • 1-888-651-3431 Rev. 062118...
